Sharp DV-NC70 - Page 10

10
DV-NC70/W
DV-NC70X/RU
13
16
14
15
19
18
17
20
(6) Remove the two screws e to remove the Power PWB
Unit.
5) Removing the Cassette Housing Control/VCR Mechanism.
(1) Remove the two screws r.
(2) Remove the one screw t.
(3) Remove the two screws y.
6) Removing the Antenna Terminal Cover/VCR Main PWB Unit.
(1) Remove the four screws u.
(2) Remove the two screws i.
(3) Remove the one screw o.
7) Removing the Bottom Plate.
(1) Remove the one screw p.
