Sharp DV-NC70 - Page 81

98
DV-NC70/W
DV-NC70X/RU
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
MISCELLANEOUS PARTS
CN3201 QPLGN0964TAZZY Plug, 9Pin AF
CN3202 QSOCN1136TAZZY Socket, 11Pin AE
CN3301 QSOCN2336TAZZY Socket, 23Pin AF
CN3501 QSOCN2936TAZZY Socket, 29Pin AF
CN3701 QPLGN0664TAZZY Plug, 6Pin AD
CN3702 QPLGN0564TAZZY Plug, 5Pin AC
DUNTKB374TEV2
DVD Operation PWB Unit
DISPLAYS
LCD8002 RLCDD0005GEZZ Display AN
LCD8052 RLCDDA006WJZZ Display AM
INTEGRATED CIRCUITS
IC8002 VHiPT6596++-1Q PT6596++, LCD Driver AM
IC8051 VHiPT6596++-1Q PT6596++, LCD Driver AM
TRANSISTOR
Q8050 VSKRC102S//-1Y KRC102S AA
LED’S
D8001 RH-PXA008WJZZ+ PhotoDiode, B/L LED AF
D8002 RH-PXA008WJZZ+ PhotoDiode, B/L LED AF
D8005 RH-PX0297GEZZ+ PhotoDiode, DVD LED AD
D8006 RH-PXA008WJZZ+ PhotoDiode, VTR LED AF
D8007 RH-PX0297GEZZ+ PhotoDiode, DVD LED AD
D8051 RH-PX0449AJZZ+ PhotoDiode, Timer LED AC
D8053 RH-PX0449AJZZ+ PhotoDiode, Dub LED AC
D8054 RH-PXA021WJZZ+ PhotoDiode, B/L LED AD
D8055 RH-PXA021WJZZ+ PhotoDiode, B/L LED AD
D8056 RH-PXA021WJZZ+ PhotoDiode, B/L LED AD
D8057 RH-PXA021WJZZ+ PhotoDiode, B/L LED AD
CAPACITORS
C8001 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8002 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8003 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8004 VCEA9M1CW106M+ 10 16V Electrolytic AB
C8005 VCEA9M1CW106M+ 10 16V Electrolytic AB
C8006 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8007 VCCCCY1HH101JY 100p 50V Ceramic AA
C8008 VCCCCY1HH100DY 10p 50V Ceramic AA
C8009 VCCCCY1HH101JY 100p 50V Ceramic AA
C8010 VCKYCY1HB102KY 1000p 50V Ceramic AA
C8051 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8052 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8053 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8054 VCEA9M1CW106M+ 10 16V Electrolytic AB
C8055 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C8056 VCKYCY1HB102KY 1000p 50V Ceramic AA
C8057 VCKYCY1HB102KY 1000p 50V Ceramic AA
C8058 VCKYCY1HB102KY 1000p 50V Ceramic AA
C8059 VCKYCY1HB102KY 1000p 50V Ceramic AA
RESISTORS
RJ801 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
RJ803 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
RJ805 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
R8001 VRS-CY1JF473JY 47k 1/16W Metal Oxide AA
R8002 VRD-RA2BE391JY 390 1/8W Carbon AA
R8005 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R8006 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R8007 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R8008 VRD-RA2BE101JY 100 1/8W Carbon AA
R8009 VRD-RA2BE271JY 270 1/8W Carbon AA
R8010 VRD-RA2BE471JY 470 1/8W Carbon AA
R8050 VRD-RA2BE271JY 270 1/8W Carbon AA
R8051 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R8052 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R8053 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R3737 VRS-CY1JF101JY 100 1/16W Metal Oxide AA
R3738 VRS-CY1JF101JY 100 1/16W Metal Oxide AA
R3740 VRS-CY1JF103JY 10k 1/16W Metal Oxide AA
R3741 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R3742 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R3743 VRS-CY1JF101JY 100 1/16W Metal Oxide AA
R3744 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R3750 VRS-CY1JF153JY 15k 1/16W Metal Oxide AA
R3751 VRS-CY1JF823JY 82k 1/16W Metal Oxide AA
R3752 VRS-CY1JF823JY 82k 1/16W Metal Oxide AA
R3753 VRS-CY1JF153JY 15k 1/16W Metal Oxide AA
R3756 VRS-CY1JF273JY 27k 1/16W Metal Oxide AA
R3760 VRS-CY1JF183JY 18k 1/16W Metal Oxide AA
R3761 VRS-CY1JF104JY 100k 1/16W Metal Oxide AA
R3762 VRS-CY1JF104JY 100k 1/16W Metal Oxide AA
R3763 VRS-CY1JF823JY 82k 1/16W Metal Oxide AA
R3764 VRS-CY1JF104JY 100k 1/16W Metal Oxide AA
R3765 VRS-CY1JF393JY 39k 1/16W Metal Oxide AA
R3766 VRS-CY1JF183JY 18k 1/16W Metal Oxide AA
R3767 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
R3768 VRS-CY1JF153JY 15k 1/16W Metal Oxide AA
R3801 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
R3803 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
R3804 VRS-TV1JD470JY 47 1/16W Metal Oxide AA
R3807 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
R3808 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
R3811 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
R3812 VRS-CY1JF000JY 0 1/16W Metal Oxide AA
BALUNES
FB3301 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3302 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3501 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3502 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3503 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3504 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3505 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3507 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3508 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3509 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3510 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3511 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3512 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3513 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3514 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3515 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3516 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3517 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3520 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3521 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3522 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3523 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3524 RBLN-0077TAZZY Balun, BLN-0077TA AB
FB3601 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3602 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3604 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3701 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3702 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3703 RBLN-0061TAZZY Balun, BLN-0061TA AD
FB3802 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3213 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3214 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3215 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3216 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3217 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3218 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3639 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3642 RBLN-0061TAZZY Balun, BLN-0061TA AD
R3814 RBLN-0061TAZZY Balun, BLN-0061TA AD
DUNTKB209TE6S(NC70/W)
DUNTKB209TE6T(NC70RU)
DUNTKB209TE6X(NC70X)
DVD Main PWB Unit(Continued)
