100
DV-NC70/W
DV-NC70X/RU
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
DUNTKB517TEV1(NC70W)
DUNTKB517TEV2(NC70)
DUNTKB517TEV3(NC70X/RU)
VCR Main PWB Unit
TUNER
TU101 VTUATMDG2-836 VHF Tuner(NC70X/RU) BE
TU101 VTUATMDZ2-901 VHF Tuner(NC70/W) BK
INTEGRATED CIRCUITS
IC201 VHiHA8317F/-1 HA8317F, BA
Y/C Audio Processor
IC601 VHiTC4S66F/-1Y TC4S66F AD
IC651 VHiAN3651FB-1 AN3651FB, AU
Hifi Audio Processor
IC701 RH-iXA214WJZZQ IXA214WJ AX
IC703 VHiPST3225N1EY PST3225 AD
IC710 VHiBR24C08F-1Y BR24C08F, E
2
PROM AF
IC801 RH-iX1539CEZZY IX1539CE AE
IC2001 VHiMM1567AJ-1Y MM1567AJ, LPF+ Driver AM
IC2002 VHiMM1501XN-1Y MM1501XN
, Dub Video SW
AE
IC2003 VHiMM1508XN-1Y MM1508XN
, Comp. Driver
AE
IC6004 VHiNJM4565M-1Y NJM4565M, Audio Amp AE
TRANSISTORS
Q251 VS2PB709AR/-1Y 2PB709AR AB
Q302 VSKRC103S//-1Y KRC103S AA
Q305 VS2PD601AR/-1Y 2PD601AR AB
Q401 VSKRC102S//-1Y KRC102S AA
Q402 VS2SK1826++-1Y 2SK1826++ AC
Q403 VSKRC102S//-1Y KRC102S AA
Q501 VS2PD601AR/-1Y 2PD601AR AB
Q502 VSKRA102S//-1Y KRA102S AA
Q503 VSKRC102S//-1Y KRC102S AA
Q602 VS2SC3203Y/-1+ 2SC3203Y AC
Q603 VS2PD601AR/-1Y 2PD601AR AB
Q604 VSKRA103S//-1Y KRA103S AA
Q605 VS2PD601AR/-1Y 2PD601AR AB
Q606 VS2PD601AR/-1Y 2PD601AR AB
Q613 VS2PD601AR/-1Y 2PD601AR AB
Q651 VS2PD601AR/-1Y 2PD601AR AB
Q652 VS2PD601AR/-1Y 2PD601AR AB
Q655 VS2PD601AR/-1Y 2PD601AR AB
Q658 VSKRA104S//-1Y KRA104S AA
Q659 VSKRA104S//-1Y KRA104S AA
Q660 VSKRC104S//-1Y KRA104S AA
Q704 VS2PB709AR/-1Y 2PB709AR AB
Q705 VS2PD601AR/-1Y 2PD601AR AB
Q706 VS2PB709AR/-1Y 2PB709AR AB
Q710 VS2PD601AR/-1Y 2PD601AR AB
Q711 VS2PD601AR/-1Y 2PD601AR AB
Q712 VSKRC102S//-1Y KRC102S AA
Q850 VS2PD601AR/-1Y 2PD601AR AB
Q851 VSKRC102S//-1Y KRC102S AA
Q852 VSKRC102S//-1Y KRC102S AA
Q853 VSKRA103S//-1Y KRA103S AA
Q854 VSKRA103S//-1Y KRA103S AA
Q859 VS2PB709AR/-1Y 2PB709AR AB
Q860 VSKRC102S//-1Y KRC102S AA
Q861 VS2PD601AR/-1Y
2PD601AR, LCD Back Light
AB
Q1901 VS2SC3852A/-1 2SC3852A, M_27V AH
Q1904 VSKRC102S//-1Y KRC102S AA
Q1905 VS2SA1271-Y-1+
2SA1271-Y, PC_5V(3) SW
AC
Q1907 VS2SA1271-Y-1+
2SA1271-Y, PC_5V(3) SW
AC
Q1908 VS2SA1271-Y-1+
2SA1271-Y, PC_5V(2) SW
AC
Q1910 VSKRC102S//-1Y KRC102S AA
Q1911 VSKRC102S//-1Y KRC102S AA
Q1912 VSKRC103S//-1Y KRC103S AA
Q1913 VSKRC102S//-1Y KRC102S AA
Q1914 VS2SB1443TV1E+
2SB1443TV, PC_13V SW
AE
Q1915 VS2SA1015Y/1E+ 2SA1015Y, PC_40V SW AB
Q1916 VSKRC103S//-1Y KRC103S AA
Q1918 VS2SC3203Y/-1+ 2SC3203Y AC
Q2001 VS2PB709AR/-1Y 2PB709AR AB
Q6003 VSKRC104S//-1Y KRC104S AA
C945 VCEA9M1CW107M+ 100 16V Electrolytic AB
C946 VCEA9M1HW225M+ 2.2 50V Electrolytic AB
C948 VCEA9M0JW227M+ 220 6.3V Electrolytic AB
C949 VCEA9M1HW105M+ 1 50V Electrolytic AB
C950 VCEA9M0JW476M+ 47 6.3V Electrolytic AB
C952 VCEA9M1CW226M+ 22 16V Electrolytic AB
RESISTORS
å R901 VRD-RA2EE474JY 470k 1/4W Carbon AA
å R902 RR-HZ0014GEZZY 12M 1/2W
Alumina Ceramic
AE
å R903 VRS-CY1JF564JY 560k 1/16W Metal Oxide AA
å R905 VRD-RM2HD222JY 2.2k 1/2W Carbon AA
å R907 VRD-RA2HD184JY 180k 1/2W Carbon AB
å R908 VRD-RA2HD184JY 180k 1/2W Carbon AB
å R910 VRN-VV3DBR39J 0.39 2W Metal Film AA
R911 VRD-RA2BE273JY 27k 1/8W Carbon AA
R912 VRS-CY1JF223JY 22k 1/16W Metal Oxide AA
R914 VRS-CY1JF683JY 68k 1/16W Metal Oxide AA
R917 VRS-CY1JF223JY 22k 1/16W Metal Oxide AA
R919 VRS-CY1JF101JY 100 1/16W Metal Oxide AA
R921 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R923 VRD-RA2BE471JY 470 1/8W Carbon AA
R924 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R925 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R926 VRD-RA2BE121JY 120 1/8W Carbon AA
R927 VRS-CY1JF332JY 3.3k 1/16W Metal Oxide AA
R928 VRD-RA2BE102JY 1k 1/8W Carbon AA
R929 VRS-CY1JF100JY 10 1/16W Metal Oxide AA
R931 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R932 VRS-CY1JF562JY 5.6k 1/16W Metal Oxide AA
R933 VRD-RA2BE103JY 10k 1/8W Carbon AA
R934 VRD-RM2HD102JY 1k 1/2W Carbon AA
R935 VRS-CY1JF103JY 10k 1/16W Metal Oxide AA
R936 VRD-RA2BE221JY 220 1/8W Carbon AA
R937 VRS-CY1JF103JY 10k 1/16W Metal Oxide AA
R938 VRD-RA2BE221JY 220 1/8W Carbon AA
R939 VRD-RA2BE103JY 10k 1/8W Carbon AA
R940 VRD-RA2BE102JY 1k 1/8W Carbon AA
R941 VRD-RA2BE103JY 10k 1/8W Carbon AA
R942 VRD-RA2BE102JY 1k 1/8W Carbon AA
R943 VRS-CY1JF683JY 68k 1/16W Metal Oxide AA
R944 VRS-CY1JF102FY 1k 1/16W Metal Oxide AA
R945 VRS-CY1JF222FY 2.2k 1/16W Metal Oxide AA
R946 VRS-CY1JF681FY 680 1/16W Metal Oxide AA
R947 VRS-CY1JF272FY 2.7k 1/16W Metal Oxide AA
R950 VRS-CY1JF222JY 2.2k 1/16W Metal Oxide AA
R952 VRD-RA2BE222JY 2.2k 1/8W Carbon AA
R956 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R957 VRS-CY1JF104JY 100k 1/16W Metal Oxide AA
BALUNES
å FB901 RBLN-0090GEZZY Balun, BLN-0090GE AB
FB921 RBLN-0090GEZZY Balun, BLN-0090GE AB
FB922 RBLN-0090GEZZY Balun, BLN-0090GE AB
MISCELLANEOUS PARTS
å ACC901 QACCB5005AJZZ AC Cord(NC70W) AY
å ACC901 QACCL3004AJZZ AC Cord(NC70X) AT
å ACC901 QACCV2009AJZZ AC Cord(NC70/RU) AM
CN201 QPLGN0978GEZZ Plug, 9Pin AC
å F901 QFS-C2025CEZZ Fuse, 2A/250V AD
å FH901 QFSHD1017CEZZ+ Fuse Holder AC
å FH902 QFSHD1018CEZZ+ Fuse Holder AC
å P901 QPLGN0269GEZZ Plug, 2Pin AB
P902 QPLGN1278GEZZ Plug, 12Pin AC
å W901 PRDAF5021AJFW Heat Sink, Q901 AE
å W902 XBPSD30P10KS0 Screw AA
W908 PRDAR0083PEFW Heat Sink, IC908 AD
W909 XBPSD30P10KS0 Screw AA
DUNTKB376TEV2
Power PWB Unit(Continued)
To Next Page
