35
DW-71-H
REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 DPWB-A150PRK0 Control P.W.B. unit 1 AN
1- 2 RC-EZA010FBE0 Running capacitor 4µF 1 AP
1- 3 RMOT-A046FBE0 Fan motor 1 BA
1- 4 DPWB-A149PRK0 Power supply P.W.B. unit 1 AX
1- 5 FACCJA025FBK0 Power supply cord 1 AL
1- 7 RHOG-A008FBE0 Protector 1 AQ
1- 8 QSW-MA004FBE0 Micro switch 1 AK
1-10 RH-HZA007FBE0 Thermistor 1 AL
1-11 PCLI-A015FBE0 Solenoid coil assembly 1 AV
1-12 QSW-PA005FBK0 Power switch 1 AH
1-13 QSW-PA001FBE0 SPUN switch 1 AF
1-14 RTRNPA029PRE0 Transformer 1 AY
APPEARANCE PARTS
2- 2 GBDY-A049FBFB Rear body 1 AV
2- 3 LHLD-A014FBF0 Damper holder 1 AD
2- 4 PGID-A001FBFB Damper 1 AF
2- 5 GBDY-A053FBFB Front body 1 AX
2- 7 GFTAFA003FBFB Front lid 1 AH
2- 8 LANG-A029FBM0 Handle support angle 1 AG
2- 9 PSEL-A108FBRA Control panel Sheet 1 AN
2-14 FFRM-A013FBK0 Rear frame 1 AU
2-15 LBND-A002CBE0 Band 2 AA
2-16 LBND-0005CBE0 Comp. holder band 1 AB
2-17 PFPF-A005FBE0 Comp. felt 1 AB
2-18 PGUM-A006CBF0 Vibration proof rubber 1 AE
2-19 PGUM-A008FBE0 Vibration proof rubber 3 AH
2-20 PGUM-A009FBF0 Pipe vibration proof rubber 1 AE
2-21 PKYU-A005FBE0 Cushion 2 AC
2-22 PSRA-A008FBF0 Evaporating pan 1 AL
2-23 FFLO-A007FBF0 Float 1 AG
2-24 JHND-A001FBF0 Tank handle 1 AF
2-25 PTNKNA012FBRA Drain tank 1 AQ
2-26 LANG-A030FBW0 Motor fixing angle 1 AH
2-27 NFANSA003FBE0 Centrifagal fan 1 AN
2-28 PDUC-A007FBF0 Casing 1 AN
2-29 FBOX-A010FBF0 Control box 1 AR
2-30 GWAKPA009FBFB Filter frame 1 AP
2-32 LHLD-A006CDF0 Switch holder 1 AF
2-33 PLEV-A004FBF0 Switch lever 1 AD
2-34 GCOVHA001FBF0 Power supply cover 1 AG
2-35 GGADPA001FBFA Fin cover 1 AF
2-36 JHNDPA011FBFB Handle 1 AG
2-37 LANG-A024FBFE Handle stopper 1 AE
2-38 JKNBKA007FBFB Button A 1 AD
2-39 JKNBKA008FBFB Button B 1 AD
2-40 PCOV-A033FBF0 Water proof rubber 1 AE
2-41 PBOX-A008FBF0 Switch box 1 AE
2-42 PCOV-A034FBF0 Water proof rubber 1 AE
2-43 PCOVPA005FBP0 Trans. cover 1 AE
2-44 LHLD-A030AKE0 SL-4N clip 1 AA
2-45 LX-BZ0202JBE0 Earth screw 1 AA
2-46 LX-NZA005FBE0 Nut 3 AC
THE OTHERS PARTS
4- 1 PKYU-A002FBE0 Suction pipe butyl 1 AD
4- 2 LX-TZA001FBE0 Special screw 1 AC
CYCLE PARTS
6- 1 DEVA-A010FBE0 Evaporator 1 BB
6- 2 PPIPCA064FB10 Junction pipe 1 AH
6- 3 DPIPCA001FBY0 Discharge pipe 1 AU
6- 4 PPIPCA065FB10 Gum valve out-pipe 1 AG
6- 5 PVLVEA001FBE0 Gum valve 1 AR
6- 6 CPIPCA036FBY0 Capillary pipe 1 AP
6- 7 CPIPCA037FBK0 Suction pipe 1 AY
6- 8 CDRY-A001FBK0 Dryer 1 AS
6- 9 PETE-A004FBE0 Condenser 1 BC
6-10 PPIPCA068FB10 Condenser 1 AH
6-11 PCMPLA008FBE0 Compressor 1 CB
