Digital Full Colour Multifunctional System
DX-C200
420 mm
493 mm
476 mm
SHARP CORPORATION OF AUSTRALIA PTY LTD
ABN 40 003 039 405
1 Huntingwood Drive, Huntingwood NSW 2148
P.O. Box 6827, Blacktown, NSW 2148
Tel: (02) 9830 4600 Fax: (02) 9672 1208
www.sharp.net.au
All in one performance
• Four functions in one as standard – copy, print, scan and fax.
• Full colour network scanning with scan to email/FTP server/network
folder/USB memory and support for JPEG, TIFF, and PDF formats.
• USB port allows easy scan to USB memory.
• Convenient access for shared use in growing offices with
standard networking including IPV6 support.
• Super G3 fax and Internet fax that supports direct SMTP (in B/W).
• Standard 250 sheet paper capacity, expandable to max.
750 sheets (plus 1-sheet bypass tray).
Highly Productive Operation
• Speedy output of max. 20 ppm in both colour and B/W.
• Fast first print out time of 14 sec. in colour and B/W with short
warm up time of less than 30 seconds.
• Standard 35-sheet Single Pass Feeder.
• Standard automatic duplex printing.
• Easy management of multiple jobs with a powerful 400 MHz
controller and 256 MB RAM.
• ID card copy facility enables both sides of a document to be copied
onto a single sheet, saving paper and time.
Compact Design and Enhanced Usability
• Small in size to fit into any workspace
• Easy to use 4-line operation panel – raised for easy access to
device settings and alerts, such as toner or paper needs replacing.
• Web Image Monitor for remote monitoring of system in
real-time offers immediate access to supply status and print
network settings.
Superb Image Quality
• High quality colour business documents with true 600 x 600 dpi
and interpolated resolutions of up to 2,400 x 600 dpi.
• Full colour and black & white scanning at up to 1200 x 1200 dpi.
• Vibrant colour and sharp text delivered on a wide range of media.
Environmentally Advanced and Cost Saving
• Certified for Energy Star®.
• Low power consumption and short warm-up time saves energy.
• Energy saving sleep mode.
• High-yield all-in-one toner saves cost and time.
• Optimise toner usage with Economy Colour/Toner Save Mode,
limiting the amount of toner used on images and graphics to
reduce output costs.
• Duplex printing saves paper and reduces costs.
GENERAL
Type Desktop
Paper size Max. A4, min. A6
Paper weight (g/m
2
)
Drawer 60 – 160
Bypass 60 – 160
Optional Drawer 60 – 105
Paper capacity (Std – Max)
Sheets 250 - 270 (plus 1 sheet bypass tray)
Drawers 1 - 2 (plus 1 sheet bypass tray)
Warm-up time*
1
(seconds)
30
First print out time*
2
(seconds)
Full colour 14
B/W 14
Memory (MB) 256
Power requirements 230~240V AC, 50/60 Hz
Power consumption (Max) 1.3 kW
Dimensions (mm)
(W x D x H)
420 x 493 x 476
Weight (kg) 30
COPIER
Original paper size (Max) A4
First copy time*
3
(seconds)
Full colour 30
B/W 30
Continuous copies (Max) 99
Resolution (dpi)
Scan 600 x 600
Print 600 x 600, (600 x 300 via SPF)
Gradation levels 256
Zoom range (%) 25 – 400 in 1% increments
Preset copy ratios 8 (4R/4E)
NETWORK PRINTER
Resolution (dpi) 600 x 600, 1200 x 600, 2400 x 600*
4
Interface USB 2.0, 10Base-T/100Base-TX
Supported OS Windows® XP, Windows® Server 2003/2003R2/2008/2008R2,
Windows® Vista, Windows® 7
Mac OS X 10.3 - 10.6
Network protocols TCP/IP (IPv4, IPv6), IPP, Bonjour
Printing protocols LPR, Raw TCP (port 9100), FTP, IPP
PDL emulation Std PCL5c/6, PS3
Available fonts PCL/PS 80
NETWORK SCANNER
Scan method Push scan (via operation panel)
Pull scan (TWAIN-complaint application)
Resolution (dpi)
Platen Cover 1200 x 1200
Single Pass Feeder 600 x 600
File formats TIFF, PDF, JPEG (colour only)
Scanner utilities Presto! Page Manager
Scan destinations Scan to e-mail, FTP server, network folder (SMB),
FACSIMILE
USB memory
Compression method MH/MR/MMR/JBIG
Communication protocol Super G3
Transmission time*
5
(seconds)
Less than 3
Modem speed (bps) 33,600 – 2,400 with automatic fallback
Transmission resolution (dpi)
Std 200 x 100
Ultra Fine 200 x 200
Recording width A4 – A6
Memory (MB) 2
Specifications
*1: At rated voltage. May vary depending on machine conditions and operating environment.
*2: Best achieved time based on A4, 600 x 600 dpi. May vary depending on machine conditions and
operating environment. *3: Best achieved time based on A4, at 25
o
C. May vary depending on machine
conditions and operating environment. *4: Resolutions higher than 600 dpi are interpolated.
*5: Based on 8 x 3.85 line/mm, 33.6 kbps, MMR, ITUT#1 chart.
• Design and specifications are subject to change without prior notice. • Colour variations to products may
occur due to printing. • Some features require optional items. Please consult with an authorised Sharp
reseller for details. • All information and technical details are correct as at machine release date.
• Windows and Windows Vista are registered trademarks of Microsoft Corporation in the United States
and/or other countries. • All other brand names and product names may be trademarks or registered
trademarks of their respective owners.
• The ENERGY STAR logo is a certification mark and may only be used to certify products that have been
determined to meet the ENERGY STAR programme requirements. ENERGY STAR is a US registered mark.
The ENERGY STAR guidelines apply to products only in the US, the EU, Japan, Canada, Australia, New
Zealand and Taiwan.
