Sharp EL-2607PG User Manual

7
INK RIBBON REPLACEMENT
1. Remove the paper roll from the calculator.
(Tear the paper and remove it from the print
mechanism by using .)
2. Turn the power off before replacing ribbon.
3. Remove the printer cover. (Fig. 1)
4. Remove the old ribbon by pulling it up.
5. Insert the new ribbon.
6. With the black side of the ribbon facing
upwards, place one of the reels on the reel
shaft on the right. (Fig. 2) Make sure that the
reel is securely in place.
7. Thread the ribbon around the outside of the
metal guides. (Fig. 3)
8. Ta ke up any slack by manually turning one of
the reels.
9. Replace the printer cover. (Fig. 4)
10. Replace the paper roll.
Fig. 2
Fig. 3
Fig. 4
Fig. 1
5EL-2607PPG(AXO)-Eng2 12.8.10, 11:22 AMPage 7 AdobePageMaker6.5J/PPC

Sharp EL-2607PG Specifications

General

Type	Printing
Form factor	Desktop
Product color	Black, White
Digits	12 digits

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	221 x 327 x 78 mm
