Overview
Page / 1
Designs and specifications are subject to change without notice.
The ER-A450T model ECR provides support for loading image data that may be used as an graphics
logo for the header or footer of a receipt. The data must meet the specifications defined within this
document which will outline the attributes necessary for loading the image data.
1. Types of functions supported:
(1) Sending picture file (*.bmp or *.pcx) data to the ECR ....................... Pc to ER-A450T
ER02FD to ER-A450T
(2) Converting Image Logo data for use with the ER-02FD .................... at the PC
2. Functions Supported:
(1) Changes the Image Logo for use on the ER-A450T on customer receipts and reports.
(2) Creates an Image Logo data file.
(3) Can load the Image Logo data to the ER-02FD Floppy Drive unit
(for detailed information about the ER-02FD floppy disk unit, please refer to the applicable service manual)
3. Format Specifications:
(1) File format: *.PCX or *.BMP
(2) Size: 288 dots (w) x 140 dots (h)
(3) Color: Monochrome only (black & white)
FUNCTIONS OVERVIEW
