[JOB#2320]
MEDIA KEY PROGRAMMING
XXX: Function No.
Function
No.
Function A B C D E F G
42 CA1
43 CA2
44 CHK1
45 CHK2
46 CHK3
47 CHK4
48 CR1
49 CR2
50 CR3
51 CR4
Items marked with ( ) are programmable.
A: EFT function A
Non compulsory 0
Compulsory 1
B: Footer print B
No 0
Yes 1
C: Non-add code entry C
Non compulsory 0
Compulsory 1
D: Change due D
Enable 0
Disable 1
E (For ER-A440): VP E
Non compulsory 0
Compulsory 1
E (For ER-A450): Not used (Fixed at "0")
F: Drawer opening F
Yes 0
No 1
G: Entry of amount tendered G
Non compulsory (Cash, Check)
Inhibit (CR1 to CR4)
0
Compulsory 1
MRS=0000000
[JOB#2321]
MEDIA KEY FUNCTION PROGRAM (AMOUNT HALO)
XXX: Function No.
YYYYYYYYY: Limitation amount
Func.
No.
Function Entry range MRS
59
62
41
CID (Sentinel)
CHK CHANGE
CA/CHK
0 to 999999999
0 to 99999999
0 to 99999999
999999999
99999999
99999999
[JOB#2324]
CURRENCY DESCRIPTER
XXX: Function No.
Function No. Function Remarks
52 Exchange 1
53 Exchange 2
54 Exchange 3
55 Exchange 4
Character can be entered by using character keys or numeric keys.
The key entry sequence for entering one character by numeric keys
is as follows:
XXX
→ 00 KEY XXX: Character code (3 digits)
Please refer to section 4.
MRS = "space"
This symbol is printed with (+) amount of foreign currency. The pro-
grammed characters is printed at left side of amout.
Ex) Case of "DM":
EXCH1 1.234567
DM 1.23
Programmed symbol
If some space characters are programmed at the left side of symbol
(like "
"), they are not counted as the number of character of the
currency symbol. (In case of " DM", the number of character is 2.)
Ex) Case of " DM": (The currency symbol means "DM")
[JOB#1400]
CLERK CODE DIFINITION
XX: Clerk No.= 1
∼ 99
YY: Clerk code = 00
∼ 99
MRS = No record (It is set same code as clerk No. when a clerk file
is created.)
2320 XXX ABCDEFG
No change
ST TL
2321 XXX
YYYYYYYY
No change
ST TL
2324 XXX Character key
No change
ST TL
(4 chara.)Function No.
1400 XX YY
No change
ST TL
2 – 14
