PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
GX-CD1200W
– 1 –
INTEGRATED CIRCUITS
IC1 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC2 VHILA1805//-1 J AM FM/AM IF MPX.,LA1805
IC101 VHITA8189N/-1 J AM Record/Playback Amp.,TA8189N
IC151 VHITA2011S/-1 J AM Mic Amp.,TA2011S
IC201 VHIBA3822LS-1 J AL Graphic Equalizer,BA3822LS
IC202,203 VHILB1403N/-1 J AG Level Meter Driver,LB1403N
IC401 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC402 VHILA4663//-1 J AQ Power Amp.,LA4663
IC501,502 VHIKA7809AP-1 J Voltage Regulator,KA7809AP
IC801 VHITA2109F/-1 J AL Servo Pre Amp.,TA2109F
IC802 VHITC9457F0-1 J AZ Servo/Signal Control,TC9457F0
IC803 VHILA6541D/-1 J AW Focus/Tracking/Spin/Sled Driver,
LA6541D
TRANSISTORS
Q153 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q154 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q156 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q181,182 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q301 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q403,404 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q502,503 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q504 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q505 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q601 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q602 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q603 VSKTD2058Y/-1 J AF Silicon,NPN,KTD2058 Y
Q801 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q802 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q803,804 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
DIODES
D1,2 VHDDS1SS133-1 J AB Silicon,DS1SS133
D152 VHDDS1SS133-1 J AB Silicon,DS1SS133
D154 VHDDS1SS133-1 J AB Silicon,DS1SS133
D156 VHDDS1SS133-1 J AB Silicon,DS1SS133
D158 VHDDS1SS133-1 J AB Silicon,DS1SS133
D162~165 VHDDS1SS133-1 J AB Silicon,DS1SS133
! D651 VHDTS4B03GM-1 J AK Silicon,TS4B03GM
DZ601 VHEDZ8R2BSB-1 J AB Zener,8.2V,DZ8.2BSB
LED1 VHP333ID213-1 J LED,RED,333ID213
LED253~260 VHP333ID213-1 J LED,RED,333ID213
LED401 VHP333ID213-1 J LED,RED,333ID213
LED501,502 VHP333ID213-1 J LED,RED,333ID213
FILTERS
CF1 RFILR0008AWZZ J AE FM Band Pass Filter
CF2 92LFILTF1342A J AD FM IF,10.7 MHz
CF3 RFILA0001BGZZ J AC AM IF,455 kHz
TRANSFORMER
! T601 RTRNP0001BGZZ J AX Power
COILS
L1 RCILB0001BGZZ J AD FM Oscillation
L2 RCILR0001BGZZ J AA FM Tracking
L3,4 RCILA0001BGZZ J AH MW/SW1 Bar Antenna
L5 RCILA0003BGZZ J AC SW2 Antenna
L6 RCILB0002BGZZ J AC MW Oscillation
L7 RCILB0003BGZZ J AC SW1 Oscillation
L8 RCILB0004BGZZ J AC SW2 Oscillation
L9 RCILI0002BGZZ J AD FM IF
L10 RCILI0003BGZZ J AD FM Detection
L11 RCILI0001BGZZ J AD AM IF
L103,104 VP-MK223K0000 J AC 22 mH,Choke
L301 RCILB0005BGZZ J AD Bias Oscillation
L501 VP-MK470K0000 J AB 47 µH,Choke
L801 VP-DHR82K0000 J AE 0.82 µH,Choke
L802,803 VP-DH100K0000 J AB 10 µH,Choke
VARIABLE RESISTORS
VR1 RVR-M0026AWZZ J AC 10 kohm (B),Semi-VR [VCO]
VR102 RVR-M0018AWZZ J AC 470 ohms (B),Semi-VR
[Tape Speed]
VR202 RVR-Q0002BGZZ J AE 50 kohms (B)×2 [X-BASS]
VR203~205 RVR-Q0001BGZZ J AC 100 kohm (B)×2
[Graphic Equalizer]
VR401 RVR-B0002BGZZ J 50 kohms (B)×2 [VOLUME]
VARIABLE CAPACITORS
TC5,6 RTO-H1003SJZZ J AG Trimmer,5 pF
TC7,8 RTO-H1001BGZZ J AD Trimmer,10 pF
TC9 RVC-Z0001BGZZ J AF Fine Tuning
VC1~4 RVC-R0001BGZZ J AK Variable Capacitance with
Trimmer (TC1~4)
VIBRATOR
XL801 RCRM-0008AWZZ J AF Ceramic,16.93 MHz
CAPACITORS
C2 VCCCPU1HH5R0J J AA 5 pF (CH),50V
C4 VCCCPU1HH240J J AA 24 pF (CH),50V
C5 VCKYPA1HB102K J AA 0.001 µF,50V
C6,7 VCKYPA1HB472K J AB 0.0047 µF,50V
C8,9 VCKZPA1HF223Z J AA 0.022 µF,50V
C10 VCCCPU1HH150J J AA 15 pF (CH),50V
C11 VCCCPU1HH220J J AA 22 pF (CH),50V
C12 VCCCPU1HH3R0J J AA 3 pF (CH),50V
C13 VCKZPA1HF223Z J AA 0.022 µF,50V
C14 VCCCPU1HH5R0J J AA 5 pF (CH),50V
C15 VCKZPA1HF223Z J AA 0.022 µF,50V
C17 VCKZPA1HF223Z J AA 0.022 µF,50V
C18 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C19 VCKYPA1HB331K J AA 330 pF,50V
C20 VCKYPA1HB222K J AA 0.0022 µF,50V
C21 VCCUPA1HJ5R0C J AA 5 pF (UJ),50V
C22 VCKZPA1HF223Z J AA 0.022 µF,50V
C23 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C24~26 VCKZPA1HF223Z J AA 0.022 µF,50V
C27 VCKYPA1HB472K J AB 0.0047 µF,50V
C29 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C30 VCKZPA1HF223Z J AA 0.022 µF,50V
C31 VCQYKA1HM472K J AB 0.0047 µF,50V,Mylar
C32 VCQYKA1HM822K J AA 0.0082 µF,50V,Mylar
C33 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C34 VCKYPA1HB471K J AA 470 pF,50V
C35 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C36 92LCPU100V1500 J AC 0.0015 µF,100V
C37,38 VCQYKA1HM123K J AA 0.012 µF,50V,Mylar
C39~41 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C42 VCKZPA1HF223Z J AA 0.022 µF,50V
C43 VCKYPA1HB221K J AA 220 pF,50V
C101,102 VCKYPA1HB471K J AA 470 pF,50V
C103,104 VCKYPA1HB471K J AA 470 pF,50V
C105~108 VCKYPA1HB331K J AA 330 pF,50V
C109,110 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C111,112 VCQYKA1HM153K J AB 0.015 µF,50V,Mylar
C113~116 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C117,118 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C119,120 VCQYKA1HM333K J AB 0.033 µF,50V,Mylar
C121,122 VCKYPA1HB331K J AA 330 pF,50V
C123,124 VCKYPA1HB103K J AA 0.01 µF,50V
C125,126 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C127 RC-GZA337AF1A J AB 330 µF,10V,Electrolytic
C128 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C129 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C131,132 VCKYPA1HB121K J AA 120 pF,50V
C133,134 VCKYPA1HB151K J AA 150 pF,50V
C137,138 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
C151 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C152 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C154 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C155 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C156 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C157 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C158,159 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C160 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C180 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C181,182 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C183,184 VCKYPA1HB221K J AA 220 pF,50V
C185,186 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C200 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C201,202 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
To Next Page
