Sharp GX-CD1200W BK User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
GX-CD1200W
C203,204 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C205,206 VCQYKA1HM103K J AA 0.01 µF,50V,Mylar
C207,208 VCKYPA1HB471K J AA 470 pF,50V
C209,210 VCQYKA1HM823K J AC 0.082 µF,50V,Mylar
C211,212 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
C213,214 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C215,216 VCQYKA1HM562K J AA 0.0056 µF,50V,Mylar
C217,218 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C219,220 VCQYKA1HM393K J AB 0.039 µF,50V,Mylar
C221,222 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C251,252 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C253,254 VCKZPA1HF223Z J AA 0.022 µF,50V
C255,256 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C257 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C259,260 VCQYKA1HM392K J AA 0.0039 µF,50V,Mylar
C301 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C302 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C303 VCQYKA1HM562K J AA 0.0056 µF,50V,Mylar
C304 VCKZPA1HF223Z J AA 0.022 µF,50V
C305 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
C306 VCKYPA1HB391K J AA 390 pF,50V
C307 VCKYPA1HB151K J AA 150 pF,50V
C401,402 VCQYKA1HM682K J AA 0.0068 µF,50V,Mylar
C403,404 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C405,406 VCQYKA1HM332K J AA 0.0033 µF,50V,Mylar
C407,408 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C409,410 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C411 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C412 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C413,414 VCQYKA1HM102K J AA 0.001 µF,50V,Mylar
C415,416 VCQYKA1HM154K J AB 0.15 µF,50V,Mylar
C418 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C419,420 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C423 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C424 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C425~428 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C429,430 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C433 VCKZPA1HF223Z J AA 0.022 µF,50V
C505 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C506 VCKZPA1HF223Z J AA 0.022 µF,50V
C508 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C509 VCKZPA1HF223Z J AA 0.022 µF,50V
C510 RC-GZG338AF1E J 3300 µF,25V,Electrolytic
C511 VCKZPA1HF223Z J AA 0.022 µF,50V
C513,514 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C601 VCKZPA1HF223Z J AA 0.022 µF,50V
C602 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C603 VCKZPA1HF223Z J AA 0.022 µF,50V
C604 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C651~654 VCKZPA1HF223Z J AA 0.022 µF,50V
C801 VCQYKA1HM103K J AA 0.01 µF,50V,Mylar
[To Serial No.00404990 Only]
C802 VCKZPA1HF223Z J AA 0.022 µF,50V
C804 VCCCPA1HH2R0C J AA 2 pF (CH),50V
C805 VCKZPA1HF223Z J AA 0.022 µF,50V
C806 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C807 VCKZPA1HF473Z J AA 0.047 µF,50V
C813 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C814 VCKZPA1HF473Z J AA 0.047 µF,50V
C815 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C816 VCKZPA1HF223Z J AA 0.022 µF,50V
C817 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C818 VCCSPA1HL560J J AA 56 pF,50V
C819,820 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C821 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C822 VCKZPA1HF473Z J AA 0.047 µF,50V
C823 VCKZPA1HF223Z J AA 0.022 µF,50V
C824 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C825 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C826 VCCSPA1HL470J J AA 47 pF,50V
C827 VCQYKA1HM153K J AB 0.015 µF,50V,Mylar
C828 VCKYPA1HB272K J AA 0.0027 µF,50V
C829 VCKYPA1HB472K J AB 0.0047 µF,50V
C830 VCQYKA1HM103K J AA 0.01 µF,50V,Mylar
C832 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C833 VCQYKA1HM333K J AB 0.033 µF,50V,Mylar
C834,835 VCKYPA1HB471K J AA 470 pF,50V
C836~839 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C840~842 VCKZPA1HF473K J AA 0.047 µF,50V
C843 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C844 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C845 VCKZPA1HF473Z J AA 0.047 µF,50V
C846 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C847 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C848 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C849,850 VCKYPA1HB121K J AA 120 pF,50V
C851,852 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C853 VCKZPA1HF223Z J AA 0.022 µF,50V
C854 VCKYPA1HB682K J AB 0.0068 µF,50V
C855 VCKZPA1HF223Z J AA 0.022 µF,50V
C858 VCKZPA1HF223J J 0.022 µF,50V
C859 VCKYPA1HB272K J AA 0.0027 µF,50V
C860 VCKYPA1HB152K J AA 0.0015 µF,50V
C863 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C893 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C894 VCKZPA1HF223Z J AA 0.022 µF,50V
RESISTORS
R1 VRD-ST2EE100J J AA 10 ohm,1/4W
R2 VRD-ST2CD330J J AA 33 ohms,1/6W
R3 VRD-ST2CD470J J AA 47 ohms,1/6W
R4 VRD-ST2CD334J J AA 330 kohms,1/6W
R5 VRD-ST2CD101J J AA 100 ohm,1/6W
R7 VRD-ST2CD824J J AA 820 kohms,1/6W
R8 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R9 VRD-ST2CD123J J AA 12 kohms,1/6W
R10,11 VRD-ST2EE470J J AA 47 ohms,1/4W
R12 VRD-ST2CD102J J AA 1 kohm,1/6W
R13 VRD-ST2EE101J J AA 100 ohm,1/4W
R14 VRD-ST2CD104J J AA 100 kohm,1/6W
R15,16 VRD-ST2CD103J J AA 10 kohm,1/6W
R17,18 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R19 VRD-ST2CD153J J AA 15 kohms,1/6W
R20 VRD-ST2EE100J J AA 10 ohm,1/4W
R100 VRD-ST2EE151J J AA 150 ohms,1/4W
R101,102 VRD-ST2CD101J J AA 100 ohm,1/6W
R105,106 VRD-ST2CD184J J AA 180 kohms,1/6W
R107,108 VRD-ST2CD103J J AA 10 kohm,1/6W
R109,110 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R111,112 VRD-ST2CD223J J AA 22 kohms,1/6W
R113,114 VRD-ST2CD124J J AA 120 kohms,1/6W
R115,116 VRD-ST2CD681J J AA 680 ohms,1/6W
R117,118 VRD-ST2CD334J J AA 330 kohms,1/6W
R119,120 VRD-ST2CD101J J AA 100 ohm,1/6W
R121~124 VRD-ST2CD103J J AA 10 kohm,1/6W
R127,128 VRD-ST2CD223J J AA 22 kohms,1/6W
R129,130 VRD-ST2CD154J J AA 150 kohms,1/6W
R131,132 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R133,134 VRD-ST2CD823J J AA 82 kohms,1/6W
R135,136 VRD-ST2CD103J J AA 10 kohm,1/6W
R151 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R152 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R153 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R154 VRD-ST2CD561J J AA 560 ohms,1/6W
R161 VRD-ST2CD105J J AA 1 Mohm,1/6W
R165 VRD-ST2CD103J J AA 10 kohm,1/6W
R166 VRD-ST2EE561J J AA 560 ohms,1/4W
R168,169 VRD-ST2CD103J J AA 10 kohm,1/6W
R170,171 VRD-ST2CD333J J AA 33 kohms,1/6W
R172,173 VRD-ST2CD103J J AA 10 kohm,1/6W
R174 VRD-ST2CD223J J AA 22 kohms,1/6W
R177 VRD-ST2CD102J J AA 1 kohm,1/6W
R180 VRD-ST2EE561J J AA 560 ohms,1/4W
R181,182 VRD-ST2CD102J J AA 1 kohm,1/6W
R183,184 VRD-ST2CD334J J AA 330 kohms,1/6W
R185,186 VRD-ST2CD221J J AA 220 ohms,1/6W
R187,188 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R200 VRD-ST2EE331J J AA 330 ohms,1/4W
R201,202 VRD-ST2CD102J J AA 1 kohm,1/6W
R203,204 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R205 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R206 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R207 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R208 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R211,212 VRD-ST2CD102J J AA 1 kohm,1/6W
R251,252 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R253,254 VRD-ST2CD393J J AA 39 kohms,1/6W
R255,256 VRD-ST2EE121J J AA 120 ohms,1/4W
R257,258 VRD-ST2CD103J J AA 10 kohm,1/6W
R259,260 VRD-ST2EE121J J AA 120 ohms,1/4W
R301 VRD-ST2EE331J J AA 330 ohms,1/4W
R302,303 VRD-ST2EE101J J AA 100 ohm,1/4W
R304 VRD-ST2EE100J J AA 10 ohm,1/4W
– 2 –
