Sharp GX-CD1200W BK User Manual

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
GX-CD1200W
R305 VRD-ST2EE273J J AA 27 kohms,1/4W
R306 VRD-ST2EE470J J AA 47 ohms,1/4W
R351,352 VRD-ST2CD473J J AA 47 kohms,1/6W
R353,354 VRD-ST2CD273J J AA 27 kohms,1/6W
R401,402 VRD-ST2CD104J J AA 100 kohm,1/6W
R403,404 VRD-ST2CD103J J AA 10 kohm,1/6W
R405,406 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R407~410 VRD-ST2CD123J J AA 12 kohms,1/6W
R411 VRD-ST2EE331J J AA 330 ohms,1/4W
R412,413 VRD-ST2CD103J J AA 10 kohm,1/6W
R415,416 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R417,418 VRD-ST2CD223J J AA 22 kohms,1/6W
R419,420 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R425,426 VRD-ST2CD102J J AA 1 kohm,1/6W
R427,428 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R429 VRD-ST2CD104J J AA 100 kohm,1/6W
R431 VRD-ST2CD273J J AA 27 kohms,1/6W
R433~436 VRD-ST2CD2R2J J AA 2.2 ohms,1/6W
R437,438 VRD-ST2EE121J J AA 120 ohms,1/4W
R440 VRD-ST2EE471J J AA 470 ohms,1/4W
R441,442 VRD-ST2CD153J J AA 15 kohms,1/6W
R511~513 VRD-ST2CD103J J AA 10 kohm,1/6W
R514 VRD-ST2CD104J J AA 100 kohm,1/6W
R515 VRD-ST2CD121J J AA 120 ohms,1/6W
R516 VRD-ST2CD302J J AA 3.6 kohms,1/6W
R518,519 VRD-ST2CD102J J AA 1 kohm,1/6W
R520,521 VRD-ST2CD103J J AA 10 kohm,1/6W
R601 VRD-ST2EE271J J AA 270 ohms,1/4W
R602 VRD-ST2EE101J J AA 100 ohm,1/4W
R801 VRD-ST2EE220J J AA 22 ohms,1/4W
R802 VRD-ST2CD222J J AA 2.2 kohms,1/6W
[To Serial No.00404990 Only]
R803 VRD-ST2CD823J J AA 82 kohms,1/6W
R804 VRD-ST2CD683J J AA 68 kohms,1/6W
R805 VRD-ST2CD393J J AA 39 kohms,1/6W
R806 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R807 VRD-ST2CD102J J AA 1 kohm,1/6W
R811 VRD-ST2CD223J J AA 22 kohms,1/6W
R812 VRD-ST2CD102J J AA 1 kohm,1/6W
R820 VRD-ST2CD473J J AA 47 kohms,1/6W
R821,822 VRD-ST2CD223J J AA 22 kohms,1/6W
R824 VRD-ST2CD103J J AA 10 kohm,1/6W
R826 VRD-ST2CD224J J AA 220 kohms,1/6W
R827 VRD-ST2CD153J J AA 15 kohms,1/6W
R828 VRD-ST2CD103J J AA 10 kohm,1/6W
R829 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R830 VRD-ST2CD103J J AA 10 kohm,1/6W
R831~834 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R835,836 VRD-ST2CD153J J AA 15 kohms,1/6W
R839 VRD-ST2CD473J J AA 47 kohms,1/6W
R840 VRD-ST2EE100J J AA 10 ohm,1/4W
R844 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R846 VRD-ST2CD331J J AA 330 ohms,1/6W
R847 VRD-ST2CD102J J AA 1 kohm,1/6W
R848 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R849 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R851~853 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R857,858 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R861 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R863 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R865 VRD-ST2CD102J J AA 1 kohm,1/6W
R891 VRD-ST2CD683J J AA 68 kohms,1/6W
[From Serial No.00504991]
R892 VRD-ST2CD563J J AA 56 kohms,1/6W
[From Serial No.00504991]
R893~895 VRD-ST2CD683J J AA 68 kohms,1/6W
[From Serial No.00504991]
R896 VRD-ST2CD563J J AA 56 kohms,1/6W
[From Serial No.00504991]
OTHER CIRCUITRY PARTS
BI801/CNS801 QCNWN0026BGZZ J Connector Ass’y,8/8Pin
BI802/CNS802 QCNWN0027BGZZ J Connector Ass’y,5/5Pin
[To Serial No.00404990]
BI802/CNS802 QCNWN0032BGZZ J Connector Ass’y,7/7Pin
[From Serial No.00504991]
BI803/CNS803 QCNWN0028BGZZ J Connector Ass’y,6/6Pin
BI804/CNS804 QCNWN0031BGZZ J Connector Ass’y,6/6Pin
CNP101 QCNCM705CAFZZ J AA Plug,3Pin
CNP102 QCNCM705DAFZZ J AB Plug,4Pin
CNP103 QCNCM698JAFZZ J AC Plug,9Pin
CNP501 QTANA0001BGZZ J AD Terminal,Speaker
CNP601 QCNCM035BAWZZ J AB Plug,2Pin
CNP803 92LCONE6P53254 J AC Plug,6Pin
CNP804 QCNCM705FAFZZ J AB Plug,6Pin
CNS101 QCNWN0001BGZZ J AD Connector Ass’y,3Pin
CNS102 QCNWN0002BGZZ J AE Connector Ass’y,4Pin
CNS103 QCNWN0003BGZZ J AF Connector Ass’y,9Pin
CNS601 QCNWN0006BGZZ J AD Connector Ass’y,2Pin
! F601 QFS-D402ABGNI J AC T4A L 250V
FW1 QCNWN0038BGZZ J Flat Wire,4Pin
FW2 QCNWN0014BGZZ J AA Flat Wire,2Pin
FW801 QCNWN0030AFZZ J AG Flat Wire,10Pin
FW802 QCNWN0029AFZZ J Flat Wire,2Pin
J151 QJAKA0004BGZZ J Jack,Mic
J401 QJAKM0001BGZZ J AE Jack,Headphones
LCD801 RV-LX0001BGZZ J LCD Display
M501(300-10) 92L1959123012 J Motor with Pulley [Tape]
M801 92LMMTR1651B J AL Motor with Chassis [Sled]
M802 92LMMTR1854A J AP Motor with Gear [Spindle]
MIC151 RMICC0001BGZZ J AF Built-in Microphone
! SO601 QSOCA0006SJZZ J AB AC Socket
SP401,402 VSP0012PBG28A J Speaker,Woofer
SP403,404 RALMB0001BGZZ J AC Speaker,Tweeter
SW1 QSW-S9001BGZZ J AE Switch,Slide Type
[Band Selector]
SW101 QSW-S9002BGZZ J AD Switch,Slide Type
[Record/Playback]
SW102 QSW-S9003BGZZ J AC Switch,Slide Type [Beat Cancel]
SW103 QSW-S9004BGZZ J AC Switch,Slide Type [Dubbing
Speed/Mic/FM Mode]
SW401 QSW-P9001BGZZ J AE Switch,Push Type [Surround]
SW501 QSW-S9005BGZZ J AD Switch,Slide Type
[Function Selector]
! SW601 QSW-S0004SJZZ J AK Switch,Slide Type
[Voltage Selector]
SW702 QSWF9001AW01 J Switch,Push Type [Pickup In]
SW801 QSW-K0008AWZZ J AC Switch,Key Type [Play/Pause]
SW801 92LSWICHT1663 J AC Switch,Key Type [Play/Pause]
SW802 QSW-K0008AWZZ J AC Switch,Key Type [Stop]
SW803 QSW-K0008AWZZ J AC Switch,Key Type [Cue/Track Up]
SW804 QSW-K0008AWZZ J AC Switch,Key Type
[Review/Track Down]
SW810 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW901(300-12) 92L640101149 J Switch,Leaf Type [Tape 1 Main]
SW902(300-11) 92L640101149 J Switch,Leaf Type [Tape 2 Main]
SW903(300-13) 92L640101149 J Switch,Leaf Type [Tape 2 Play]
SW904(300-14) 92L64030204 J Switch,Slide Type
[Tape 2 Direction]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LMCUSN1524A J AD Cushion
! 306 92LHPC1LASY J Pickup Unit Ass’y
[To Serial No.00404990]
! 306 92LHPC1LXASY J BD Pickup Unit Ass’y
[From Serial No.00504991]
307 PCOVP1001AWSA J AE Cover,CD Mechanism
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M801 92LMMTR1651B J AL Motor with Chassis [Sled]
M802 92LMMTR1854A J AP Motor with Gear [Spindle]
SW702 QSWF9001AW01 J Switch,Push Type [Pickup In]
CABINET PARTS
201 GCABA1003BGSA J Front Cabinet [GL]
201 GCABA1003BGSB J Front Cabinet [BK]
202 GFTAC0001BGSB J AK Cassette Holder [Tape 1] [BK]
202 GFTAC0001BGSC J Cassette Holder [Tape 1] [GL]
203 GFTAC0002BGSB J AK Cassette Holder [Tape 2] [BK]
203 GFTAC0002BGSC J Cassette Holder [Tape 2] [GL]
204 HBDGA1003BGSA J Badge,SHARP
205 HBDGS1001BGSA J AF Sheet,Surround Sound System
206 HDECQ0001BGSA J AH Panel,Display
207 HDECQ0004BGSA J AD Ring,Volume Knob
208 HDECQ0017BGSA J Panel,Cassette Holder [Tape 1]
– 3 –
