GX-CD5100W
–2
[6] NAMES OF PARTS
Top
Controls and indicators
Front panel
1. Disc Compartment
1. Tape 1 Cassette Compartment
2. Built in Microphone
3. Headphone Socket
4. Tuning Down Button
5. Tuning Up Button
6. Line In Button
7. On/Stand by Button
8. Tuner (Band) Button
9. Tape (1 2) Button
10. Timer Indicator
11. CD/MP3 disc Track Down or Fast Reverse Button
12. CD/MP3 Disc Play or Repeat Button
13. CD/MP3 Button
14. CD/MP3 Disc/Stop Button
15. CD/MP3 disc Track Up or Fast Forward Button
16. Remote Sensor
17. Volume Control
18. Simba Mode/Demo Button
19. Mixing Microphone Socket
20. Tape 2 Cassette Compartment
21. Tape 1 Play Button
22. Tape 1 Stop Button
23. Tape 1 Rewind Button
24. Tape 1 Fast Forward Button
25. Tape Continuous Playback Button
26. Tape High Speed Dubbing Button
27. Tape 2 Reverse Play Button
28. Tape 2 Forward Play Button
29. Tape 2 Stop Button
30. Tape 2 Fast Wind Buttons
31. Tape 2 Record Pause Button
1
1
2
3
4
5
6
7
8
9
10
11 12 13 14 15 16 17
18
19
20
21 22 23 24 25 26 27 28 29 30 31
PUSH
OPEN/CLOSE
1 – 4
