Sharp GX-CD5100W Service Manual

GX-CD5100W
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
C907 VCQYKA1HM104K AB 0.1µF,50V,Mylar
C908 VCEAZA1CW107M AC 100µF,16V,Electrolytic
CV701 VCKYCY1HB104K AA 0.1µF,50V
CV702 VCEAZA1HW106M AB 10µF,50V,Electrolytic
[9] RESISTORS
C392 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP2 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP3 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP4 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP7 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP8 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP13 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP15 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP16 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP300 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP301 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP302 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP303 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP304 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP305 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP306 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP307 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP308 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP309 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP310 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP311 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP312 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP701 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP702 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP703 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP704 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP705 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP706 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP707 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP803 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
JP804 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
R1 VRD-ST2CD102J AA 1 kohms,1/6W
R4 VRD-ST2CD102J AA 1 kohms,1/6W
R7 VRS-CY1JB470J AA 47 ohms,1/16W
R8 VRS-CY1JB100J AA 10 ohms,1/16W
R9 VRD-ST2CD102J AA 1 kohms,1/6W
R16 VRS-CY1JB331J AA 330 kohms,1/16W
R18 VRS-CY1JB1R0J AA 1 ohms,1/16W
R19 VRD-ST2CD682J AA 6.8 kohms,1/6W
R20 VRD-ST2CD123J AA 12 kohms,1/6W
R21 VRD-ST2CD103J AA 10 kohms,1/6W
R22 VRD-ST2CD682J AA 6.8 kohms,1/6W
R23 VRD-ST2CD681J AA 680 ohms,1/6W
R24 VRD-ST2CD681J AA 680 ohms,1/6W
R25 VRD-ST2CD683J AA 68 kohms,1/6W
R26 VRD-ST2CD102J AA 1 kohms,1/6W
R27 VRD-ST2CD820J AA 82 ohms,1/6W
R28 VRS-CY1JB472J AA 4.7 kohms,1/16W
R29 VRD-ST2CD1R0J AA 1 ohms,1/6W
R30 VRS-CY1JB271J AA 270 ohms,1/16W
R31 VRS-CY1JB681J AA 680 ohms,1/16W
R32 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
R33 VRS-CY1JB102J AA 1 kohms,1/16W
R34 VRS-CY1JB102J AA 1 kohms,1/16W
R35 VRD-ST2CD102J AA 1 kohms,1/6W
R36 VRS-CY1JB102J AA 1 kohms,1/16W
R37 VRS-CY1JB102J AA 1 kohms,1/16W
R38 VRS-CY1JB102J AA 1 kohms,1/16W
R39 VRS-CY1JB102J AA 1 kohms,1/16W
R43 VRS-CY1JB220J AA 22 ohms,1/16W
R44 VRS-CY1JB332J AA 3.3 kohms,1/16W
R45 VRS-CY1JB151J AA 150 ohms,1/16W
R46 VRS-CY1JB223J AA 22 kohms,1/16W
R47 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm,Green
R48 VRS-CY1JB101J AA 100 ohms,1/16W
R49 VRS-CY1JB101J AA 100 ohms,1/16W
R52 VRS-CY1JB820J AA 82 ohms,1/16W
R53 VRD-ST2EE1R0J AA 1 ohms,1/4W
R54 VRD-ST2EE1R0J AA 1 ohms,1/4W
R63 VRS-CY1JB182J AA 1.8 kohms,1/16W
R64 VRS-CY1JB392J AA 3.9 kohms,1/16W
R65 VRS-CY1JB182J AA 1.8 kohms,1/16W
R66 VRD-ST2CD392J AA 3.9 kohms,1/6W
R67 VRS-CY1JB225J AA 2.2 Mohms,1/16W
R69 VRS-CY1JB392J AA 3.9 kohms,1/16W
R70 VRS-CY1JB182J AA 1.8 kohms,1/16W
