Sharp GX-CD5100W Service Manual

GX-CD5100W
12
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
RA715 VRS-CY1JB103J AA 10 kohms,1/16W
RV701 VRD-ST2CD101J AA 100 ohms,1/6W
RV702 VRD-ST2CD101J AA 100 ohms,1/6W
RV703 VRS-CY1JB101J AA 100 ohms,1/16W
[10] OTHER CIRCUITRY PARTS
BI501 QCNWNA638AWPZ AE Connector Assy,2/2Pin with CNS501
BI502A/B QCNWNA674AWPZ AE Connector Assy,2/2Pin with BI502A/BI502B
BI504A/B QCNWNA494AWPZ AD Connector Assy,2/2Pin with BI504A/BI504B
BI603 QCNWNA654AWPZ AG Connector Assy,8/7Pin with CNS603
BI703 QCNWNA632AWPZ AF Connector Assy,6/5Pin with CNS703
BI706 QCNWNA656AWPZ AG Connector Assy,8/7Pin with CNS706
BI701 QCNWNA635AWPZ AH Connector Assy,9/8Pin with CNS701
BI709 QCNWNA659AWPZ AE Connector Assy,2/2Pin
BI714 QCNWNA652AWPZ AH Connector Assy,10/10Pin with CNS714
BI715 QCNWNA634AWPZ AG Connector Assy,10/9Pin with CNS711
BI803 QCNWNA631AWPZ AK Connector Assy,8/7Pin with CNS803
BI903 QCNWNA630AWPZ AF Connector Assy,5/5Pin with CNS903
CNP1 QCNCWYP16AWZZ AD Socket,16Pin
CNP2 QCNCM705FAFZZ AB Plug,6Pin
CNP3 92LCONE7P53254 AB Plug,7Pin
CNP7 QCNCWZY08AWZZ AC Socket,8Pin
CNP101 QCNCM705CAWZZ AA Plug,3Pin
CNP102 QCNCM705GAWZZ AB Plug,7Pin
CNP103 QCNCWZX12AWZZ AC Socket,12Pin
CNP104 92LCONE8P53253 AC Plug,8Pin
CNP105 92LCONE9P53253 AC Plug,9Pin
CNP201 92LCONE2P53253 AB Plug,2Pin
CNP301 92LCONE2P5268 AB Plug,2Pin
CNP602 92LCONEAP53253 AC Plug,10Pin
CNP702 92LCONE3P53254 AB Plug,3Pin
CNP708 QCNCWZY08AWZZ AC Socket,8Pin
CNP801 92LCONE5P5267X AB Plug,5Pin
CNP802 92LCONE5P53253 AB Plug,5Pin
CNP804 92LCONE7P53253 AC Plug,7Pin
CNP805 92LCONE7P53254 AB Plug,7Pin
CNP806 QCNCW010GAWZZ AC Plug,7Pin
!
CNP901 QCNCM050BAWZZ AC Plug,2Pin
CNP902 92LCONE2P5267X AB Plug,2Pin
!
CNP904 QCNCM049CAWZZ AC Plug,3Pin
CNS102A QCNWNA636AWPZ AM Connector Assy,8/6Pin with CNS102B
CNS2A QCNWNA607AWPZ AF Connector Assy,6/6Pin with CNS2B
!
F901 QFS-D402ABGNi AC Fuse,4A,250V
FFC103 QCNWNA637AWPZ AD Flat Cable,12 Pin
FFC1 QCNWNA672AWPZ AD Flat Cable,16Pin
FFC708 QCNWNA653AWPZ AD Flat Cable,8Pin
JK201 QJAKM0004AWZZ AK Jack,Headphones
JK801 QJAKM0004AWZZ AK Jack,Headphones
LCD701 RV-LXA004AWZZ AZ LCD Display
LUG1 QCNWNA074AWPZ AC Lug Wire
MIC201 RMICCA002AWZZ AF Mic In
RMC701 VHLK2013TH2E1 AG Remote Sensor
SO401 QSOCJ0220AWZZ AD Jack,AUX
SO801 QTANA0424AWZZ AE Terminal,Speaker
!
SO901 QSOCAA001AWZZ AG Socket,Power
!
SO902 QSOCE0004AWZZ AF Socket,Voltage Selector
!
SO903 QJAKCA003AWZZ AD Socket,DC Voltage Input
SW101 QSW-SA004AWZZ AD Span Selector
SW501 92LSWICHT1663T AC Tape High Speed Dubbing
SW502 92LSWICHT1663T AC Tape Continous Playback
SW503 92LSWICHT1663T AC Tape 1 Fast Forward
SW504 92LSWICHT1663T AC Tape 1 Rewind
SW505 92LSWICHT1663T AC Tape 1 Stop
SW506 92LSWICHT1663T AC Tape 1 Play
SW507 92LSWICHT1663T AC Tape 2 REC Pause
SW508 92LSWICHT1663T AC Tape 2 Fast Forward
SW509 92LSWICHT1663T AC Tape 2 Fast Rewind
SW510 92LSWICHT1663T AC Tape 2 Stop
SW511 92LSWICHT1663T AC Tape 2 Forward Play
SW512 92LSWICHT1663T AC Tape 2 Reverse Play
SW513 92LSWICHT1663T AC Power On / Standby
SW702 92LSWICHT1663T AC CD Play
SW703 92LSWICHT1663T AC CD / Line
SW704 92LSWICHT1663T AC Tape ( 1 2 )
SW705 92LSWICHT1663T AC Tuner ( Band )
SW706 92LSWICHT1663T AC Tuning Down
SW707 92LSWICHT1663T AC Tuning Up
SW708 92LSWICHT1663T AC CD
SW709 92LSWICHT1663T AC CD Fast Rewind
SW710 92LSWICHT1663T AC CD Stop
SW711 92LSWICHT1663T AC Simba Mode / Demo
SW712 92LSWICHT1663T AC CD Fast Forward
SW800 QSW-K9006SJZZ AG Switch, LID OPEN
VR101 RVR-MA001AWZZ AC Tape Speed Variable
VR301 RVR-M0026AWZZ AC FM Mute Level Variable
VR701 QSW-ZA001AWZZ AE Switch,Jog[Type],Volume
[9] RESISTORS
