Sharp GX-CD5100W Service Manual

GX-CD5100W
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[11] CABINET PARTS
201 CCABA6532AW01 BC Front Cabinet Assembly
201-1 ------------- -- Front Cabinet (Not Replacement Item)
201-2 HBDGBA004AWSA AC Badge, SHARP
201-3 HDECQA279AWSA AF Decoration, Volume
201-4 HDECQA280AWSA AF Decoration, Ring
201-5 HDECQA285AWSA AF Decoration, Center
201-6 HPNLHA003AWSB AK Panel, Display
201-7 JKNBZA193AWSA AF Knob, Power
201-8 JKNBZA194AWSA AF Knob, Function
201-9 JKNBZA195AWSA AF Knob, Operation A
201-10 JKNBZA196AWSA AG Knob, Operation B
201-11 JKNBZA197AWSA AF Knob, Tuning
201-12 JKNBZA198AWSA AF Knob, SIMBA
201-13 JKNBZA199AWSA AC Holder, SIMBA Knob
201-14 LANGKA094AWFW AC Bracket, Front Cabinet
201-15 MLOKC0014AWZZ AC Lock, Cassette [Tape 1]
201-16 MLOKC0015AWZZ AC Lock, Cassette [Tape 2]
201-17 MSPRD0196AWFJ AB Spring, Cassette Lock [Tape 1]
201-18 MSPRD0197AWFJ AC Spring, Cassette Lock [Tape 2]
201-19 PSHEZA105AWZZ AB Sheet, SIMBA Knob
201-20 JKNBZA200AWSA AF Knob, CD Function
201-21 JKNBZA201AWSA AG Knob, CD Play/Stop
202 92LCSPR1431C AA Spring, Ring
!
203 92LFSHOLD1652T AQ Holder, Fuse
204 GCABBA062AWSA AX Back Cabinet
205 GCABCA064AWSA AM Top Cabinet (CD)
206 GCOVAA147AWSA AN Cover, Cassette [Tape 1]
207 GCOVAA148AWSA AN Cover, Cassette [Tape 2]
208 GDORFA013AWSA AF Holder, Cassette [Tape 1]
209 GDORFA014AWSA AF Holder, Cassette [Tape 2]
210 GFTABA010AWSA AF Cover, Battery
211 GFTABA011AWSA AC Cover, Flash
212 HDECQA282AWSA AD Panel, Edge Light
213 HDECQA283AWSA AE Panel, Cassette [Tape 1]
214 HDECQA284AWSA AE Panel, Cassette [Tape 2]
215 JHNDPA003AWSA AH Handle
216 JKNBKA023AWSA AL Knob, Volume
217 KMECBA010AWZZ BD Tape Mechanism Assembly
218 LBND-1011AWZZ AA Nylon Band
219 LHLDZA133AWZZ AD Holder, LCD
220 LPLTMA009AWFW AC Plate, Battery ( + / - )
221 LPLTMA010AWFW AC Plate, Battery ( + )
222 LPLTMA011AWFW AC Plate, Battery ( - )
223 MLiF-A001AWZZ AD Damper, Cassette
224 MSPRCA013AWFJ AC Spring, Battery A ( + / - )
225 MSPRCA014AWFJ AC Spring, Battery B ( + / - )
226 MSPRCA015AWFJ AC Spring, Battery B ( - )
227 MSPRDA032AWFJ AC Spring, Rod Antenna
228 MSPRDA033AWFJ AC Spring, Cassette Up [Tape 1]
229 MSPRDA034AWFJ AC Spring, Cassette Up [Tape 2]
230 MSPRDA037AWFJ AC Spring, Wire Dressing
231 PCUSG0022AWZZ AB Cushion, Foot
232 PFLT-A067AWZZ AA Felt
233 PRDARA120AWFW AP Heat Sink, Main
234 PRDARA118AWFW AG Heat Sink, Sub
235 PRDARA119AWFW AG Heat Sink, Sub
236 PSHEPA062AWZZ AE Sheet, LCD Diffusion
237 PSLDMA070AWZZ AD Plate, Mecha Shield
238 PSLDMA071AWZZ AK Plate, PT Shield
239 QANTR0007AWSA AM Rod Antenna
240 TSPC-A605AWZZ AD Label, Specification ( For Australia/New Zealand )
240 TSPC-A606AWZZ AD Label, Specification ( Except Australia/New Zealand )
241 ------------- -- Nut (Not Replacement Item)
242 ------------- -- Washer (Not Replacement Item)
243 92LMCUSN1524A AD Cushion, CD
244 GCOVAA146AWSA AD Cover, CD
245 GCOVDA004AWSA AC Cover, Dust
246 GDORTA004AWSA AL Door, CD
247 KMECZA002AWZZ AZ CD Mechanism Assembly
248 LHLDMA008AWSA AE Stabilizer
249 MLiF-A002AWZZ AD Damper, CD
250 MSPRDA029AWFJ AC Spring, CD Up (A)
251 MSPRDA036AWFJ AC Spring, CD Up
252 PCUSG0001AWSA AD Cushion, CD
253 PCUSG0004AWSA AD Cushion, CD
254 PMAGF0007AWZZ AD Magnet, Stabilizer
255 TLABS0354AWZZ AC Label, caution
256 JKNBZA202AWSA AG Knob, CD FF/REW
601 LX-EZ0005AWF7 AB Screw, Special, M2.6x10mm
602 LX-EZ0010AWF7 AB Screw, Special
603 LX-JZ0010AFF7 AB Screw, Special
604 LX-JZ0022AFF7 AB Screw, Special
605 XEBSN30P30000 AB Screw, M3x30mm
606 XEBY726P10000 AA Screw, M2.6x10mm
607 XEBY730P08000 AA Screw, M3x8mm
608 XEBY730P10000 AA Screw, M3x10mm
609 XEBY830P10000 AB Screw, M3x10mm
610 XEBY830P12000 AB Screw, M3x12mm
