GX-CD5100W
17
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[12] SPEAKER BOX PARTS
901 GCAB-A043AW01 AW Front Cabinet Assembly, Left
902 GCAB-A044AW01 AW Front Cabinet Assembly, Right
903 GCAB-A041AWSA AW Rear Cabinet, Left
904 GCAB-A042AWSA AW Rear Cabinet, Right
905 LBSHCA004AWSA AF Holder, Speaker Cord
906 PCUSG0022AWZZ AD Cushion, Foot
907 PFLT-A066AWZZ AA Felt
908 QCNWNA620AWPZ AF Speaker Cord, Woofer
909 QCNWNA676AWPZ AF Speaker Cord, Tweeter
910 XEBY730P08000 AA Screw, M3x8mm
911 XEPY740P12000 AB Screw, M4x12mm
912 XEPY740P16000 AB Screw, M4x16mm
SP 1,2 RSP-ZA195AWZZ AY Woofer
SP 3,4 RSP-ZA196AWZZ AR Tweeter
[13] ACCESSORIES / PACKING PARTS
1 ------------- -- Battery ( Not Replacement Item )
!
2 QACCEA002AW00 AL AC Power Supply Cord ( Except Australia/New Zealand )
!
2 QACCLA002AW00 AQ AC Power Supply Cord ( For Australia/New Zealand )
3 QANTL0005AWZZ AG AM Loop Antenna
4 RRMCGA094AWSA AR Remote Control
5 SPAKAA127AWZZ AM Packing Add., Unit, Top
6 SPAKAA129AWZZ AM Packing Add., Unit, Bottom
7 SPAKCA372AWZZ AV Packing Case ( For Australia/New Zealand )
7 SPAKCA374AWZZ AT Packing Case ( Except Australia/New Zealand )
8 SSAKAA008AWZZ AB Polyethylene Bag, Accessories
9 SPAKP0026AWZZ AB Polyethylene Bag, AC Cord ( For Australia/New Zealand only )
10 SSAKHA014AWZZ AD Polyethylene Bag, Unit
11 SSAKHA081AWZZ AC Polyethylene Bag, Speaker
12 TiNSZA195AWZZ AE Operation Manual ( For Australia/New Zealand )
12 TiNSZA196AWZZ AM Operation Manual ( Except Australia/New Zealand )
13 TLABZA360AWZZ AE Label, Pop ( Left )
14 TLABZA369AWZZ AE Label, Pop ( Right )
15 SPAKZA353AWZZ AF Packing Add., AC Cord ( For Australia/New Zealand only )
[14] P.W.B. ASSEMBLY (Not Replacement Item)
!
PWB-A 92LPWB6532MANS --
Main (A1) / Display (A2) / Power Key (A3)
Power Supply (A4) / Head Phone (A5) /
Tape 1 Knob (A6) / Tape 2 Knob (A7) /
Flash (A8)
PWB-B -------------- -- Tape Mechanism (PWB Only) (B1) / (B2)
PWB-C 92LPWB653
2CDUS -- CD Servo
