NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
HT-DP4000
R583,584 VRS-TV2AB223J J AA 22 kohms,1/10W
R585,586 VRS-TV2AB102J J AA 1 kohm,1/10W
R587,588 VRS-TV2AB392J J AA 3.9 kohms,1/10W
R589,590 VRS-TV2AB273J J AA 27 kohms,1/10W
R591,592 VRS-TV2AB101J J AA 100 ohm,1/10W
R594 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R596 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R598 VRS-TV2AB102J J AA 1 kohm,1/10W
R600 VRS-TV2AB102J J AA 1 kohm,1/10W
! R601 RR-HZ0001AWZZ J AE 4.7 Mohms,1/2W
R603 VRD-ST2EE122J J AA 1.2 kohms,1/4W
R604 VRD-ST2EE470J J AA 47 ohms,1/4W
R607 VRD-ST2EE332J J AA 3.3 kohms,1/4W
R608 VRD-ST2EE473J J AA 47 kohms,1/4W
R610 VHHXE030///-1 J Thermistor,Positive/Negative C
R611,612 VRD-ST2EE1R0J J AA 1 ohm,1/4W
R613 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R614 VRD-ST2EE101J J AA 100 ohm,1/4W
R615 VRD-ST2EE123J J AA 12 kohms,1/4W
R616,617 VRD-ST2EE221J J AA 220 ohms,1/4W
R620 VRD-ST2EE561J J AA 560 ohms,1/4W
R621 VRD-ST2EE102J J AA 1 kohm,1/4W
R622 VRD-ST2EE470J J AA 47 ohms,1/4W
R623 VRS-PT3DA561J J 560 ohms,2W,Metal Oxide Film
R624 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R626 VRS-TV2AB103J J AA 10 kohm,1/10W
R627 VRS-TV2AB183J J AA 18 kohms,1/10W
R701,702 VRD-ST2EE102J J AA 1 kohm,1/4W
R703,704 VRS-TV2AB103J J AA 10 kohm,1/10W
R705,706 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R707,708 VRS-TV2AB102J J AA 1 kohm,1/10W
R709,710 VRS-TV2AB473J J AA 47 kohms,1/10W
R713,714 VRS-PT3AA0R2J J 0.2 ohms,1W,Metal Oxide Film
R715,716 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R717,718 VRD-ST2EE682J J AA 6.8 kohms,1/4W
R719 VRS-TV2AB183J J AA 18 kohms,1/10W
R720 VRS-TV2AB123J J AA 12 kohms,1/10W
R721 VRS-TV2AB393J J AA 39 kohms,1/10W
R724 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R725~728 VRD-RT2HD220J J AA 22 ohms,1/2W
R729,730 VRS-TV2AB563J J AA 56 kohms,1/10W
R731 VRS-TV2AB103J J AA 10 kohm,1/10W
R733,734 VRD-RT2HD4R7J J AA 4.7 ohms,1/2W
R741 VRD-ST2EE102J J AA 1 kohm,1/4W
R742 VRS-TV2AB563J J AA 56 kohms,1/10W
R743 VRS-TV2AB221J J AA 220 ohms,1/10W
R744 VRS-TV2AB102J J AA 1 kohm,1/10W
R745 VRS-TV2AB473J J AA 47 kohms,1/10W
R747 VRS-PT3AA0R2J J 0.2 ohms,1W,Metal Oxide Film
R748 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R749 VRD-ST2EE682J J AA 6.8 kohms,1/4W
R751 VRS-TV2AB393J J AA 39 kohms,1/10W
R752 VRS-TV2AB273J J AA 27 kohms,1/10W
R753 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R754 VRS-TV2AB104J J AA 100 kohm,1/10W
R756,757 VRD-RT2HD220J J AA 22 ohms,1/2W
R758 VRD-ST2CD563J J AA 56 kohms,1/6W
R760 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R761 VRD-ST2EE102J J AA 1 kohm,1/4W
R762 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R763 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R764 VRS-TV2AB102J J AA 1 kohm,1/10W
R765 VRS-TV2AB473J J AA 47 kohms,1/10W
R767 VRS-PT3AA0R2J J 0.2 ohms,1W,Metal Oxide Film
R768 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R769 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R771 VRS-TV2AB393J J AA 39 kohms,1/10W
R772 VRS-TV2AB273J J AA 27 kohms,1/10W
R773 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R774 VRS-TV2AB104J J AA 100 kohm,1/10W
R776,777 VRD-RT2HD220J J AA 22 ohms,1/2W
R778 VRD-ST2CD563J J AA 56 kohms,1/6W
R780 VRD-ST2HD4R7J J AA 4.7 ohms,1/2W
R781 VRD-ST2EE102J J AA 1 kohm,1/4W
R782 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R783 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R784 VRS-TV2AB102J J AA 1 kohm,1/10W
R785 VRS-TV2AB473J J AA 47 kohms,1/10W
R787 VRS-PT3AA0R2J J 0.2 ohms,1W,Metal Oxide Film
R788 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R789 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R791 VRS-TV2AB393J J AA 39 kohms,1/10W
R792 VRS-TV2AB273J J AA 27 kohms,1/10W
R793 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R794 VRS-TV2AB104J J AA 100 kohm,1/10W
R795 VRD-ST2HD4R7J J AA 4.7 ohms,1/2W
R796,797 VRD-RT2HD220J J AA 22 ohms,1/2W
R798 VRD-ST2CD563J J AA 56 kohms,1/6W
OTHER CIRCUITRY PARTS
CNP1A QCNCWZF23//ZZ J Socket,23Pin
CNP3 QCNCM999BAFZZ J AD Plug,2Pin
CNP4 QCNCM998HAFZZ J AH Plug,8Pin
CNP5 QCNCM999CAFZZ J AG Plug,3Pin
CNP201 QCNCM010MAFZZ J AC Socket,12Pin
CNP581 QCNCM999EAFZZ J AG Plug,5Pin
! CNP601 QCNCM036BAWZZ J AC Plug,2Pin
CNP602 QCNCM998G//// J Plug,7Pin
CNP603 QCNCM998E//// J Plug,5Pin
CNP702 QCNWNM998B/// J Plug,2Pin
CNS1B QCNCWZG23AWZZ J AK Plug,23Pin
CNS201 QCNCW010MAWZZ J AD Plug,12Pin
CNW1 QCNWN0032SJZZ J AL Flat Cable,23Pin
CNW3/BI3 QCNWN0038SJZZ J AK Connector Ass’y,4/4Pin
CNW4/BI4 QCNWN0036SJZZ J AN Connector Ass’y,8/8Pin
CNW5/BI5 QCNWN0031SJZZ J AK Connector Ass’y,3/3Pin
CNW202 QCNWN0135SJZZ J Lug Wire
CNW581/BI581 QCNWN0037SJZZ J AM Connector Ass’y,5/5Pin
! CNW601/BI601 QCNWN0035SJZZ J AN Connector Ass’y,2/2Pin
CNW602/BI602 QCNWN0030SJZZ J AP Connector Ass’y,7/7Pin
CNW603/BI603 QCNWN0034SJZZ J AK Connector Ass’y,5/5Pin
CNW702/BI702 QCNWN0155SJZZ J AC Connector Ass’y,2/2Pin
! F601 QFS-D402BSJNI J AB Fuse,4A/125V
! F611 QFS-D801BSJNI J AG Fuse,800mA
FL1 VVKET211GK/-1 J FL Display
J202 VRS-TV2AB153J J AA 15 kohms,1/10W
J581 QJAKJ0001SJZZ J AM Jack,Headphones
JK401 QJAKZ0001SJZZ J AP Jack,Audio Input/Output
! RLY601 RRLYD0001SJZZ J AQ Relay
RX1 VHLN64H380A-1 J AK Remote Sensor,N64H380A
SO701 QCNCM772HAFZZ J AN Socket,Front/Center/Sub
Speakers
SO702 QCNCM772DAFZZ J AD Socket,Surround Speaker
SOC201 QTANC0301AWZZ J AH Terminal,Antenna
SW1 QSW-P0002SJZZ J AH Switch,Push Type [POWER]
SW2 QSW-K0005AWZZ J AC Switch,Key Type
[TIMER/SLEEP]
SW3 QSW-K0005AWZZ J AC Switch,Push Type
[DOLBY PROLOGIC]
SW4 QSW-K0005AWZZ J AC Switch,Push Type [EQALIZER]
SW5 QSW-K0005AWZZ J AC Switch,Push Type [X-BASS]
SW6 QSW-K0005AWZZ J AC Switch,Push Type [ENTER]
SW7 QSW-K0005AWZZ J AC Switch,Push Type
[VOLUME DOWN]
SW8 QSW-K0005AWZZ J AC Switch,Push Type [VOLUME UP]
SW9 QSW-K0005AWZZ J AC Switch,Push Type
[MEMORY/SET]
SW10 QSW-K0005AWZZ J AC Switch,Push Type [TUNING UP]
SW11 QSW-K0005AWZZ J AC Switch,Push Type
[TUNING DOWN]
SW12 QSW-K0005AWZZ J AC Switch,Push Type
[TUNER/BAND]
SW13 QSW-K0005AWZZ J AC Switch,Push Type [CD/AUX]
SW14 QSW-K0005AWZZ J AC Switch,Push Type [VCR-2]
SW15 QSW-K0005AWZZ J AC Switch,Push Type [VCR-1]
SW23 QSW-Z0003AWZZ J AH Switch,Push Type [JOG]
CABINET PARTS
201 GCAB-3004SJSA J BB Top Cabinet
203 GITAR0027SJSA J AM Rear Panel
204 LANGK0004SJFW J AF Bracket,Tuner PWB A
205 LANGK0005SJFW J AE Bracket,Tuner PWB B
206 GLEGP0001SJSA J AF Leg
207 LCHSM0001SJFW J AZ Main Chassis
208 LANGK0018SJFW J AC Bracket,Heat Sink A
209 JKNBZ0022SJSA J AK Button,Function
210 JKNBZ0008SJSA J AF Button,Enter
211 JKNBK0009SJSA J AG Knob,Volume
212 CPNLC1043SJZZ J Front Panel Ass’y
212- 1 ———— — Front Panel
(Not Replacement Item)
212- 2 HBDGA1002SJSA J AF Badge,SHARP
212- 3 HDECB0001SJSA J AE Decoration,Leg
212- 4 PCUSG0001SJZZ J AD Leg Cushion
– 4 –
