HT-DP4000
– 8 –
Screw
Driver
(A1)x1
(A2)x4
ø4x13mm
(A2)x2
ø4x13mm
Screw
Driver
(A1)x1
(A2)x4
ø4x13mm
Screw
Driver
(A1)x1
(A2)x4
ø4x13mm
Screw
Driver
(A1)x1
(A2)x4
ø4x13mm
Figure 8-2
CP-F4000 CP-C4000
CP-SR4000
CP-SW4000
Figure 8-4
Figure 8-1 Figure 8-3
