AIN_R
(8202A only)
189 A ADC input (right channel)
GPIO
(8202A-256 only)
189 Input/Output GPIO
VM
(8202A only)
190 A ADC input voltage reference. When not used, connect a 0.1uF to ground.
GPIO
(8202A-256 only)
190 Input/Output GPIO
VDD_ADA
(8202A only)
191 S 3.3V power supply pin for on-chip audio ADC
VDD_O9
(8202A-256 only)
191 S I/O power supply pins #9
VDD_ADA
(8202A only)
192 S Ground pin for on-chip audio ADC
VSS_O8/VSS_K8
(8202A-256 only)
192 S Chip kernel logic and output shared ground pin #9
GPIO 193 Input/Output GPIO
GPIO 194 Input/Output GPIO
Symbol Pin # Input/Output Description
Priority selection Function Dir
gpio_first[6][7] = 1 GPIO[103]
Input/Output
sft_cfg13[3:0] = 4'b1111 IEC_RX Input
sft_cfg13[8:4] = 5'b11101 ADC_DATA Input
sft_cfg13[14:12] = 3'b111 AT_D[8] Input/Output
sft_cfg4[15:13] = 3'b100 TV_HSYNC_PC Output
sft_cfg11[5:3] = 3'b111 TS_FRAME_B Input/Output
sft_cfg11[11:9] = 3'b010 TV_LCD_G_EXT[0] Output
(other) GPIO[103] (default) Input/Output
Priority selection Function Dir
gpio_first[6][8] = 1 GPIO[104]
Input/Output
sft_cfg13[8:4] = 5'b11110 ADC_DATA Input
sft_cfg13[14:12] = 3'b111 AT_D[7] Input/Output
sft_cfg4[15:13] = 3'b100 TV_VSYNC_PC Output
sft_cfg4[15:13] = 3'b100 TV_HSYNC_PC Output
sft_cfg11[5:3] = 3'b111 TS_GNT_B Input/Output
sft_cfg11[11:9] = 3'b010 TV_LCD_G_EXT[1] Output
(other) GPIO[104] (default) Input/Output
Priority selection Function Dir
gpio_first[3][2] = 1 GPIO[50]
Input/Output
sft_cfg13[8:4] = 5'b10001 ADC_DATA Input
sft_cfg1[8:6] = 3'b101 FL_MEM_CSALL_B Output
sft_cfg14[12:11] = 1 TV_SRGB_DEN Output
sft_cfg2[9:8] = 1 FL_PCMCIA_WAIT_B Input
sft_cfg7[11:8] = 4'b0011 VGA_CLK Input
sft_cfg11[11:9] = 3'b010 TV_LCD_B_EXT[0] Output
sfg_cfg15[15:12] = 4'b0001 FM_GPIOB[7] Input/Output
sft_cfg7[15:14] = 2 CLK27_OUT Output
sft_cfg7[13:12] = 2 CLK54_OUT Output
sft_cfg18[5:4] = 2 CLK48_OUT Output
sft_cfg18[7:6] = 2 CLK108_OUT Output
(other) GPIO[50] (default) Input/Output
Priority selection Function Dir
gpio_first[3][3] = 1 GPIO[51] Input/Output
sft_cfg13[3:0] = 4'b0001 IEC_RX Input
sft_cfg11[11:9] = 3'b010 TV_LCD_B_EXT[1] Output
(other) GPIO[51] (default) Input/Output
