HT-DV40H
8 – 43
47 ROPIN Output Rch Feedback Resistor Input Pin. 0.5 x AVDD1.
48 RISEL Output Rch Feedback Resistor Output Pin
49 AVSS1 — ADC Ground Pin, 0V
50 AVDD1 — ADC Power Supply Pin, 4.5V~5.5V
51 LIN1 Input Lch Input 1 Pin
52 RIN1 Input Rch Input 1 Pin
53 LIN2 Input Lch Input 2 Pin
54 RIN2 Input Rch Input 2 Pin
55 LIN3 Input Lch Input 3 Pin
56 RIN3 Input Rch Input 3 Pin
57 LIN4 Input Lch Input 4 Pin
58 RIN4 Input Rch Input 4 Pin
59 LIN5 Input Lch Input 5 Pin
60 RIN5 Input Rch Input 5 Pin
61 LIN6 Input Lch Input 6 Pin
62 RIN6 Input Rch Input 6 Pin
63 PVSS — PLL Ground pin
64 R —
External Resistor Pin
12kΩ +/-1% resistor should be connected to PVSS externally.
Note: All input pins except internal biased pin (RX0) and analog input pins (LIN1-6, RIN1-6) should not be left floating.
No. Pin Name Input / Output Function
