HT-DV40H
6 – 43
Figure 6-40: WIRING SIDE OF SCART, VIDEO OUT, DIGITAL IN PWB (BOTTOM VIEW)
SCART PWB-B3
VIDEO OUT PWB-B4 DIGITAL IN PWB-B5
A
B
C
D
E
F
G
H
1
23456
Lead-free solder indication
Lead-free solder is used in the SCART, VIDEO OUT, DIGITAL IN PWB.
Refer to "Precautions for handling lead-free solder" for instructions
and precautions.
To Next Page
