Sharp HT-M700H - Page 94

HT-M700H
16
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[12] OTHER CIRCUITRY PARTS
CFW301 QCNWNA483SJZZ N Connector Ass'y,1Pin
CFW501 QCNWNA470SJZZ N Connector Ass'y,1Pin
CFW701 QCNWNA471SJZZ N Connector Ass'y,1Pin
CNP301 QCNCM004DAFZZ AD Plug,4Pin
CNP302 QCNCM004KAFZZ N Plug,10Pin
CNP305 QCNWNA472SJZZ N Connector Ass'y,3Pin
CNP505 QCNCM999BAFZZ AD Plug,2Pin
CNP505 QCNWNA473SJZZ N Connector Ass'y 2/2Pin with JP6
CNP508 QCNCM004CAFZZ AB Plug,3Pin
CNP601 QCNWNA423SJZZ N Connector Ass'y,2Pin
CNP801 QCNCM004DAFZZ AD Plug,4Pin
CNP901 QCNCM004BAFZZ AB Plug,2Pin
CNP903 QCNCM004CAFZZ AB Plug,3Pin
CNP904 QCNCM004HAFZZ N Plug,8Pin
CNW1A QCNWNA441SJZZ N Connector Ass'y,11/11Pin with CNW1B
CNW2A QCNWNA444SJZZ N Connector Ass'y,3/3Pin with CNW2B
CNW3A QCNWNA443SJZZ N Connector Ass'y,13/13Pin with CNW3B
CNW6A QCNWNA442SJZZ N Connector Ass'y,12/12Pin with CNW6B
CNW303A QCNWNA426SJZZ N Connector Ass'y,4/4Pin with CNW303B
CNW504 QCNWNA446SJZZ N Connector Ass'y,3/3Pin with CNS504
CNW505A QCNWNA425SJZZ N Connector Ass'y,8/8Pin with CNW505B
CNW506 QCNWNA447SJZZ N Connector Ass'y,4/4Pin with CNS506
CNW508 QCNWNA421SJZZ N Connector Ass'y,3/3Pin with CNS508
CNW601 QCNWNA420SJZZ N Connector Ass'y,3/3Pin with CNS601
CNW701 QCNWNA413SJZZ N Connector Ass'y,10/10Pin with CNS701
CNW702 QCNWNA417SJZZ N Connector Ass'y,4/4Pin with CNS702
CNW703 QCNWNA418SJZZ N Connector Ass'y,4/4Pin with CNS703
CNW704 QCNWNA414SJZZ N Connector Ass'y,9/9Pin with CNS704
CNW705 QCNWNA415SJZZ N Connector Ass'y,8/8Pin with CNS705
CNW706 QCNWNA416SJZZ N Connector Ass'y,7/7Pin with CNS706
CNW707 QCNWNA419SJZZ N Connector Ass'y,3/3Pin with CNS707
CNW708 QCNCM004FAFZZ AC Plug,6Pin
CNW901 QCNWNA422SJZZ N Connector Ass'y,2/2Pin with CNS901
!
F1 QFS-D332CAWNI N Fuse,T3.15A L 250V
FFC1 QCNWNA445SJZZ N Flat Cable,24Pin
!
FR VHHVSR808//-1 N Resistor
J1 QCNCMA064SJ03 N Plug,3Pin
J2 QTANAA009SJZZ N Terminal,Speaker
J3 QCNWM999PAFZZ N Plug,13Pin
J4 QCNWM999CAFZZ N Plug,3Pin
J5 QCNWM999DAFZZ N Plug,4Pin
JJ1 QCNCWA055SJ24 N Socket,24Pin
JK501 QJAKMA002SJZZ AE Jack,Headphones
JP1A QCNWM999LAFZZ N Plug,11Pin
JP1B QCNWM999MAFZZ N Plug,12Pin
JP2A QCNWM999DAFZZ N Plug,4Pin
JP2B QCNWMA0655J03 N Plug,3Pin
JP3A QCNWM999NAFZZ N Plug,13Pin
JP3B QCNWM999JAFZZ N Plug,9Pin
JP4A QCNWM999HAFZZ N Plug,8Pin
JP4B QCNWM999BAFZZ N Plug,2Pin
JP5 QCNWM999CAFZZ N Plug,3Pin
JP6A QCNWM999MAFZZ N Plug,12Pin
JP6B QCNWM999BAFZZ N Plug,2Pin
JP7 QCNWM999GAFZZ N Plug,8Pin
JR1 QCNWM999DAFZZ N Plug,4Pin
JR2 QCNWM999CAFZZ N Plug,3Pin
M601 RMOTV0409AFZZ AL Door Motor
P1 QSOCJ0003SJZZ AG Jack,AUX IN
P2 QSOCJ0002SJZZ AH Jack,Video/S-Video
!
PJ1 QCNWMA061SJ02 N Plug,2Pin
!
RLY RRLYD0004SJZZ AG Relay
S501 QSOCZA001SJZZ AE Socket,SCART Out
SO301 QTANAA007SJZZ N Terminal,FM Antenna
SO302 QTANAA008SJZZ N Terminal,AM Antenna
SW501 QSW-K0002SJZZ AC Switch,Key Type [OPEN/CLOSE]
SW601 QSW-B0002SJZZ AE Switch,Lever Type [Door]
SW701 QSW-K0002SJZZ AC Switch,Key Type [PLAY]
SW702 QSW-K0002SJZZ AC Switch,Key Type [STOP]
SW703 QSW-K0002SJZZ AC Switch,Key Type [DISC TRAY OPEN/CLOSE]
SW705 QSW-K0002SJZZ AC Switch,Key Type [TUNER (BAND)]
SW706 QSW-K0002SJZZ AC Switch,Key Type [FUNCTION]
SW707 QSW-K0002SJZZ AC Switch,Key Type [SKIP UP]
SW708 QSW-K0002SJZZ AC Switch,Key Type [SKIP DOWN]
SW709 QSW-ZA002SJZZ AF Jog Volume
SW801 QSW-K0002SJZZ AC Switch,Key Type [ON/STAND-BY]
U14 VHPBFTX1001-1 AK Terminal,Audio Digital Output
U801 VHLGP1UD261-1 AK Remote Sensor,GP1UD261
VFD701 VVK42-1002F-1 N FL Display
