4
Accessories
• 1x Remote control
• 1x User manual
• 1x UK power cord
• 1x EU power cord
• 2x Wall Bracket
• 1x Set of wall-mounting screws
• 1x Quick start guide
• 2 x AAA battery
Controls
1
3
2
1
1. Remote Control Sensor
2. LED Indicators
•
Red indicator: In STANDBY mode.
•
Green indicator: In AUX mode.
•
Orange indicator: In Optical mode.
•
Blue indicator: In Bluetooth mode.
••
White indicator: In HDMI ARC
mode.
3. Wall bracket screws
4.
button
Switch the unit between ON and
STANDBY mode.
5.
button
Select the play function.
6.
button
Select the Bluetooth mode. Press and
hold to activate the pairing function
in Bluetooth mode or disconnect the
existing paired Bluetooth device.
7. +/- buttons
Increase/decrease the volume level.
Inputs/Outputs
1. AC~ Socket
Connect power cord.
2. OPTICAL Socket
Opticial input jack.
3. SERVICE ONLY Socket
The USB socket is for service only. It is
not designed to charge smartphones,
tablets or similar devices.
4. AUX 1 Socket
Connect to an external audio device.
5. HDMI ARC Socket
Connect to a TV via HDMI cable.
4 5 6 7
1 2 3 4 51
