Sharp HT-X1H - Subwoofer;Amplifier Unit Specifications

HT-X1H
17
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[12] OTHER CIRCUITRY PARTS
BI203 QCNWNA193SJZZ AE Connector Ass'y,2/2Pin with CNS203
BI205 QCNWNA196SJZZ AD Connector Ass'y,3Pin
BI302 QCNWNA187SJZZ AF Connector Ass'y,10/10Pin with CNS302
BI401 QCNWNA194SJZZ AK Connector Ass'y,11/10Pin with CNS401
BI402 QCNWNA195SJZZ AK Connector Ass'y,15/5/9Pin with CNS402B/402A
BI501 QCNWNA188SJZZ AK Connector Ass'y,9/9Pin with CNS501
BI502 QCNWNA189SJZZ AH Connector Ass'y,7/7Pin with CNS502
BI503 QCNWNA190SJZZ AK Connector Ass'y,10/10Pin with CNS503
BI506 QCNWNA191SJZZ AG Connector Ass'y,5/5Pin with CNS506
CFW1 QCNWNA230SJZZ AB Connector Ass'y,1Pin
CFW2 QCNWNA229SJZZ AC Connector Ass'y,1Pin
CFW3 QCNWNA231SJZZ AB Connector Ass'y,1Pin
CFW4 QCNWNA227SJZZ AC Connector Ass'y,1Pin
CFW5 QCNWNA227SJZZ AC Connector Ass'y,1Pin
CFW6 QCNWNA228SJZZ AC Connector Ass'y,1Pin
CFW9 QCNWNA228SJZZ AC Connector Ass'y,1Pin
CNP201 QCNCM017BSJZZ AD Plug,3Pin
CNP202 QCNCM017CSJZZ AC Plug,3Pin
CNP203 QCNCM017BSJZZ AD Plug,3Pin
CNP204 QCNCM998DAFZZ AB Plug,4Pin
CNP205 QCNCM004DSJZZ AB Plug,3Pin
CNP206 QCNCM052CSJZZ AB Plug,2Pin
CNP301 QCNCM004DSJZZ AB Plug,4Pin
CNP302 QCNCM004KSJZZ AC Plug,10Pin
CNP401 QCNCM998NAFZZ AG Plug,13Pin
CNP402
A
QCNCM999EAFZZ AG Plug,5Pin
CNP402
B
QCNCM999JAFZZ AC Plug,9Pin
CNP609 QCNCM004FSJZZ Plug,6Pin
CNP702 QCNCM004MSJZZ AC Plug,12Pin
CNP704 QCNCM004NSJZZ AC Plug,13Pin
CNP705 QCNCMA013SJ07 AC Plug,7Pin
CNP706 QCNCMA032SJZZ AC Plug,7Pin
CNP707 QCNCM004BSJZZ AB Plug,2Pin
CNW301 QCNWNA197SJZZ AE Connector Ass'y,4/4Pin
CNW508
A
QCNWNA192SJZZ AF Connector Ass'y,12/12Pin with CNW508B
CNW609 QCNWNA198SJZZ AE Connector Ass'y,6/6Pin
CNW702 QCNWNA212SJZZ AG Connector Ass'y,12/12Pin
CNW703 QCNWNA232SJZZ AE Connector Ass'y,7/7Pin
CNW704 QCNWNA213SJZZ AG Connector Ass'y,13/13Pin
CNW705 QCNWNA199SJZZ AE Connector Ass'y,7/7Pin
CNW707 QCNWNA200SJZZ AC Connector Ass'y,2/2Pin
!
F101 QFS-D632CAWNI AC Fuse,T6.3A L 250V
!
F102 QFS-D632CAWNI AC Fuse,T6.3A L 250V
!
F201 QFS-D202CAWNI AC Fuse,T2A L 250V
JK1 QJAKMA002SJZZ AE Jack,Headphones
M401 RMOTV0409AFZZ AL Fan Motor
M402 RMOTV0409AFZZ AL Fan Motor
RLY400 RRLYD0004SJZZ AG Relay
RLY401 RRLYD0014AWZZ AK Relay
RLY402 RRLYD0014AWZZ AK Relay
RLY403 RRLYD0014AWZZ AK Relay
RX701 VHLGP1UD261-1 AK Remote Sensor,GP1UD261
RX702 VHLGP1UD261-1 AK Remote Sensor,GP1UD261
S0202 QSOCA0212AWZZ AD Socket AC Input
S101A QCNCWA030SJZZ AG Socket,System Cable 1
S101B QCNCWA030SJZZ AG Socket,System Cable 2
S102A QCNCWA028SJZZ AG Socket,System Cable 1
S102B QCNCWA028SJZZ AG Socket,System Cable 2
S501 QSOCJA005SJZZ AE Jack,Video Out
S503 VHPBFRX1001-1 AM Optical IN
S504 QSOCJ0003SJZZ AG Socket,Video/AUX Input
S505 QSOCZA001SJZZ AE Socket,SCART Out
SO301 QTANCA001SJZZ AD Terminal,FM Antenna
SO302 QTANCA002SJZZ AC Terminal,AM Antenna
SO401 QTANAA005SJZZ AF Terminal,Speaker
SW700 QSW-ZA002SJZZ AF Jog Volume
SW701 QSW-K0002SJZZ AC Switch,Key Type [Power]
SW702 QSW-K0002SJZZ AC Switch,Key Type [Play]
SW703 QSW-K0002SJZZ AC Switch,Key Type [Stop]
SW704 QSW-K0002SJZZ AC Switch,Key Type [Eject]
SW705 QSW-K0002SJZZ AC Switch,Key Type [Tuner]
SW706 QSW-K0002SJZZ AC Switch,Key Type [Function]
SW707 QSW-K0002SJZZ AC Switch,Key Type [Preset Up]
SW708 QSW-K0002SJZZ AC Switch,Key Type [Preset Down]
VFD701 VVK42-1001F-1 FL Display
