FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS
REFER TO THE OPERATION MANUAL.
GENERAL
Power source:
(JC-130)
Power source:
(JCI
30Hil29)
Output power:
(JC-I
29/l
30)
Output power:
(JC130H)
Dimensions:
Weight:
RADIO
Frequency range:
(JC-130)
Frequency range:
(JC-130H)
Frequency range:
(JC-129)
SPECIFICATIONS
TAPE DECK
DC 3 V
(UMISUM-3,
R6, HP-7 or
“AA” cell
x
2 or external DC 3 V)
DC 3 V
(UMSUM-3
or
R6
x 2 or
external DC 3 V)
Tape:
Compact cassette tape
Frequency response: 40 10,000 Hz
Signal/noise ratio:
54 dB
MAX; 60 mW (30 mW
+
30 mW)
(DC operation)
RMS; 40 mW (20 mW
+
20
mWI
(DC operation, 10% distortion)
MAX; 60 mW (30
mW
+
30
mW1
(DC operation)
HEADPHONES
Type:
Impedance:
Over-head
32 ohms
RMS; 40 mW (20
mW
+
20 mW)
(DC operation, DIN 45 324)
Width; 87 mm
(3-7116”)
Height; 138.5 mm
(5-7/16”)
Depth; 36.5 mm
(l-7/1
6”)
265
g
(9.35 oz.) without batteries
FM; 87.6
-
108
MHz
AM; 526.5
-
1606.5
kHz
FM; 87.5
-
108 MHz
AM; 526.5
-
1,606.5
kHz
FM; 88
-
108 MHz
AM: 526.5
-
1606.5
kHz
Specifications for this model are subject to change
with-
out prior notice.
NAMES OF PARTS
1.
Tuning Control
2. Band Selector Switch
3. FM Stereo Indicator
4. Function Selector Switch
5. Headphones Socket
6. Cassette Compartment
7. Volume Control
8. Play Button:
4
9. Fast Forward Button:
++
IO.
Stop/Eject Button:
n
/
r
11. External DC Power Input Socket
12. Battery Compartment
Figure 2-l
11
12
Figure 2-2
