EN
least 65cm above the hob.
· Extractor fans must be fitted in
accordance with the manufacturer's
instructions.
· The wall in contact with the rear of
the hob must be made of flameproof
material.
· The power cable length should not
exceed 2 metres
)LWWLQJWKHKRELQWRDZRUN
VXUIDFH
· The hob can be inserted into any
worktop provided it is heat resistant up
to at least 90ºC.
· Create an opening with the
dimensions shown in the picture below
and on the next page.
· The induction hob may be built in 25
to 40 mm thick worktops.
W (mm) D (mm)
H (mm)
520
590
58
PRODUCT DIMENSION
CUT OUT DIMENSION C1 (mm) C2 (mm)
560
490
NEIGHBOUR HOOD WALLS MIN A (mm) MIN B (mm)
WOOD /
CONCRETE OR CERAMIC
TILED
50 50
To Next Page
