EN
W (mm) D (mm)
H (mm)
520
590
58
PRODUCT DIMENSION
CUTOUT DIMENSION C1 (mm) C2 (mm)
560 490
NEIGHBOUR HOOD WALLS MIN A (mm) MIN B (mm)
WOOD /
CONCRETE OR CERAMIC
TILED
50 50
Apply one-sided self-adhesive sealing
tape supplied all the way round the
lower glass edge of the cooking sur-
face along the outer edge of the glass
ceramic panel. Do not stretch it.
