Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
69
LC-13B4E
LC-15B4E
DUNTKB750FE01:LC-13B4E
DUNTKB750FE02:LC-15B4E
MAIN UNIT (Continued)
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU2201 VTUVT4T5FD532 J Tuner BF
INTEGRATED CIRCUITS
IC304 VHiBH3543F+-1Y J BH3543F-E2 AE
IC1901 RH-iX1853BMZZQ J MSP3410G-QG-B8 BB
IC1902 VHiNJM4560M-1Y J NJM4560M AG
IC1905 VHiNJM4560M-1Y J NJM4560M AG
IC2202 VHiMM1506XN-1Y J MM1506XNRE AD
IC3301 VHiLA4635A+-1S J LA4635A AM
IC3501 VHiNJM4560M-1Y J NJM4560M AG
IC3701 VHiNJM2377M-1Y J NJM2377M AK
IC3702 VHiNJM2147M-1Y J NJM2147M-TE1 AF
TRANSISTORS
Q302 VSDTC144EKA-1Y J DTC144EKA AB
Q303 VSFMMT718//-1Y J FMMT718 AE
Q2201 VS2SC3928AR-1Y J 2SC3928AR AB
Q2202 VS2SC3928AR-1Y J 2SC3928AR AB
Q2203 VS2SC3928AR-1Y J 2SC3928AR AB
Q2204 VS2SC3928AR-1Y J 2SC3928AR AB
Q2205 VSiMZ1A////-1Y J IMZ1A AC
Q2206 VSiMZ1A////-1Y J IMZ1A AC
Q3301 VSDTC314TK/-1Y J DTC314TK AC
Q3302 VSDTA144EE/-1Y J DTA144EE AA
Q3303 VS2SC3928AR-1Y J 2SC3928AR AB
Q3304 VSDTC314TK/-1Y J DTC314TK AC
Q3305 VSDTC314TK/-1Y J DTC314TK AC
Q3601 VSUM5K1NTR+-1Y J UM5K1NTR AC
Q3602 VSUM5K1NTR+-1Y J UM5K1NTR AC
Q3606 VSDTC114YE/-1Y J DTC114YE AB
Q3701 VSDTC144EE/-1Y J DTC144EE AA
Q3702 VSFMMT718//-1Y J FMMT718 AE
Q3703 VSFMMT718//-1Y J FMMT718 AE
Q3704 VSDTC144EE/-1Y J DTC144EE AA
Q3705 VSFMY3/////-1Y J FMY3 AB
Q3706 VS2SK2503//-1Y J 2SK2503 AE
Q3707 VSFMMT619//-1Y J FMMT619 AE
Q3708 VS2SC3928AR-1Y J 2SC3928AR AB
Q3709 VSFMY3/////-1Y J FMY3 AB
Q3901 VS2SA1530AR-1Y J 2SA1530AR AB
Q3902 VS2SA1530AR-1Y J 2SA1530AR AB
Q3903 VSDTC314TK/-1Y J DTC314TK AC
Q3904 VS2SC3928AR-1Y J 2SC3928AR AB
Q3905 VSDTC314TK/-1Y J DTC314TK AC
Q3906 VSDTC314TK/-1Y J DTC314TK AC
Q3907 VSDTC314TK/-1Y J DTC314TK AC
DIODES
D301 VHDMA3120WA-1Y J Diode AD
D302 VHDMA3120WA-1Y J Diode AD
D303 VHDDAN222//-1Y J Diode AA
D1901 RH-EX1271CEZZY J Zener Diode, 12V AB
D2201 RH-EX0906CEZZY J Zener Diode AD
D2202 RH-EX1264CEZZY J Zener Diode AB
D3301 RH-EX1396CEZZY J Zener Diode AB
D3302 VHDDAN222//-1Y J Diode AA
D3601 VHDiMN10///-1Y J Diode AB
D3602 VHDiMN10///-1Y J Diode AB
D3605 VHDDAN222//-1Y J Diode AA
D3608 VHDDAN222//-1Y J Diode AA
D3701 VHDDAN222//-1Y J Diode AA
D3702 VHDDAN222//-1Y J Diode AA
D3705 VHDSFPB56//2EY J Diode AC
D3706 VHDSFPB74//2EY J Diode AD
D3707 VHDSFPB74//2EY J Diode AD
D3709 VHDDAN222//-1Y J Diode AA
D3710 VHD1SS250//1EY J Diode AB
D3711 VHDDAN222//-1Y J Diode AA
R2050 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2051 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2052 VRS-CY1JF512JY J 5.1k 1/16W Metal Oxide AA
R2055 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R2056 VRS-CA1JF103JY J 10k 1/16W Metal Oxide AA
R2057 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R2058 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2059 VRS-CA1JF223JY J 22k 1/16W Metal Oxide AA
R2060 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R2061 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R2063 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2064 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2065 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2066 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R2067 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2068 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2069 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2070 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2071 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2072 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2073 VRS-CA1JF153JY J 15k 1/16W Metal Oxide AB
R2076 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R2077 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R2078 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R2079 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2080 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2081 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2082 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2083 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2084 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2085 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2086 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R2087 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2088 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R2090 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2093 VRS-CA1JF103JY J 10k 1/16W Metal Oxide AA
R2096 VRS-CA1JF103JY J 10k 1/16W Metal Oxide AA
R2097 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2098 VRS-CY1JF512JY J 5.1k 1/16W Metal Oxide AA
R2099 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2100 VRS-CY1JF512JY J 5.1k 1/16W Metal Oxide AA
R2101 VRS-CY1JF512JY J 5.1k 1/16W Metal Oxide AA
R2102 VRS-CY1JF512JY J 5.1k 1/16W Metal Oxide AA
R2103 VRS-CY1JF512JY J 5.1k 1/16W Metal Oxide AA
R2104 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2105 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7003 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R7004 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R7006 VRS-CA1JF000JY J 0 1/16W Metal Oxide AB
MISCELLANEOUS PARTS
FB1201 RBLN-0083GEZZY J Ferrite Bead AB
FB1601 RBLN-0006TAZZY J Ferrite Bead AB
FB1602 RBLN-0006TAZZY J Ferrite Bead AB
FB1603 RBLN-0006TAZZY J Ferrite Bead AB
FB1604 RBLN-0006TAZZY J Ferrite Bead AB
FB1605 RBLN-0006TAZZY J Ferrite Bead AB
FB1606 RBLN-0006TAZZY J Ferrite Bead AB
FB1607 RBLN-0076TAZZY J Ferrite Bead AC
FB1608 RBLN-0076TAZZY J Ferrite Bead AC
FB1609 RBLN-0076TAZZY J Ferrite Bead AC
FB1610 RBLN-0076TAZZY J Ferrite Bead AC
FB1611 RBLN-0076TAZZY J Ferrite Bead AC
P701 QPLGN0549FJZZY J Plug, 12-pin(MB) AE
P702 QPLGN0274TAZZY J Plug, 2-pin AC
P2001 QPLGN0558REZZY J Plug, 5-pin(MS) AE
SC1202 QSOCNA002WJPZY J Socket, 20-pin(LK) AD
SC1203 QSOCN0687FJZZY J Socket, 50-pin(LS) AF
SC1204 QSOCN0206FJZZY J Socket, 30-pin(LG) AF
SC2002 QSOCN0464FJZZY J Socket, 50-pin(MA) AH
TP2040 QLUGHA002WJZZ J Lug AB
PSPAHA229WJZZ J Spacer
DUNTKB751FE01:LC-13B4E
DUNTKB751FE02:LC-15B4E
TUNER UNIT
