Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
73
LC-13B4E
LC-15B4E
DUNTKB751FE01:LC-13B4E
DUNTKB751FE02:LC-15B4E
TUNER UNIT
J5002 QJAKJ0047CEZZ J Headphone AD
J5003 QJAKEA047WJ04 J VIDEO(AV-IN2) AD
P1902 QPLGN1278GEZZ J Plug, 12-pin(MB) AC
P3301 QPLGN0278GEZZ J Plug, 2-pin(SL) AA
P3302 QPLGN0278GEZZ J Plug, 2-pin(SR) AA
P3601 QPLGN0478GEZZ J Plug, 4-pin(CL) AB
P3603 QPLGN0378GEZZ J Plug, 3-pin(VE) AB
P3901 QPLGN0006CEZZ J Plug, 14-pin AD
P3902 QPLGN0558REZZY J Plug, 5-pin(MR) AE
SC3901 QSOCZA012WJZZ J AV-IN1(21pin Euro-SCART) AG
SC3902 QSOCN0464FJZZY J Socket, 50-pin(MA) AH
SC5001 QSOCD0456CEZZ J S-VIDEO(AV-IN2) AE
TP3701 QLUGHA002WJZZ J Lug AB
TP3702 QLUGHA002WJZZ J Lug AB
LANGT9102CEFW J Fixing Metal AF
LHLDW1123GEZZ J Wire Holder AB
PSLDCA005WJZZ J Shield AC
PSLDMA208WJFW J Shield
QCNW-B183WJZZ J Connecting Cord(MB) AK
(LC-15B4E)
QCNW-B608WJZZ J Connecting Cord(MB)
(LC-13B4E)
QCNW-B647WJZZ J Connecting Cord
TRANSISTORS
Q4001 VSDTC144EE/-1Y J DTC144EE AA
Q4003 VSDTC144EE/-1Y J DTC144EE AA
Q4007 VSUMG4N++++-1Y J UMG4N AB
DIODES
D4011 RH-PX0419CEZZY J Remote Sensor Indicator AC
D4012 RH-EX1271CEZZY J Zener Diode, 12V AB
D4014 RH-PX0421CEZZY J Power/Standby Indicator AD
D4015 RH-EX1271CEZZY J Zener Diode, 12V AB
D4022 RH-EX1271CEZZY J Zener Diode, 12V AB
CAPACITOR
C4018 RC-KZ1025CEZZY J 1 10V Ceramic AB
RESISTORS
R4001 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R4021 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4023 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4024 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R4029 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P4004 QPLGN0563TAZZY J Plug, 5-pin(MR) AC
RMC4002 RRMCU0239CEZZ J R/C Sensor AG
PSLDM4646CEFW J Shield AD
QCNW-B323WJZZ J Connecting Cord(MR) AE
DUNTKB752FE01:LC-13B4E
DUNTKB752FE02:LC-15B4E
R/C, LED UNIT
DUNTKB753FE01:LC-13B4E
DUNTKB753FE02:LC-15B4E
OPERATION UNIT
DIODES
D4008 RH-EX1283CEZZY J Zener Diode AB
D4009 RH-EX1271CEZZY J Zener Diode, 12V AB
D4010 RH-EX1271CEZZY J Zener Diode, 12V AB
RESISTORS
R4005 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R4006 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R4011 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R4012 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
SWITCHES
S4701 QSW-P0035GEZZ J Main Power AF
SW4002 QSW-K0108CEZZY J CH(Ù)AD
SW4003 QSW-K0108CEZZY J CH(ù)AD
SW4004 QSW-K0108CEZZY J MENU AD
SW4006 QSW-K0108CEZZY J TV/VIDEO AD
SW4007 QSW-K0108CEZZY J Volume(+) AD
SW4008 QSW-K0108CEZZY J Volume(–) AD
MISCELLANEOUS PARTS
P4001 QPLGN0563TAZZY J Plug, 5-pin(MS) AC
QCNW-B543WJZZ J Connecting Cord(MS)
