Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
74
LC-13B4E
LC-15B4E
TRANSISTORS
Q6500 VS2SC5886++-1Y J 2SC5886 AE
Q6501 VS2SC5886++-1Y J 2SC5886 AE
Q6502 VS2SA1530AR-1Y J 2SA1530AR AB
Q6503 VS2SC5886++-1Y J 2SC5886 AE
Q6504 VS2SC5886++-1Y J 2SC5886 AE
Q6505 VS2SA1530AR-1Y J 2SA1530AR AB
DIODE
D6500 VHDDAN222//-1Y J Diode AA
COILS
L6500 RCiLPA093WJZZ J Coil AF
L6502 RCiLPA093WJZZ J Coil AF
TRANSFORMERS
å T6500 RTRNZA029WJZZQ J Transformer AH
å T6501 RTRNZA026WJZZQ J Transformer AL
å T6502 RTRNZA029WJZZQ J Transformer AH
å T6503 RTRNZA026WJZZQ J Transformer AL
CAPACITORS
C6502 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C6503 VCKYCY1CB473KY J 0.047 16V Ceramic AA
C6504 VCEA4A1CN108M J 1000 16V Electrolytic AD
C6507 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C6508 VCKYCY1CB473KY J 0.047 16V Ceramic AA
C6509 VCEA4A1CN108M J 1000 16V Electrolytic AD
C6510 RC-FZA034WJZZ J 0.15 250V Film AE
C6511 RC-FZA034WJZZ J 0.15 250V Film AE
RESISTORS
R6500 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6502 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R6503 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6504 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6506 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R6507 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6510 VRS-TW2ED152JY J 1.5k 1/4W Metal Oxide AB
R6511 VRS-TW2ED152JY J 1.5k 1/4W Metal Oxide AB
MISCELLANEOUS PARTS
å F6500 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6501 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
FH6500 QFSHD1002CEZZ J Fuse Holder AA
FH6501 QFSHD1002CEZZ J Fuse Holder AA
FH6502 QFSHD1002CEZZ J Fuse Holder AA
FH6503 QFSHD1002CEZZ J Fuse Holder AA
P6500 QPLGN0155FJZZY J Plug, 3-pin AE
P6501 QPLGN0155FJZZY J Plug, 3-pin AE
P6502 QPLGN0378GEZZ J Plug, 3-pin(VE) AB
QCNW-A385WJZZ J Connecting Cord(VE) AE
DUNTKB754FE01:LC-13B4E
DUNTKB754FE02:LC-15B4E
INVERTER UNIT
