Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
71
LC-13B4E
LC-15B4E
DUNTKB751FE01:LC-13B4E
DUNTKB751FE02:LC-15B4E
TUNER UNIT
C3508 RC-KZ0044TAZZY J 4.7 10V Ceramic AD
C3509 RC-KZA041WJZZY J 10 10V Ceramic AC
C3510 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3511 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3512 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C3513 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C3601 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3602 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3603 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3604 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3702 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3703 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3705 VCKYCY1EB103KY J 0.01 25V Ceramic AA
C3706 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3708 RC-EZA140WJZZY J 4.7 25V Electrolytic AB
C3709 VCEAPT1CN226MY J 22 16V Electrolytic AC
C3710 VCCCCY1HH471JY J 470p 50V Ceramic AA
C3711 VCKYCY1HB562KY J 5600p 50V Ceramic AA
C3712 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3713 VCAAPF1CJ826MY J 82 16V Electrolytic AG
C3714 VCKYCY1HB562KY J 5600p 50V Ceramic AA
C3715 VCCCCY1HH181JY J 180p 50V Ceramic AA
C3716 VCEASH1HN476MY J 47 50V Electrolytic AD
C3717 VCEASH1CN337MY J 330 16V Electrolytic AE
C3718 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3719 VCEASH1CN337MY J 330 16V Electrolytic AE
C3721 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C3722 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3723 VCAAPF0JJ157MY J 150 6.3V Electrolytic AG
C3724 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3726 VCEASH1CN477MY J 470 16V Electrolytic AD
C3727 RC-EZ1339CEZZY J 220 16V Electrolytic AD
C3728 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3729 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C3730 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C3731 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3732 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3733 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C3734 RC-KZ0075TAZZY J 2.2 16V Ceramic AC
C3735 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3736 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3737 RC-EZA127WJZZY J 100 16V Electrolytic AC
C3901 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C3902 RC-EZA126WJZZY J 47 16V Electrolytic AC
C3903 RC-KZA041WJZZY J 10 10V Ceramic AC
C3904 RC-KZA041WJZZY J 10 10V Ceramic AC
C3905 RC-EZA126WJZZY J 47 16V Electrolytic AC
C3906 VCCCCY1HH221JY J 220p 50V Ceramic AA
C3907 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3908 RC-KZA041WJZZY J 10 10V Ceramic AC
C3909 RC-KZA041WJZZY J 10 10V Ceramic AC
C3910 VCCCCY1HH221JY J 220p 50V Ceramic AA
C3911 VCCCCY1HH221JY J 220p 50V Ceramic AA
C3912 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3913 VCCCCY1HH221JY J 220p 50V Ceramic AA
C3914 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3915 VCCCCY1HH101JY J 100p 50V Ceramic AA
C5001 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C5002 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C5003 RC-KZA041WJZZY J 10 10V Ceramic AC
RESISTORS
R345 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R346 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R350 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R351 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R352 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R353 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R354 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R355 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R358 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R361 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R362 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1901 VRS-CA1JF102JY J 1k 1/16W Metal Oxide AA
R1902 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1903 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1904 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R1907 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1908 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1911 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1912 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1913 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R1914 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R1915 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1916 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R1917 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R1918 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R1919 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R1920 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1921 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1923 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R1924 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R1927 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1928 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1932 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1933 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R1945 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1947 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1948 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R1950 VRS-CY1JF392FY J 3.9k 1/16W Metal Oxide AA
R1952 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R1953 VRS-CY1JF392FY J 3.9k 1/16W Metal Oxide AA
R1954 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R1960 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R1962 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R1963 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1965 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R1966 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1968 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1973 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R1974 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2201 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R2202 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R2203 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R2204 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R2205 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2207 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2208 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2209 VRS-TW2ED000JY J 0 1/4W Metal Oxide AB
R2210 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2211 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2212 VRS-TW2HF1R0JY J 1 1/2W Metal Oxide
R2213 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2214 VRS-CY1JF561JY J 560 1/16W Metal Oxide AA
R2215 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2216 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2217 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2218 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2219 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R2220 VRS-TW2HF471JY J 470 1/2W Metal Oxide
R2221 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R2222 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R2223 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R2224 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2225 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2226 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2227 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R2228 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R2229 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R3301 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3302 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3303 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3304 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3305 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R3306 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R3307 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
