Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
77
LC-13B4E
LC-15B4E
10 Not Available – Serial No. Label —
11 LANGK0782CEFW J 21-pin Terminal Angle AF
12 LX-BZ3442CEFF J Screw, x4 AB
13 QCNW-A386WJZZ J Connecting Cord(MA) AD
14 QCNW-B183WJZZ J Connecting Cord(MB) AK
16 QCNW-B322WJZZ J Connecting Cord(MR) AE
17 QCNW-B543WJZZ J Connecting Cord(MS)
18 QCNW-A385WJZZ J Connecting Cord(VE) AE
19 XBBSF30P05000 J Screw, x2 AB
20 XBBSF30P08000 J Screw, x2 AA
21 XBPSN30P09JS0 J Screw, x3 AB
22 XEBSD30P06000 J Screw, x2 AA
23 XEBSD30P08000 J Screw, x10 AA
24 XEBSD30P12000 J Screw, x4 AA
25 XEBSF30P14000 J Screw, x8 AA
26 TLABS0106TAZZ J GOST Label (LC-15B4E(R)) AD
29 RCORFA009WJZZ J Core AH
1 CCABAA302WJ01 J Cabinet A Ass’y
1-1
Not Available – Cabinet A —
1-2 GCOVA2020CEZZ J R/C, LED Cover AF
1-3 HBDGBA012WJSA J ”SHARP” Badge AG
1-4 PSPAG0406CEZZ J Spacer, x2 AC
1-5 PSPAG0406CEZZ J Spacer, x2 AC
1-6 PSPAG0407CEZZ J Spacer, x4 AB
1-7 PSPAH0678CEZZ J Spacer, x2 AA
1-8 PSPAH0694CEZZ J Spacer, x2 AC
1-9 PSPAH0695CEZZ J Spacer, x2 AC
1-10 QEARZ0047CEZZ J Grounding Part AC
1-11 RSP-Z0131CEZZ J Speaker(L) AR
1-12 RSP-Z0132CEZZ J Speaker(R) AR
1-13 XETSD40P12000 J Screw, x8 AB
2 CCABB2358CE03 J Cabinet B Ass’y
2-1 Not Available – Cabinet B —
2-2 HiNDPA391WJSA J Model Label
2-3 LANGT9061CEFW J Reinforcement Angle BD
2-4 XEBSD30P08000 J Screw, x1 AA
2-5 PMLT-0401CEZZ J Light Shielding Spacer, x1 AB
2-6 PMLT-0409CEZZ J Light Shielding Spacer, x4 AC
2-7 PSPAH0720CEZZ J Spacer, x1 AD
3 CDAi-A033WJ01 J Stand Ass’yBM
3-1 GDAi-A033WJSA J Stand, Base AX
3-2 CDAi-1121CE01 J Stand Joint Ass’yBA
3-2-1
Not Available – Stand Joint —
3-2-2 PSPAZA083WJZZ J Spacer, x2 AB
3-3 GCOVA1945CESA J Stand Grip AK
3-4 GLEGGA010WJZZ J Leg, x6 AC
3-5 JHNDP0105CESA J Stand Handle AW
3-6 LANGG1196CEFW J Swivel Base AF
3-7 LANGG1198CEFW J Fixing Metal AE
3-8 LANGG1199CEFW J Fixing Metal AD
3-9 LX-NZ3185CEFE J Nut, x1 AC
3-10 MHNG-3051CEFW J Hinge AV
3-11 PSPAHA126WJZZ J Spacer, x2 AC
3-12 XESSD40P14000 J Screw, x8 AB
3-13 XESSN40P10000 J Screw, x8 AB
4 CCOVAA396WJ01 J Top Cover Ass’y
4-1 Not Available – Top Cover —
4-2 JBTN-A087WJKA J Operation Button AL
4-3 JBTN-A088WJKA J Power Button AF
4-4 LHLDZA027WJKZ J Power Button Holder AE
4-5 MSPRCA014WJFW J Spring, for Power Button AB
4-6 XEBSD30P08000 J Screw, x2 AA
5 Not Available – 15” LCD Panel Unit Ass’y —
5-1 RLCDTA013WJN1 J 15” LCD Panel Unit CZ
å 5-2 KLMP-0122CEZZ J Lamp Unit BD
5-3 PGiDM0070CEZZ J Light Guide Panel BA
5-4 PMiR-0294CEZZ J Reflection Mirror(L), x2 AG
5-5 PMiR-0295CEZZ J Reflection Mirror(S), x2 AF
5-6 PSHEP0281CEZZ J Reflection/Deflection Sheet BE
5-7 PSHEP0282CEZZ J Prism Sheet AY
5-8 PSHEP0283CEZZ J Diffusion Sheet AL
5-9 PSHEP0284CEZZ J Reflection Sheet-1 AG
5-10 PSHEP0285CEZZ J Reflection Sheet-2 AG
5-11 PSHEP0307CEZZ J Reflection Sheet(Cover) AC
5-12 PSLDM4689CEFW J Back Shield, x2 AR
5-13 QCNW-6064CEZZ J Connecting Cord AD
5-14 QCNW-6065CEZZ J Connecting Cord AC
5-15 QCNW-A069WJZZ J Connecting Cord AF
5-16 XBBSD30P05000 J Screw, x4 AA
6 GCOVA2048CEKA J Terminal Cover(L) AK
7 GCOVA2049CEKA J Terminal Cover(S) AH
8 GCOVA2116CEKA J Chassis Frame AP
9 GCOVA2118CEKA J Chassis Frame Cover AG
CABINET AND MECHANCAL PARTS
MODEL:LC-15B4E
