Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
65
LC-13S1E
LC-15S1E
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which does no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
LCD PANEL
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
LC-13S1E
DUNTKB984WE01 – TUNER Unit —
DUNTKB985WE01 – R/C,LED Unit —
DUNTKB988FE01 – MAIN Unit —
LC-15S1E
DUNTKB984WE02 – TUNER Unit —
DUNTKB985WE02 – R/C,LED Unit —
DUNTKB988FE02 – MAIN Unit —
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCDTA023WJZZ J 13" LCD Panel Unit CQ
(LC-13S1E)
RLCDTA024WJZZ J 15" LCD Panel Unit CT
(LC-15S1E)
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU2201 VTUVT4T5FD532 J Tuner BK
INTEGRATED CIRCUITS
IC350 VHiBH3543F+-1Y J BH3543F-E2 AE
IC1900 RH-iX1853BMZZQ J MSP3410G-QG-B8 BB
IC1901 VHiNJM4560M-1Y J NJM4560M AG
IC1902 VHiNJM4560M-1Y J NJM4560M AG
IC1903 VHiNJM4560M-1Y J NJM4560M AG
IC1904 VHiNJM4560M-1Y J NJM4560M AG
IC2201 VHiMM1506XN-1Y J MM1506XNRE AD
IC3301 VHiLA4635A+-1S J LA4635A AM
IC3500 VHiNJM4560M-1Y J NJM4560M AG
IC3701 VHiNJM2377M-1Y J NJM2377M AK
IC3702 VHiNJM2147M-1Y J NJM2147M-TE1 AF
TRANSISTORS
Q350 VSDTC144EKA-1Y J DTC144EKA AB
Q351 VSFMMT718//-1Y J FMMT718 AE
Q2201 VSUMZ1N////-1Y J UMZ1N AA
Q2202 VSUMZ1N////-1Y J UMZ1N AA
Q2203 VS2SC3928AR-1Y J 2SC3928AR AB
Q2204 VS2SC3928AR-1Y J 2SC3928AR AB
Q2205 VS2SC3928AR-1Y J 2SC3928AR AB
Q2206 VS2SC3928AR-1Y J 2SC3928AR AB
Q3300 VS2SC3928AR-1Y J 2SC3928AR AB
Q3301 VSDTC314TK/-1Y J DTC314TK AC
Q3302 VSDTA144EE/-1Y J DTA144EE AA
Q3303 VSDTC314TK/-1Y J DTC314TK AC
Q3304 VSDTC314TK/-1Y J DTC314TK AC
Q3601 VSDTC114YE/-1Y J DTC114YE AB
Q3602 VSUM5K1NTR+-1Y J UM5K1NTR AC
Q3603 VSUM5K1NTR+-1Y J UM5K1NTR AC
Q3701 VSUMH6N++++-1Y S UMH6N AB
Q3702 VSFMMT718//-1Y J FMMT718 AE
Q3703 VSFMMT718//-1Y J FMMT718 AE
Q3705 VSFMY3/////-1Y J FMY3 AB
Q3706 VS2SK2503//-1Y J 2SK2503 AE
Q3707 VSFMMT619//-1Y J FMMT619 AE
Q3708 VS2SC3928AR-1Y J 2SC3928AR AB
Q3709 VSFMY3/////-1Y J FMY3 AB
Q3901 VS2SA1530AR-1Y J 2SA1530AR AB
Q3902 VSUMZ1N////-1Y J UMZ1N AA
Q3903 VSDTC314TK/-1Y J DTC314TK AC
Q3904 VSDTC314TK/-1Y J DTC314TK AC
Q3905 VSDTC314TK/-1Y J DTC314TK AC
Q3906 VSDTC314TK/-1Y J DTC314TK AC
Q6500 VS2SC5886++-1Y J 2SC5886 AE
Q6501 VS2SC5886++-1Y J 2SC5886 AE
Q6502 VSUMT1N++++-1Y S UMT1N AB
Q6503 VS2SC5886++-1Y J 2SC5886 AE
Q6504 VS2SC5886++-1Y J 2SC5886 AE
DIODES
D350 VHDDAN222//-1Y J Diode AA
D351 VHDMA3120WA-1Y J Diode AD
D352 VHDMA3120WA-1Y J Diode AD
D1901 RH-EX1271CEZZY J Zener Diode, 12V AB
D2201 RH-EXA101WJZZY J Zener Diode AA
D2202 RH-EX1264CEZZY J Zener Diode AB
D3300 VHDDAN222//-1Y J Diode AA
D3301 RH-EX1396CEZZY J Zener Diode AB
D3600 VHDiMN10///-1Y J Diode AB
D3601 VHDiMN10///-1Y J Diode AB
D3602 VHDDAN222//-1Y J Diode AA
D3603 VHDDAN222//-1Y J Diode AA
D3605 RH-EX1283CEZZY J Zener Diode, 18V AB
D3702 VHDDAN222//-1Y J Diode AA
D3705 VHDSFPB56//2EY J Diode AC
DUNTKB984WE01 (LC-13S1E)
DUNTKB984WE02 (LC-15S1E)
TUNER UNIT
