Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
70
LC-13S1E
LC-15S1E
DUNTKB985WE01 (LC-13S1E)
DUNTKB985WE02 (LC-15S1E)
R/C, LED UNIT
DUNTKB988WE01 (LC-13S1E)
DUNTKB988WE02 (LC-15S1E)
MAIN UNIT
INTEGRATED CIRCUITS
IC702 VHiBA05FP++-1Y J BA05FP-E2 AF
IC704 VHiNJ79M08D-1Y J NJM79M08DL1A AF
IC705 VHiNJU7662M-1Y J NJU7662M(TE2) AL
IC706 VHiPQ1R34++-1Y J PQ1R34 AE
IC707 VHiPQ1R33//-1Y J PQ1R33 AE
IC708 VHiLM1117MJ-1Y J LM1117MPX-ADJ AF
IC709 VHiMM1562FF-1Y J MM1562FFBE AE
IC710 VHiMM1563DF-1Y J MM1563DFBE AE
IC801 VHiVPC3230D1EQ J VPC3230D-QA-B3 BD
IC802 VHiNJM2293M-1Y J NJM2293M(TE1) AG
IC803 VHiNJM2268M-1Y J NJM2268M-TE1 AF
IC804 VHiBA7046F/-1Y J BA7046F AF
IC805 VHiNJM2233V-1Y J NJM2233V AE
IC806 VHiMM1563DF-1Y J MM1563DFBE AE
IC1101 VHiBD8120FP-1Y J BD8120FP AX
IC1201 VHiDPS9450+-1Q J DPS9450A-XZ-A1 BD
IC1202 VHiTC4W66U/-1Y J TC4W66FU AE
IC1601 VHiSDA5550M-1Q J SDA5550M AZ
IC1603 VHiPST3228N1EY J PST3228NR AD
IC1604 VHiMM1501XN-1Y J MM1501XNRE AE
IC1606 VHiPST3221N1EY J PST3221NR AD
IC1608 VHiNC7SZ58P-1Y J NC7SZ58P6X AE
IC1611 RH-iXA745WJN1Q J M29W400BT70N6 AP
IC1612 VHi62S8308X-1Q J A62S8308X-70SI AY
IC2001 RH-iXA661WJZZQ J I.C. BA
IC2003 VHiSi3010KM-1Y J SI-3010KM-TL AF
IC2004 VHiMM1573DN-1Y J MM1573DNRE AD
IC2006 VHiBD4729G+-1Y J BD4729G-TR AD
IC2007 VHiBR24C32F-1Y J BR24C32F-E2 AH
IC2009 VHiBR2416E2-1Y J BR24C16F AK
IC2010 VHiTC4W66U/-1Y J TC4W66FU AE
IC2011 VHiTC4W66U/-1Y J TC4W66FU AE
TRANSISTORS
Q701 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q702 VSDTC144EE/-1Y J DTC144EE AA
Q703 VSFMMT718//-1Y J FMMT718 AE
Q704 VSDTC144EE/-1Y J DTC144EE AA
Q705 VSUMX2N++++-1Y J UMX2N AB
Q801 VS2SA1530AR-1Y J 2SA1530AR AB
Q802 VS2SA1530AR-1Y J 2SA1530AR AB
Q803 VS2SA1530AR-1Y J 2SA1530AR AB
Q1101 VSFMMT718//-1Y J FMMT718 AE
Q1102 VS2SC4520//-1Y J 2SC4520 AE
Q1103 VS2SA1729//-1Y J 2SA1729 AF
Q1104 VSDTC144EE/-1Y J DTC144EE AA
Q1105 VS2SC4520//-1Y J 2SC4520 AE
Q1106 VS2SA1729//-1Y J 2SA1729 AF
Q1206 VSDTC144EE/-1Y J DTC144EE AA
Q1601 VS2SA1530AR-1Y J 2SA1530AR AB
Q1602 VS2SA1530AR-1Y J 2SA1530AR AB
Q1603 VSDTC144TE/-1Y J DTC144TE AB
Q1604 VS2SA1530AR-1Y J 2SA1530AR AB
Q1605 VS2SC3928AR-1Y J 2SC3928AR AB
Q1606 VS2SA1530AR-1Y J 2SA1530AR AB
Q1607 VS2SA1530AR-1Y J 2SA1530AR AB
Q2001 VSUM5K1NTR+-1Y J UM5K1NTR AC
Q2005 VSDTC114EE/-1Y J DTC114EE AB
Q2006 VSDTC114EE/-1Y J DTC114EE AB
Q2007 VSUPA606T//-1Y J UPA606T AD
Q2008 VSDTC114EE/-1Y J DTC114EE AB
Q2009 VSUPA606T//-1Y J UPA606T AD
Q2011 VSUPA606T//-1Y J UPA606T AD
DIODES
D701 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D702 VHDDAN222//-1Y J Diode AA
D703 VHDDAN222//-1Y J Diode AA
D704 RH-EX1245CEZZY J Zener Diode, 5.1V AB
D705 VHDDAN222//-1Y J Diode AA
INTEGRATED CIRCUITS
IC4201 VHiTPS850++-1Y J TPS850 AG
TRANSISTORS
Q4001 VSDTC144EE/-1Y J DTC144EE AA
Q4002 VSUMG4N++++-1Y J UMG4N AB
Q4003 VSDTC144EE/-1Y J DTC144EE AA
Q4004 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D4001 RH-PX0421CEZZY J Power/Standby AD
Remote Sensor Indicator
D4002 RH-PX0421CEZZY J OPC Sensor Indicator AD
D4004 RH-EX1271CEZZY J Zener Diode, 12V AB
D4005 RH-EX1271CEZZY J Zener Diode, 12V AB
D4006 RH-EX1271CEZZY J Zener Diode, 12V AB
D4007 RH-EX1271CEZZY J Zener Diode, 12V AB
D4011 RH-EX1247CEZZY J Zener Diode, 5.6V AB
CAPACITORS
C4001 RC-KZ0117TAZZY J 4.7 6.3V Ceramic AD
C4201 RC-EZA124WJZZY J 10 16V Electrolytic AB
C4202 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C4203 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
RESISTORS
R4001 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R4002 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4003 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4006 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4007 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R4009 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
J4021 QJAKJ0068CEZZ J Headphone Jack AG
P4001 QPLGN0958REZZY J Plug, 9-pin(MS) AC
P4003 QPLGN0378GEZZ J Plug, 3-pin(TM) AB
RMC4001 RRMCU0239CEZZ J R/C Receiver AG
