Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
69
LC-13S1E
LC-15S1E
DUNTKB984WE01 (LC-13S1E)
DUNTKB984WE02 (LC-15S1E)
TUNER UNIT (Continued)
R3722 VRS-TW2HF152JY J 1.5k 1/2W Metal Oxide AA
R3723 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3725 VRS-TW2HF152JY J 1.5k 1/2W Metal Oxide AA
R3728 VRS-TV1JD103JY J 10k 1/10W Metal Oxide AA
R3729 VRS-CY1JF1R0JY J 1 1/16W Metal Oxide AA
R3731 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3734 VRS-TQ2BD683JY J 68k 1/8W Metal Oxide AA
R3735 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3737 VRS-TW2ED561JY J 560 1/4W Metal Oxide AA
R3738 VRS-CY1JF113FY J 11k 1/16W Metal Oxide AA
R3739 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R3740 VRS-CY1JF182FY J 1.8k 1/16W Metal Oxide AA
R3741 VRS-CY1JF122FY J 1.2k 1/16W Metal Oxide AA
R3742 VRS-CY1JF682FY J 6.8k 1/16W Metal Oxide AA
R3743 VRS-CY1JF122FY J 1.2k 1/16W Metal Oxide AA
R3744 VRS-CY1JF223FY J 22k 1/16W Metal Oxide AA
R3745 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3746 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3747 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R3748 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3749 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R3750 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3751 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
R3752 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
R3753 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R3754 VRS-TV1JD103JY J 10k 1/16W Metal Oxide AA
R3755 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3756 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R3902 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3903 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3904 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3905 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3906 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3907 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3908 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3909 VRS-CJ1JF271JY S 270 1/16W Metal Oxide AA
R3910 VRS-CJ1JF104JY S 100k 1/16W Metal Oxide AA
R3911 VRS-CY1JF823JY J 82k 1/16W Metal Oxide AA
R3912 VRS-CJ1JF104JY S 100k 1/16W Metal Oxide AA
R3913 VRS-CJ1JF271JY S 270 1/16W Metal Oxide AA
R3914 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R3915 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R3916 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3917 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3918 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3919 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3920 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3921 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3922 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R3923 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3924 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3925 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3926 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R3927 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3928 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3929 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3930 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3931 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3932 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4011 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R4012 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R4015 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R4016 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R5000 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R5001 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R5002 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5003 VRS-CJ1JF473JY S 47k 1/16W Metal Oxide AA
R5004 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5005 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R5006 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R5007 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5008 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5009 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5010 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5012 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5013 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6500 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6501 VRS-TW2ED152JY J 1.5k 1/4W Metal Oxide AB
R6502 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6503 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6504 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6506 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6507 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6513 VRS-TW2ED152JY J 1.5k 1/4W Metal Oxide AB
R6518 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
SWITCHES
S4001 QSW-PA011WJZZ J MAIN POWER AF
SW4002 QSW-K0065GEZZY J CH(Ù)AD
SW4003 QSW-K0065GEZZY J CH(ù)AD
SW4004 QSW-K0065GEZZY J MENU AD
SW4006 QSW-K0065GEZZY J TV/VIDEO AD
SW4007 QSW-K0065GEZZY J VOL(+) AD
SW4008 QSW-K0065GEZZY J VOL(–) AD
MISCELLANEOUS PARTS
å F3301 QFS-D0008CEZZ J Fuse, 2A/250V AE
å F3302 QFS-ZA002WJZZ J Fuse, 1.25A/250V AD
å F6501 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6502 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
FH3301 QFSHD1002CEZZ J Fuse Holder AA
FH3302 QFSHD1002CEZZ J Fuse Holder AA
FH6501 QFSHD1002CEZZ J Fuse Holder AA
FH6502 QFSHD1002CEZZ J Fuse Holder AA
FH6503 QFSHD1002CEZZ J Fuse Holder AA
FH6504 QFSHD1002CEZZ J Fuse Holder AA
FB350 RBLN-0062TAZZY J Ferrite Bead AB
FB351 RBLN-0062TAZZY J Ferrite Bead AB
FB352 RBLN-0062TAZZY J Ferrite Bead AB
FB3300 RBLN-0254TAZZY J Ferrite Bead AB
FB3301 RBLN-0254TAZZY J Ferrite Bead AB
FB3302 RBLN-0254TAZZY J Ferrite Bead AB
FB3304 RBLN-0254TAZZY J Ferrite Bead AB
FB3305 RBLN-0254TAZZY J Ferrite Bead AB
FB3701 RBLN-0095CEZZY J Ferrite Bead AD
FB3702 RBLN-0095CEZZY J Ferrite Bead AD
FB3703 RBLN-0095CEZZY J Ferrite Bead AD
FB3705 RBLN-0051TAZZY J Ferrite Bead AC
FB3707 RBLN-0254TAZZY J Ferrite Bead AB
FB3708 RBLN-0051TAZZY J Ferrite Bead AC
FB3709 RBLN-0254TAZZY J Ferrite Bead AB
FB5000 RBLN-0062CEZZY J Ferrite Bead AC
J3300 QJAKCA010WJZZ J POWER INPUT DC 12V AF
J3900 QJAKFA021WJZZ S AUDIO OUT(L/R) AD
J5000 QSOCD0456CEZZ J S-VIDEO(AV-IN2) AE
J5001 QJAKGA038WJZZ J AUDIO(L/R)/VIDEO(AV-IN2) AE
P350 QPLGN0378GEZZ J Plug, 3-pin(TM) AB
P3301 QPLGN0478GEZZ J Plug, 4-pin(TS) AB
P3600 QPLGN0478GEZZ J Plug, 4-pin AB
P6500 QPLGN0155FJZZY J Plug, 3-pin AE
P6501 QPLGN0155FJZZY J Plug, 3-pin AE
SC3901 QSOCN0464FJZZY J Socket, 50-pin(MA) AH
SC3902 QSOCZA056WJZZ S 21-pin Euro-SCART(AV-IN1)AH
TP3300 QLUGHA006WJZZY J Lug AA
TP3301 QLUGHA006WJZZY J Lug AA
TP3701 QLUGHA006WJZZY J Lug AA
LANGT9102CEFW J Tuner Angle AF
PSLDMA208WJFW J Tuner Shield AD
QCNW-B527WJQZ J Connecting Cord AK
