Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
75
LC-13S1E
LC-15S1E
CABINET AND MECHANICAL PARTS
(LC-13S1E)
1 Not wAvailable – Cabinet A Ass’y Unit —
1-1 CCABAA376WJ02 S Cabinet A Ass’y BG
1-1-1 Not Available – Cabinet A —
1-1-2 HDECQA269WJSA J R/C, LED Cover AE
1-1-3 PSPAHA061WJZZ J Spacer(L), x2 AC
1-1-4 PSPAHA062WJZZ J Spacer(S), x2 AC
1-1-5 QEARZ0047CEZZ J Grounding Part AC
1-2 QCNW-B662WJQZ J Connecting Cord(SP) AH
1-3 VSP7530PB628B J Speaker, x2 AN
1-4 XEBSN30P08000 J Screw, x6 AA
2 CCABBA271WJ02 S Cabinet B Ass’y BL
2-1 Not Available – Cabinet B —
2-2 GCOVAA502WJKA J Terminal Cover AH
2-3 GLEGGA027WJSA J Rubber Leg, x2 AF
2-4 JBTN-A183WJKA J Operation Button AK
2-5 JBTN-A186WJKA J Power Button AF
2-6 LANGF2155CEFW J Round Rock AD
2-7 LANGTA080WJFW J Reinforcement Angle AM
2-8 MSPRCA015WJFW J Power Button Spring AB
2-9 PMLT-0402CEZZ J Light Shielding Spacer, x1 AC
2-10 XEBSN30P08000 J Screw, x3 AA
3 CDAi-A089WJ01 J Stand Ass’y BC
3-1 CDAi-A089WJ02 J Stand Base Ass’y AZ
3-1-1 Not Available – Stand Base —
3-1-2 GLEGGA029WJSA J Rubber Leg, x1 AF
3-1-3 PSPAZA083WJZZ J Spacer, x2 AB
3-2 JHNDPA004WJSA J Stand Handle AT
3-3 XESSN40P14000 J Screw, x8 AA
4 Not Available – 13” LCD Panel Unit Ass’y —
4-1 RLCDTA023WJZZ J 13” LCD Panel Unit CQ
4-2 Not Available – Back Shield Ass’y —
4-2-1 PSLDMA253WJFW J Back Shield AP
4-2-2 TCAUZA031WJZZ J Caution Label AB
å 4-3 KLMP-0120CEZZ J Lamp Unit BD
4-4 PGiDMA010WJZZ J Light Guide Plate AY
4-5 PMiR-0292CEZZ J Reflection Mirror(L), x2 AG
4-6 PMiR-0293CEZZ J Reflection Mirror(S), x2 AF
4-7 PSHEP0276CEZZ J Reflection/Deflection Sheet BB
4-8 PSHEP0277CEZZ J Prism Sheet AV
4-9 PSHEP0278CEZZ J Diffusion Sheet AL
4-10 PSHEP0279CEZZ J Reflection Sheet-1 AG
4-11 PSHEP0280CEZZ J Reflection Sheet-2 AG
4-12 PSHEP0306CEZZ J Reflection Sheet(Cover) AC
4-13 QCNW-B531WJQZ J Connecting Cord AD
4-14 QCNW-B532WJQZ J Connecting Cord AF
4-15 QCNW-B779WJQZ J Connecting Cord AE
4-16 PSLDMA284WJZZ J Shield, x2 AE
4-17 PSPAKA014WJZZ J Spacer, x1 AD
4-18 PMLT-A074WJZZ J Light Shielding Spacer AD
5 GCOVAA505WJKA J Bass Cone Cover AD
6 LCHSMA052WJKA S Chassis Frame(R) AS
7 LCHSMA055WJKA J Chassis Frame(L) AL
8 LHLDZA251WJKZ J Power Button Holder AD
9 LX-BZ3442CEF9 J Screw, x4 AB
10 QCNW-B528WJQZ J Connecting Cord AG
11 QCNW-B529WJQZ J Connecting Cord AG
12 QCNW-B534WJQZ J Connecting Cord AF
13 Not Available – Serial No. Label —
14 HiNDPA606WJSA S Model Label AG
15 XBBS930P05000 J Screw, x1 AA
16 XBPSN30P10JS0 J Screw, x5 AB
17 XBPSN30P18JS0 J Screw, x3 AA
18 XEBS930P14000 J Screw, x7 AA
19 XEBSN30P08000 J Screw, x2 AA
20 RCORFA009WJZZ J Core AH
21 RCORFA031WJZZ J Core AH
23 PSPAKA031WJZZ J Spacer, x1 AD
24 XBBS930P05000 J Screw, x1 AA
27 TLABSA028WJSA S GOST Label(LC-13S1E(R))
