Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
71
LC-13S1E
LC-15S1E
DUNTKB988WE01 (LC-13S1E)
DUNTKB988WE02 (LC-15S1E)
MAIN UNIT (Continued)
D706 VHDDAN222//-1Y J Diode AA
D707 VHDDAN222//-1Y J Diode AA
D708 RH-EX1245CEZZY J Zener Diode, 5.1V AB
D709 VHDDAN222//-1Y J Diode AA
D710 VHDDAN202K/-1Y J Diode AB
D711 VHD1SS250//1EY J Diode AB
D712 VHDDAN222//-1Y J Diode AA
D713 VHDRB481K++-1Y J Diode AD
D714 VHDRB491D++-1Y J Diode AD
D1101 VHD1SS250//1EY J Diode AB
D1103 VHD1SS250//1EY J Diode AB
D1104 VHD1SS250//1EY J Diode AB
D2001 RH-EX1232CEZZY J Zener Diode AB
D2002 VHDDAN202K/-1Y J Diode AB
D2003 VHDDAN202K/-1Y J Diode AB
D2004 VHDRB491D++-1Y J Diode AD
PACKAGED CIRCUITS
X801 RCRSC0012CEZZY J Crystal, 20.25MHz AH
X1201 RCRSC0012CEZZY J Crystal AH
X1601 RCRSCA002WJZZY J Crystal AG
FILTERS AND COILS
FL801 RFiLJA001WJZZY J Filter AG
FL802 RFiLJA001WJZZY J Filter AG
FL2001 RFiLZ0169TAZZY J Filter AD
L701 RCiLPA143WJZZY J Coil AD
L702 VP-1M470J5R4NY J Peaking 47µH AC
L801 RCiLPA143WJZZY J Coil AD
L802 RCiLPA143WJZZY J Coil AD
L803 VP-9N3R3KR46NY J Peaking 3.3µH AC
L804 VP-9N3R3KR46NY J Peaking 3.3µH AC
L805 VP-9N3R3KR46NY J Peaking 3.3µH AC
L1201 VPCGM220M0R5NY J Peaking 22µH AB
L1202 VPCGM220M0R5NY J Peaking 22µH AB
L1203 VPCGM220M0R5NY J Peaking 22µH AB
L1204 VPCGM220M0R5NY J Peaking 22µH AB
L1601 VP-1M270J3R8NY J Peaking 27µH AC
CAPACITORS
C701 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C702 RC-EZA127WJZZY J 100 16V Electrolytic AC
C704 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C705 RC-EZA127WJZZY J 100 16V Electrolytic AC
C707 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C708 VCEASK1CN227MY J 220 16V Electrolytic AC
C709 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C710 VCKYTV1CB105KY J 1 16V Ceramic AC
C711 VCKYTV1CB105KY J 1 16V Ceramic AC
C712 RC-KZ0075TAZZY J 2.2 16V Ceramic AC
C713 RC-EZA132WJZZY J 10 50V Electrolytic AC
C714 RC-KZA041WJZZY J 10 10V Ceramic AC
C715 RC-EZA129WJZZY J 2.2 50V Electrolytic AB
C716 VCKYTV1CB105KY J 1 16V Ceramic AC
C717 RC-KZA041WJZZY J 10 10V Ceramic AC
C718 VCKYTV1CB105KY J 1 16V Ceramic AC
C719 RC-KZA041WJZZY J 10 10V Ceramic AC
C720 RC-EZA132WJZZY J 10 50V Electrolytic AC
C721 RC-KZA041WJZZY J 10 10V Ceramic AC
C722 RC-KZA041WJZZY J 10 10V Ceramic AC
C723 RC-EZA132WJZZY J 10 50V Electrolytic AC
C724 VCKYTV1CB105KY J 1 16V Ceramic AC
C725 RC-KZA041WJZZY J 10 10V Ceramic AC
C726 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C727 VCEASH0JN227MY J 220 6.3V Electrolytic AC
C728 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
C729 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C730 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C731 RC-EZA131WJZZY J 4.7 50V Electrolytic AC
C732 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C733 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C734 VCCCCY1HH471JY J 470p 50V Ceramic AA
C735 RC-EZA132WJZZY J 10 50V Electrolytic AC
C736 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C737 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
C738 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C739 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C740 VCCCCY1HH471JY J 470p 50V Ceramic AA
C741 VCEASH1CN107MY J 100 16V Electrolytic AC
C801 RC-KZA041WJZZY J 10 10V Ceramic AC
C802 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C803 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C804 RC-KZA041WJZZY J 10 10V Ceramic AC
C805 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C806 RC-KZA041WJZZY J 10 10V Ceramic AC
C807 RC-KZA041WJZZY J 10 10V Ceramic AC
C808 VCKYCY1AB105KY J 1 10V Ceramic AB
C809 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C810 VCCCCY1HH101JY J 100p 50V Ceramic AA
C811 RC-KZA041WJZZY J 10 10V Ceramic AC
C812 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C813 RC-KZA041WJZZY J 10 10V Ceramic AC
C814 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C815 VCKYCY1AB105KY J 1 10V Ceramic AB
C816 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C817 RC-EZA135WJZZY J 47 6.3V Electrolytic AC
C818 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C819 VCKYTV1CF684ZY J 0.68 16V Ceramic AB
C820 VCKYTV1CF684ZY J 0.68 16V Ceramic AB
C821 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C822 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C823 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C824 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C825 RC-KZ1025CEZZY J 1 10V Ceramic AB
C827 RC-KZ1025CEZZY J 1 10V Ceramic AB
C828 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C829 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C830 VCKYCY1HB331KY J 330p 50V Ceramic AA
C831 RC-EZA122WJZZY J 22 6.3V Electrolytic AB
C832 VCKYCY1AB224KY J 0.22 10V Ceramic AB
C833 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C834 VCKYCY1HB331KY J 330p 50V Ceramic AA
C835 VCKYCY1AB224KY J 0.22 10V Ceramic AB
C836 RC-EZA124WJZZY J 10 16V Electrolytic AB
C837 VCKYCY1HB331KY J 330p 50V Ceramic AA
C838 VCKYCY1AB224KY J 0.22 10V Ceramic AB
C839 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C840 VCCCCY1HH7R0DY J 7p 50V Ceramic AA
C841 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C842 VCCCCY1HH471JY J 470p 50V Ceramic AA
C843 VCCCCY1HH7R0DY J 7p 50V Ceramic AA
C844 RC-EZA134WJZZY J 220 6.3V Electrolytic AC
C845 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C846 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C847 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C848 RC-KZ0117TAZZY J 4.7 6.3V Ceramic AD
C849 RC-KZ1025CEZZY J 1 10V Ceramic AB
C850 RC-KZ1025CEZZY J 1 10V Ceramic AB
C851 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C852 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C854 RC-KZ1025CEZZY J 1 10V Ceramic AB
C856 RC-KZ1025CEZZY J 1 10V Ceramic AB
C857 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C863 VCKYCY1EB473KY J 0.047 25V Ceramic AA
C865 VCKYCY1EB473KY J 0.047 25V Ceramic AA
C866 VCKYCY1EB473KY J 0.047 25V Ceramic AA
C1101 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1102 RC-EZ1339CEZZY J 220 16V Electrolytic AD
C1104 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1105 VCCCCY1HH181JY J 180p 50V Ceramic AA
C1106 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1107 RC-KZA041WJZZY J 10 10V Ceramic AC
C1108 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1109 RC-KZA041WJZZY J 10 10V Ceramic AC
C1110 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1111 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
