Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
72
LC-13S1E
LC-15S1E
DUNTKB988WE01 (LC-13S1E)
DUNTKB988WE02 (LC-15S1E)
MAIN UNIT (Continued)
C1112 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1113 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1114 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1115 VCKYTV1CB334KY J 0.33 16V Ceramic AC
C1116 VCKYTV1CB105KY J 1 16V Ceramic AC
C1117 VCKYTV1CB105KY J 1 16V Ceramic AC
C1118 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C1119 RC-KZA041WJZZY J 10 10V Ceramic AC
C1122 RC-EZ1339CEZZY J 220 16V Electrolytic AD
C1201 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1202 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1203 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1204 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1205 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1206 VCCCCY1HH180JY J 18p 50V Ceramic AA
C1207 VCCCCY1HH180JY J 18p 50V Ceramic AA
C1208 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1209 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1210 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1211 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1212 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1213 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1214 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1215 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1216 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1217 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1218 VCKYCY1CF474ZY J 0.47 16V Ceramic AB
C1219 VCKYCY1CF474ZY J 0.47 16V Ceramic AB
C1220 VCKYCY1CF474ZY J 0.47 16V Ceramic AB
C1221 VCKYCY1CF474ZY J 0.47 16V Ceramic AB
C1222 VCKYCY1CF474ZY J 0.47 16V Ceramic AB
C1223 VCKYCY1CF474ZY J 0.47 16V Ceramic AB
C1224 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1225 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1226 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1227 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1228 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1229 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1230 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1231 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C1232 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C1233 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C1234 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C1235 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1236 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1237 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1238 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1243 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1244 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1601 RC-KZ0074TAZZY J 10 6.3V Ceramic AF
C1603 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1607 RC-EZA199WJZZY J 10 25V Electrolytic AC
C1610 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1613 VCE9PF0JN226MY J 22 6.3V Elect. (N.P) AD
C1615 RC-EZA125WJZZY J 22 16V Electrolytic AC
C1616 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1619 VCCCCY1HH181JY J 180p 50V Ceramic AA
C1620 VCE9PF0JN226MY J 22 6.3V Elect. (N.P) AD
C1622 RC-EZA122WJZZY J 22 6.3V Electrolytic AB
C1623 RC-EZA135WJZZY J 47 6.3V Electrolytic AC
C1624 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1625 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1626 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1627 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1628 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1629 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1630 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1631 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1632 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1633 VCKYTV1CF105ZY J 1 16V Ceramic AB
C1634 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1639 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1640 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1641 VCCCCY1HH180JY J 18p 50V Ceramic AA
C1643 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1644 RC-KZ0074TAZZY J 10 6.3V Ceramic AF
C1649 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2002 VCKYTV1CF105ZY J 1 16V Ceramic AB
C2004 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2005 VCKYCY1AB105KY J 1 10V Ceramic AB
C2006 RC-EZA122WJZZY J 22 6.3V Electrolytic AB
C2007 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2009 RC-KZ0074TAZZY J 10 6.3V Ceramic AF
C2013 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2017 VCKYTV1CF684ZY J 0.68 16V Ceramic AB
C2019 RC-EZA124WJZZY J 10 16V Electrolytic AB
C2020 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2022 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2023 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2025 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2026 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2027 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2028 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2029 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C2030 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C2031 VCKYCY1HB102KY J 1000p 50V Ceramic AA
RESISTORS
R703 VRS-TW2HF2R2JY J 2.2 1/2W Metal Oxide AA
R704 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R705 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R706 VRS-CY1JF1R0JY J 1 1/16W Metal Oxide AA
R708 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R709 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R710 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R711 VRS-TW2ED103JY J 10k 1/4W Metal Oxide AA
R712 VRS-CY1JF680FY J 68 1/16W Metal Oxide AA
R714 VRS-CY1JF151FY J 150 1/16W Metal Oxide AA
R715 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R716 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R717 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R718 VRS-TW2HF330JY J 33 1/2W Metal Oxide AA
R721 VRS-TV1JD562JY J 5.6k 1/10W Metal Oxide AA
R723 VRS-TW2ED150JY J 15 1/4W Metal Oxide AA
R724 VRS-TW2HF472JY J 4.7k 1/2W Metal Oxide AA
R803 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R805 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R806 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R807 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R808 VRS-CY1JF474JY J 470k 1/16W Metal Oxide AA
R810 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R811 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R812 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R814 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R815 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R816 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R817 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R818 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R819 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R820 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R821 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R823 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R827 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R828 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R829 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R835 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R836 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R837 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R838 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R839 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R841 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R842 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R843 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R845 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R847 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R853 VRS-CA1JF220JY J 22 1/16W Metal Oxide AA
