Sharp LC-13S1E User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
67
LC-13S1E
LC-15S1E
DUNTKB984WE01 (LC-13S1E)
DUNTKB984WE02 (LC-15S1E)
TUNER UNIT (Continued)
C1964 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1965 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C1967 VCKYCY1HB222KY J 2200p 50V Ceramic AA
(LC-15S1E)
C1967 VCKYCY1HB272KY J 2700p 50V Ceramic AA
(LC-13S1E)
C2201 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2202 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C2203 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2204 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2205 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2206 VCEASH1CN477MY J 470 16V Electrolytic AD
C2207 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2208 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C2209 RC-EZA128WJZZY J 1 50V Electrolytic AB
C2210 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2211 VCCCCY1HH121JY J 120p 50V Ceramic AA
C2212 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2213 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2214 VCCCCY1HH180JY J 18p 50V Ceramic AA
C2215 VCCCCY1HH121JY J 120p 50V Ceramic AA
C2216 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2217 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2218 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2219 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2220 RC-KZA041WJZZY J 10 10V Ceramic AC
C2221 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2222 VCEASH1CN477MY J 470 16V Electrolytic AD
C2223 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2224 RC-EZ1351CEZZ J 3300 6.3V Electrolytic AF
C2225 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3300 RC-EZ1274CEZZ J 1000 16V Electrolytic AD
C3301 RC-EZ1274CEZZ J 1000 16V Electrolytic AD
C3302 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3304 RC-EZA124WJZZY J 10 16V Electrolytic AB
C3305 RC-EZA127WJZZY J 100 16V Electrolytic AC
C3306 RC-KZA041WJZZY J 10 10V Ceramic AC
C3307 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3308 RC-EZA128WJZZY J 1 50V Electrolytic AB
C3309 RC-EZA128WJZZY J 1 50V Electrolytic AB
C3310 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3312 RC-KZA041WJZZY J 10 10V Ceramic AC
C3313 RC-EZA129WJZZY J 2.2 50V Electrolytic AB
C3314 RC-EZA129WJZZY J 2.2 50V Electrolytic AB
C3315 VCEASH1CN337MY J 330 16V Electrolytic AE
C3500 VCKYCY1EB223KY J 0.022 25V Ceramic AA
C3501 VCKYCY1EB223KY J 0.022 25V Ceramic AA
C3502 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3503 RC-KZ0044TAZZY J 4.7 10V Ceramic AD
C3504 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3505 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3506 RC-EZ0417CEZZY J 150 16V Electrolytic AD
C3507 RC-KZ0044TAZZY J 4.7 10V Ceramic AD
C3508 RC-KZA041WJZZY J 10 10V Ceramic AC
C3509 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3510 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3511 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C3512 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C3600 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3601 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3602 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3603 RC-KZ0072TAZZY J 1 25V Ceramic AC
C3702 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3703 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3705 VCKYCY1EB103KY J 0.01 25V Ceramic AA
C3706 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3708 RC-EZA140WJZZY J 4.7 25V Electrolytic AB
C3709 VCEAPT1CN226MY J 22 16V Electrolytic AC
C3710 VCCCCY1HH471JY J 470p 50V Ceramic AA
C3711 VCKYCY1HB562KY J 5600p 50V Ceramic AA
C3712 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3713 VCAAPF1CJ826MY J 82 16V Electrolytic AG
C3714 VCKYCY1HB562KY J 5600p 50V Ceramic AA
C3715 VCCCCY1HH181JY J 180p 50V Ceramic AA
C3716 VCEASH1HN476MY J 47 50V Electrolytic AD
C3717 VCEASH1CN337MY J 330 16V Electrolytic AE
C3718 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3719 VCEASH1CN337MY J 330 16V Electrolytic AE
C3721 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C3722 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3723 VCAAPF0JJ157MY J 150 6.3V Electrolytic AG
C3724 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3726 VCEASH1CN477MY J 470 16V Electrolytic AD
C3727 RC-EZ1339CEZZY J 220 16V Electrolytic AD
C3728 VCKYTV1CF105ZY J 1 16V Ceramic AB
C3729 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C3730 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C3731 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3732 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3733 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C3734 RC-KZ0075TAZZY J 2.2 16V Ceramic AC
C3735 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3736 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3737 RC-EZA127WJZZY J 100 16V Electrolytic AC
C3901 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C3902 RC-EZA126WJZZY J 47 16V Electrolytic AC
C3903 RC-KZA041WJZZY J 10 10V Ceramic AC
C3904 RC-KZA041WJZZY J 10 10V Ceramic AC
C3905 RC-EZA126WJZZY J 47 16V Electrolytic AC
C3906 VCCCCY1HH331JY J 330p 50V Ceramic AA
C3907 RC-KZA041WJZZY J 10 10V Ceramic AC
C3908 RC-KZA041WJZZY J 10 10V Ceramic AC
C3909 VCCCCY1HH221JY J 220p 50V Ceramic AA
C3910 VCCCCY1HH331JY J 330p 50V Ceramic AA
C3911 VCCCCY1HH221JY J 220p 50V Ceramic AA
C3912 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3913 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3914 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3915 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3916 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3917 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3918 VCCCCY1HH101JY J 100p 50V Ceramic AA
C5000 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5001 VCCCCY1HH101JY J 100p 50V Ceramic AA
C5002 VCCCCY1HH101JY J 100p 50V Ceramic AA
C6502 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6503 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6504 VCEA4A1CN228M J 2200 16V Electrolytic AF
C6507 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6508 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6509 VCEA4A1CN228M J 2200 16V Electrolytic AF
C6510 RC-FZA107WJZZ J 0.1 250V Film AD
C6511 RC-FZA107WJZZ J 0.1 250V Film AD
C6513 VCKYCY1HB332KY J 3300p 50V Ceramic AA
RESISTORS
R352 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R354 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R356 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R357 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R358 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R359 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R360 VRS-CJ1JF392JY S 3.9k 1/16W Metal Oxide AA
R361 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R362 VRS-TW2HF220JY J 22 1/2W Metal Oxide AA
R363 VRS-TW2HF220JY J 22 1/2W Metal Oxide AA
R364 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1900 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R1901 VRS-CJ1JF472JY J 4.7k 1/16W Metal Oxide AA
R1902 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R1903 VRS-CJ1JF473JY S 47k 1/16W Metal Oxide AA
R1904 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1905 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R1906 VRS-CJ1JF471JY S 470 1/16W Metal Oxide AA
R1907 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R1908 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA

Sharp LC-13S1E Specifications

General

Brand	Sharp
Model	LC-13S1E
Category	LCD TV
Language	English
