Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
77
LC-13S1E
LC-15S1E
CABINET AND MECHANICAL PARTS
(LC-15S1E)
1
Not Available
– Cabinet A Ass’y Unit —
1-1 CCABAA373WJ02 S Cabinet A Ass’y BG
1-1-1
Not Available
– Cabinet A —
1-1-2 HDECQA269WJSA J R/C, LED Cover AE
1-1-3 PSPAHA050WJZZ J Spacer(L), x2 AC
1-1-4 PSPAHA051WJZZ J Spacer(S), x2 AC
1-1-5 QEARZ0047CEZZ J Grounding Part AC
1-2 QCNW-B662WJQZ J Connecting Cord(SP) AH
1-3 VSP7530PB628B J Speaker, x2 AN
1-4 XEBSN30P08000 J Screw, x6 AA
2 CCABBA267WJ02 S Cabinet B Ass’y BK
2-1
Not Available
– Cabinet B —
2-2 GCOVAA501WJKA J Terminal Cover AK
2-3 GLEGGA027WJSA J Rubber Leg, x2 AF
2-4 JBTN-A182WJKA J Operation Button AK
2-5 JBTN-A185WJKA J Power Button AF
2-6 LANGF2155CEFW J Round Rock AD
2-7 LANGTA079WJFW J Reinforcement Angle AM
2-8 MSPRCA014WJFW J Power Button Spring AB
2-10 XEBSN30P08000 J Screw, x3 AA
3 CDAi-A088WJ01 J Stand Ass’y BA
3-1 CDAi-A088WJ02 J Stand Base Ass’y AZ
3-1-1
Not Available
– Stand Base —
3-1-2 GLEGGA029WJSA J Rubber Leg AF
3-1-3 PSPAZA083WJZZ J Spacer, x2 AB
3-2 JHNDPA004WJSA J Stand Handle AT
3-3 XESSN40P10000 J Screw, x8 AB
4
Not Available
– 15” LCD Panel Unit Ass’y —
4-1 RLCDTA024WJZZ J 15” LCD Panel Unit CT
4-2
Not Available
– Back Shield Ass’y —
4-2-1 PSLDMA252WJFW J Back Shield AR
4-2-2 TCAUZA031WJZZ J Caution Label AB
å 4-3 KLMP-0122CEZZ J Lamp Unit BD
4-4 PGiDMA011WJZZ J Light Guide Plate BA
4-5 PMiR-0294CEZZ J Reflection Mirror(L), x2 AG
4-6 PMiR-0295CEZZ J Reflection Mirror(S), x2 AF
4-7 PSHEP0281CEZZ J Reflection/Deflection Sheet BE
4-8 PSHEP0282CEZZ J Prism Sheet AY
4-9 PSHEP0283CEZZ J Diffusion Sheet AL
4-10 PSHEP0284CEZZ J Reflection Sheet-1 AG
4-11 PSHEP0285CEZZ J Reflection Sheet-2 AG
4-12 PSHEP0307CEZZ J Reflection Sheet(Cover) AC
4-13 QCNW-B530WJQZ J Connecting Cord AE
4-14 QCNW-B531WJQZ J Connecting Cord AD
4-15 QCNW-B532WJQZ J Connecting Cord AF
4-19 PSLDMA284WJZZ J Shield, x1 AE
5 GCOVAA504WJKA J Bass Cone Cover AD
6 LCHSMA047WJKA J Chassis Frame(R) AL
7 LCHSMA052WJKA S Chassis Frame(L) AS
8 LHLDZA251WJKZ J Power Button Holder AD
9 LX-BZ3442CEF9 J Screw, x4 AB
10 QCNW-B528WJQZ J Connecting Cord AG
11 QCNW-B529WJQZ J Connecting Cord AG
12 QCNW-B533WJQZ J Connecting Cord AG
13
Not Available
– Serial No. Label —
14 HiNDPA605WJSA S Model Label AG
15 XBBS930P05000 J Screw, x1 AA
16 XBPSN30P10JS0 J Screw, x5 AB
17 XBPSN30P18JS0 J Screw, x3 AA
18 XEBSN30P08000 J Screw, x7 AA
19 XEBS930P14000 J Screw, x2 AA
20 RCORFA009WJZZ J Core AH
21 RCORFA031WJZZ J Core AH
25 PSPAGA033WJZZ J Spacer, x1 AB
26 PSPAHA077WJZZ J Spacer, x3 AB
27 TLABSA028WJSA S GOST Label(LC-15S1E(R))
To Next Page
