Sharp LC-15AV7U User Manual

15-4
A7121EL
Ref. No. Part No. Description
C1224 9HSHD1JJ3CH100 CHIP CERAMIC CAP.(1608) CH J 10pF/50V
C1301 9HSHD1JK30B103 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V
C1302 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1304 9HSHD1JJ3CH331 CHIP CERAMIC CAP. CH J 330pF/50V
C1305 9HSHD1JJ3CH331 CHIP CERAMIC CAP. CH J 330pF/50V
C1309 9HSA1J560TU008 CERAMIC CAP.(AX) CH J 56pF/50V
C1311 9HSE1CMASDL470 ELECTROLYTIC CAP. 47µF/16V M
C1312 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1313 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1314 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1315 9HSE1CMASDL470 ELECTROLYTIC CAP. 47µF/16V M
C1316 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1317 9HSE1CMASDL470 ELECTROLYTIC CAP. 47µF/16V M
C1318 9HSHD1JK30B102 CHIP CERAMIC CAP.(1608) B K 1000pF/50V
C1319 9HSHD1JJ3CH470 CHIP CERAMIC CAP.(1608) CH J 47pF/50V
C1320 9HSHD1JJ3CH470 CHIP CERAMIC CAP.(1608) CH J 47pF/50V
C1321 9HSHD1JJ3CH330 CHIP CERAMIC CAP.(1608) CH J 33pF/50V
C1322 9HSHD1JJ3CH330 CHIP CERAMIC CAP.(1608) CH J 33pF/50V
C1323 9HSHD1JK30B103 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V
C1324 9HSE1CMASDL101 ELECTROLYTIC CAP. 100µF/16V M
C1331 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1332 9HSE1CMASDL470 ELECTROLYTIC CAP. 47µF/16V M
C1334 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1335 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1336 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1337 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1338 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1339 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1340 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1341 9HSE1CMASDL470 ELECTROLYTIC CAP. 47µF/16V M
C1342 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1343 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1344 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1345 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1346 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1347 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1348 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1349 9HSE1CMASDL470 ELECTROLYTIC CAP. 47µF/16V M
C1350 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1351 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1352 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1353 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1355 9HSHD1JK30B104 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V
C1356 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1359 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1360 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1361 9HSE1CMASDL470 ELECTROLYTIC CAP. 47µF/16V M
C1362 9HSHD1AZ30F105 CHIP CERAMIC CAP. F Z 1µF/10V
C1366 9HSHD1EZ30F104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
C1368 9HSCA1JZTFZ104 CERAMIC CAP.(AX) F Z 0.1µF/50V
C1369 9HSHD1JJ3CH102 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V
C1705 9HSHD1AZ30F105 CHIP CERAMIC CAP. F Z 1µF/10V
CONNECTORS
CN401 9HS3BH020JG001 CONNECTOR PRINT OSU C/02/R/S02(8.0)B-BHS
CN403 9HS3BH020JG001 CONNECTOR PRINT OSU C/02/R/S02(8.0)B-BHS
CN1201 9HSCFNG33JG022 FMN CONNECTOR SIDE 33P 33FMN-STRK-A(LF)(SN)
CN1202 9HSCFNG25JG022 FMN CONNECTOR SIDE 25P 25FMN-STRK-A(LF)(SN)
CN1303 9HS3PHC04JG029 PH CONNECTOR TOP 4P B4B-PH-K-S (LF)(SN)
DIODES
D31 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D62 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D63 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D68 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D401 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D402 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D403 9HSDTB0MTZJ7R5 ZENER DIODE MTZJT-777.5B
D404 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D406 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D407 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
