Sharp LC-19SK25U-W User Manual

109
Ref. No. Part No.
★
Description Code Ref. No. Part No.
★
Description Code
LC-19SK25U/U-W
LC-19SB25U/U-W
LC-19SB15U
LC-19D45U
DUNTKE352FM02
MAIN UNIT (Continued)
C898 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C899 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C900 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C901 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C902 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C903 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C905 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C906 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C907 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C908 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C909 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C910 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C911 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C912 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C913 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C914 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C915 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C916 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C917 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C918 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C920 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C921 VCKYCY1EB104KY J 0.10 25V Ceramic AB
C922 VCKYCY1EB104KY J 0.10 25V Ceramic AB
C923 VCKYCZ1HB471KY J 470p 50V Ceramic AB
C924 VCKYCZ1HB471KY J 470p 50V Ceramic AB
C925 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C926 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1002 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1003 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1004 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1005 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1006 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1007 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1008 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1009 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1010 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C1012 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1013 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1014 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1021 RC-KZA383WJZZY J 10 25V Ceramic AC
C1201 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C2001 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C2002 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C2003 VCKYCY1AB105KY J 1 10V Ceramic AB
C2004 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C2009 VCKYTV1CB105KY J 1 16V Ceramic AC
C2010 VCKYTV1CB105KY J 1 16V Ceramic AC
C2021 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8201 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8202 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8203 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C8204 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C8205 VCKYCY1AB105KY J 1 10V Ceramic AB
C8206 VCKYCY1AB105KY J 1 10V Ceramic AB
C8207 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8208 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8209 VCKYCY1AB105KY J 1 10V Ceramic AB
C8210 VCKYCY1AB105KY J 1 10V Ceramic AB
C8211 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8212 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8213 VCKYCY1AB105KY J 1 10V Ceramic AB
C8214 VCKYCY1AB105KY J 1 10V Ceramic AB
C8215 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8216 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C8701 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C8702 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C9201 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9202 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9203 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9204 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C9205 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C9206 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9207 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9208 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9210 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9211 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C9212 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9213 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9217 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C9225 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C9227 VCKYCY1HB103KY J 0.010 50V Ceramic AA
C9228 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9229 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9230 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C9231 VCCCCZ1HH221JY J 220p 50V Ceramic AB
C9232 VCCCCZ1HH221JY J 220p 50V Ceramic AB
C9233 VCCCCZ1HH221JY J 220p 50V Ceramic AB
C9234 VCCCCZ1HH221JY J 220p 50V Ceramic AB
C9302 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
C9303 RC-KZA237WJZZY J 10 16V Ceramic AB
C9304 VCKYCZ1EF104ZY J 0.10 25V Ceramic AA
RESISTORS
R301 VRS-CZ1JF105JY J 1.0M 1/16W Metal Oxide AA
R302 VRS-CZ1JF222JY J 2.2k 1/16W Metal Oxide AA
R303 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R304 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R305 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R306 VRS-CZ1JF100JY J 10 1/16W Metal Oxide AA
R307 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R308 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R309 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R310 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R311 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R312 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R401 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R402 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R403 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R404 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R405 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R406 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R407 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R408 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R409 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R410 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R411 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R412 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R413 VRS-CZ1JF683JY J 68k 1/16W Metal Oxide AA
R414 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R415 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R416 VRS-CZ1JF104JY J 100k 1/16W Metal Oxide AA
R417 VRS-CZ1JF271JY J 270 1/16W Metal Oxide AA
R418 VRS-CZ1JF104JY J 100k 1/16W Metal Oxide AA
R419 VRS-CZ1JF271JY J 270 1/16W Metal Oxide AA
R420 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R421 VRS-CZ1JF271JY J 270 1/16W Metal Oxide AA
R423 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R424 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R425 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R426 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R427 VRS-CZ1JF303JY J 30k 1/16W Metal Oxide AA
R428 VRS-CZ1JF303JY J 30k 1/16W Metal Oxide AA
R429 VRS-CZ1JF683JY J 68k 1/16W Metal Oxide AA
R430 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R431 VRS-CZ1JF271JY J 270 1/16W Metal Oxide AA
R432 VRS-CZ1JF683JY J 68k 1/16W Metal Oxide AA
R433 VRS-CZ1JF822JY J 8.2k 1/16W Metal Oxide AA
R434 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R437 VRS-CZ1JF271JY J 270 1/16W Metal Oxide AA
R438 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R439 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R440 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R441 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R442 VRS-CZ1JF123JY J 12k 1/16W Metal Oxide AA
R443 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R444 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R445 VRS-CZ1JF474JY J 470k 1/16W Metal Oxide AA
R446 VRS-CZ1JF474JY J 470k 1/16W Metal Oxide AA
