117
Ref. No. Part No.
★
Description Code Ref. No. Part No.
★
Description Code
LC-19SK25U/U-W
LC-19SB25U/U-W
LC-19SB15U
LC-19D45U
CABINET AND MECHANICAL PARTS
LC-19SB25U/LC19SB25U-W/LC-19SB15U
1 CCABAB811WJ20 J
Cabinet A Ass'y (LC-19SB25U)
BC
1 CCABAB811WJ18 J Cabinet A Ass'y BC
(LC-19SB25U-W)
1 CCABAB811WJ21 J Cabinet A Ass'y BC
(LC-19SB15U)
1-1 Not Available - Cabinet A −
1-2 GCOVAC325WJ2A J SP Cover (LC-19SB25U) AQ
1-2 GCOVAC325WJ2B J
SP Cover (LC-19SB25U-W)
AQ
1-2 GCOVAC325WJ2C J SP Cover (LC-19SB15U) AQ
1-3 HDECQA765WJ2A J Led R/C Cover AD
1-4 PSPAHB215WJ00 J Mask Spacer(Side), x2 AB
1-5 PSPAHB216WJ00 J Mask Spacer, x2 AB
1-6 TLABZB513WJZZ J Pop Label AG
1-7 TLABZA635WJZZ J EnergyStar Label AC
1-8 LHLDZA867WJ2Z J SP-Holder (R) AD
1-9 LHLDZA874WJ2Z J SP-Holder (L) AD
1-10 PSPAGA378WJZZ J Gomu-Bush, x4 AB
1-11 XEBSN30P08000 J Screw For SP, x8 AA
1-12 VSP7530PA098S J Speaker, x2 AN
1-13 QCNW-G524WJQZ J For SP L/R AH
1-14 LX-HZA011WJFN J Screw For SP Holder, x2 AB
1-15 PSPAZB608WJZZ J Sponge For SP, x2 AC
1-18 PSPAHB367WJ00 J for SP(LC-19SB25U-W) AC
1-19 PSPAHB361WJ00 J Himelon AB
2 CCABBB097WJ04 J Cabinet B Ass'y BA
(LC-19SB25U/19SB15U)
2 CCABBB097WJ05 J Cabinet B Ass'y BA
(LC-19SB25U-W)
2-1 Not Available - Cabinet B −
2-2 PSPAHB320WJ00 J Mask Himelon-A AD
2-3 PSPAHB322WJ00 J Mask Himelon-B AB
2-4 PSPAZB967WJZZ J Spacer AD
3 CDAI-A375WJ01 J Stand Ass'y (LC-19SB25U) AY
3 CDAI-A375WJ02 J
Stand Ass'y (LC-19SB25U-W)
AY
3 CDAI-A375WJ06 J Stand Ass'y (LC-19SB15U) AY
3-1 Not Available - Stand Base −
3-2 GLEGGA062WJZZ J Foot, x6 AB
3-3 LANGHA065WJ2W J Stand Base Angle AN
3-4 XESSN30P08000 J Screw, x5(For Base Angle) AA
4 CSLDMB286WJ01 J Main Shield Ass'y AS
4-1 Not Available - Main Shield −
4-2 Not Available - Earth Plate −
4-3 LHLDWA181WJKZ J WH For Shield, x1 AC
4-4 PSPAHB287WJ00 J Mask For Main Shield AB
4-5 PSPAZB642WJZZ J Spacer AB
4-6 PSPAHB321WJ00 J Mask for Main Shield AB
4-7 PSPAHB360WJ00 J
Mask for Himelon Main Shield
AA
4-8 PSPAHB683WJ00 J Himelon, x1 AC
4-9 PSPAHB684WJ00 J Himelon, x2 AC
4-10 LHLDW1173CEZZ J Wire Holder, x2 AD
5 LANGTA465WJ01 J VSEA Ass'y AS
5-1 Not Available - VSEA Angle −
5-2 PSPAHB266WJ00 J Mask for Vesa AB
5-3 PZETKA237WJKZ J Barrier For Vesa AE
5-4 PZETKA286WJKZ J PC For Vesa AE
6 LANGT469WJ01 J AC Inlet Angle Ass'y AH
7 GCOVAC326WJ2A J Stand Cover AG
(LC-19SB24U/19SB15U)
7 GCOVAC326WJ2B J
Stand Cover (LC-19SB25U-W)
AG
8 GCOVAC327WJ2A J Bas-Conne Cover AE
(LC-19SB25U/19SB15U)
8 GCOVAC327WJ2B J Bas-Conne Cover AE
(LC-19SB25U-W)
9 GCOVAC350WJ2A J RS 232 Cover AD
(LC-19SB25U/19SB15U)
9 GCOVAC350WJ2B J RS 232 Cover AD
(LC-19SB25U-W)
10 JBTN-A675WJ2A J Control Button AF
(LC-19SB25U/19SB15U)
10 JBTN-A675WJ2B J Control Button AF
(LC-19SB25U-W)
11 LHLDWA181WJKZ J Wire Holder, x4 AC
12 LHLDWA092WJZZ J Wire Holder, x4 AB
13 LX-BZA202WJF7 J Screw, x13 (For PWB) AA
14 MHNG-A166WJ2Z J Hinji AV
15 PSLDMB178WJFW J Shield For Source PWB AH
16 PSPAZB626WJZZ J PC Sheet, x2 AB
17 PZETKA236WJKZ J Barrier Buttom AL
18 NSFTZ0134CEFW J For RGB 15-Dsub, x2 AD
19 PZETKA238WJKZ J Barrier for CONT-BTN AD
20 TLABMC569WJZZ J
Model Label (LC-19SB25U)
AD
20 TLABMC570WJZZ J
Model Label (LC-19SB25U-W)
AD
20 TLABMC754WJZZ J Model Label (LC-19SB15U) AH
21 XBBS940P08000 J Screw, x1(LC-19SB25U) AB
21 XBBSN40P08000 J Screw, x1(LC-19SB25U-W) AB
22 XBBS940P10000 J Screw, x4 AB
23 XBPS830P06000 J Screw, x1(LC-19SB25U) AA
23 XBPS730P06000 J Screw, x1(LC-19SB25U-W) AA
24 XEBS930P12000 J Screw, x3 AA
25 XEBS930P14000 J Screw, x9(LC-19SB25U) AA
25 XEBSN30P14000 J Screw, x9(LC-19SB25U-W) AA
26 XEBSN30P10000 J Screw, x1 AA
27 XEBSN40P10000 J Screw, x3 AB
!
28 —————— - refer to LCD Module Parts −
29 Not Available - Serial No. Label −
30 QCNW-G522WJQZ J Connecting Cord, AM
8pin RC Led
31 QCNW-G523WJQZ J Connecting Cord, 4 pin SW AH
32 QPWBM0242TPZZ J Connecting Cord, AG
FPC Main PWB-LCD
33 LX-BZA198WJF7 J Screw, x3 AB
34 PSPAHB360WJ00 J Mask for PWB, x6 AA
35 PSPAHB682WJ00 J Himelon, x2 AC
36 PSPAHB685WJ00 J Himelon, x1 AC
To Next Page
