Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
60
LC-20E1H
LC-20E1M
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
DUNTKA670FE35
DIGITAL UNIT
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
LCD PANEL
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCDTA014WJZZ J 20" LCD Panel Unit DT
INTEGRATED CIRCUITS
IC401 VHiBA7046F/-1Y J BA7046F AF
IC402 VHiNJM2235V-1Y J NJM2235V AE
IC702 VHiBA033FP/-1Y J BA033FP-E2 AG
IC703 VHiPQ20VZ11-1Y J PQ20VZ11 AG
IC801 VHiVPC3230D1EQ J VPC3230D-QA-B3 BD
IC1101 VHiMB8346BV-1Y J MB88346BPFV AN
IC1102 VHiNJM4565V-1Y J NJM4565V AF
IC1103 VHiNJM2060V-1Y J NJM2060V AF
IC1104 VHiNJM2060V-1Y J NJM2060V AF
IC1105 VHiBU4053V/-1Y J BU4053BCFV-E2 AE
IC1106 VHiNJM4580V-1Y J NJM4580V AE
IC1107 VHiNJM4580V-1Y J NJM4580V AE
IC1108 VHiNJM4580V-1Y J NJM4580V AE
IC1109 VHiNJM353M/-1Y J NJM353M AG
IC1110 VHiBU4053V/-1Y J BU4053BCFV-E2 AE
IC1111 VHiMB8346BV-1Y J MB88346BPFV AN
IC1112 VHiBU4053V/-1Y J BU4053BCFV-E2 AE
IC1113 VHiBU4053V/-1Y J BU4053BCFV-E2 AE
IC1114 VHiNJM4580V-1Y J NJM4580V AE
IC1115 VHiNJM4580V-1Y J NJM4580V AE
IC1116 VHiNJM2147M-1Y J NJM2147M-TE1 AF
IC1201 RH-iX3378CEN1Q J LR38815 AY
IC1202 VHiPD485505-2Y J UPD485505G-25 AY
IC1206 VHiLVX125FT-1Y J TC74LVX125FT AG
IC1207 VHiTC4W66U/-1Y J TC4W66FU AE
IC1208 VHiPQ1R34++-1Y J PQ1R34 AE
IC2001 RH-iXA381WJZZQ J M306V0ME-181FP AZ
IC2002 VHiBD4746G+-1Y J BD4746G-TR AD
IC2003 VHiTC4W66U/-1Y J TC4W66FU AE
IC2004 VHiBR2416E2-1Y J BR24C16F AK
TRANSISTORS
Q401 VS2SC3928AR-1Y J 2SC3928AR AB
Q402 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q711 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q712 VSDTC144EE/-1Y J DTC144EE AA
Q1101 VS2SA1729//-1Y J 2SA1729 AF
Q1102 VS2SC4520//-1Y J 2SC4520 AE
Q1103 VS2SA1036K/-1Y J 2SA1036K AC
Q1104 VS2SA1036K/-1Y J 2SA1036K AC
Q1105 VS2SA1036K/-1Y J 2SA1036K AC
Q1106 VSFMMT718//-1Y J FMMT718 AE
Q1107 VSDTC144EE/-1Y J DTC144EE AA
Q1108 VS2SC4520//-1Y J 2SC4520 AE
Q1109 VS2SA1729//-1Y J 2SA1729 AF
Q1201 VSDTC144EE/-1Y J DTC144EE AA
Q1203 VSDTC144EE/-1Y J DTC144EE AA
Q1204 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q1205 VSUMX2N++++-1Y J UMX2N++++ AB
Q2004 VSDTC114EE/-1Y J DTC144EE AB
Q2007 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D701 VHDDAN202K/-1Y J Diode AB
D1101 VHD1SS250//1EY J Diode AB
D1106 VHDDAN222//-1Y J Diode AA
D1107 VHD1SS250//1EY J Diode AB
D1108 VHDDAN222//-1Y J Diode AA
D1109 VHDDAN222//-1Y J Diode AA
D1110 VHDDAN222//-1Y J Diode AA
D1201 VHD1SS250//1EY J Diode AB
D1203 VHDRB491D++-1Y J Diode AD
D1205 VHDDAN222//-1Y J Diode AA
D1206 RH-EX0227CEZZY J Zener Diode AB
D1208 VHDDAN222//-1Y J Diode AA
D1209 RH-EX1247CEZZY J Zener Diode AB
D1210 VHDDAN222//-1Y J Diode AA
D1211 VHDDAN222//-1Y J Diode AA
D1212 VHDRB481K++-1Y J Diode AD
D2002 VHDRB491D++-1Y J Diode AD
D2004 RH-DX0061GEZZY J Diode AD
DUNTKA670FE35 – DIGITAL Unit —
DUNTKB476DE03 – ANALOG Unit
(LC-20E1H/M)
—
DUNTKB476DE06 – ANALOG Unit
(LC-20E1M(X))
—
DUNTKB477DE03 –
CONTROL Unit
(LC-20E1H/M)
—
DUNTKB477DE06 –
CONTROL Unit
(LC-20E1M(X))
—
DUNTKB478DE03 – R/C, LED Unit
(LC-20E1H/M)
—
DUNTKB478DE06 – R/C, LED Unit
(LC-20E1M(X))
—
DUNTKB590DE01 – INVERTER-A Unit —
DUNTKB591DE01 – INVERTER-B Unit —
