Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
64
LC-20E1H
LC-20E1M
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU3201 VTUVT2U5CD553 J Tuner(LC-20E1H/M) BD
TU3201 VTUVT2U5CD558 J Tuner(LC-20E1M(X)) BF
INTEGRATED CIRCUITS
IC3301 VHiNJM4560M-1Y J NJM4560M AG
IC3303 VHiNJM4560M-1Y J NJM4560M AG
IC3304 RH-iX1853BMZZQ J I.C. BB
IC3305 VHiLA4635A+-1S J LA4635A AM
IC3501 VHiTC4053BF1EY J TC4053BF AF
IC3701 VHiNJM2377M-1Y J NJM2377M AK
IC3702 VHiNJM2147M-1Y J NJM2147M-TE1 AF
TRANSISTORS
Q3201 VS2SC3928AR-1Y J 2SC3928AR AB
Q3202 VS2SC3928AR-1Y J 2SC3928AR AB
Q3203 VSDTC144EE/-1Y J DTC144EE AA
Q3204 VSDTC144EE/-1Y J DTC144EE AA
Q3205 VSDTC144EE/-1Y J DTC144EE AA
Q3303 VSDTA144EE/-1Y J DTA144EE AA
Q3304 VSDTC314TK/-1Y J DTC314TK AC
Q3305 VSDTC314TK/-1Y J DTC314TK AC
Q3306 VS2SC3928AR-1Y J 2SC3928AR AB
Q3500 VSUMG4N++++-1Y J UMG4N++++ AB
Q3501 VS2SK1467//-1Y J 2SK1467 AE
Q3502 VS2SK1467//-1Y J 2SK1467 AE
Q3503 VS2SC3928AR-1Y J 2SC3928AR AB
Q3504 VS2SC3928AR-1Y J 2SC3928AR AB
Q3505 VSDTC114EE/-1Y J DTC144EE AB
Q3510 VSDTC314TK/-1Y J DTC314TK AC
Q3511 VSDTC314TK/-1Y J DTC314TK AC
Q3512 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q3600 VSUPA606T//-1Y J UPA606T AD
Q3601 VSUPA606T//-1Y J UPA606T AD
Q3602 VSUPA606T//-1Y J UPA606T AD
Q3603 VSUPA606T//-1Y J UPA606T AD
Q3604 VSUPA606T//-1Y J UPA606T AD
Q3700 VSFMMT718//-1Y J FMMT718 AE
Q3701 VSDTC144EE/-1Y J DTC144EE AA
Q3702 VS2SK2503//-1Y J 2SK2503 AE
Q3704 VSFMMT619//-1Y J FMMT619 AE
Q3706 VSiMZ1/////-1Y J IMZ1///// AB
Q3707 VS2SC3928AR-1Y J 2SC3928AR AB
Q3708 VSDTC114YE/-1Y J DTC114YE AB
Q3709 VSFMMT718//-1Y J FMMT718 AE
Q3710 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D3301 RH-EX1396CEZZY J Zener Diode, 6.8V AB
D3302 VHDDAN222//-1Y J Diode AA
D3401 RH-EX1271CEZZY J Zener Diode, 12V AB
D3402 RH-EX1271CEZZY J Zener Diode, 12V AB
D3501 VHDDAN222//-1Y J Diode AA
D3600 VHDiMN10///-1Y J Diode AB
D3601 VHDiMN10///-1Y J Diode AB
D3602 VHDiMN10///-1Y J Diode AB
D3603 VHDiMN10///-1Y J Diode AB
D3604 VHDDAN222//-1Y J Diode AA
D3605 VHDDAN222//-1Y J Diode AA
D3606 VHDDAN222//-1Y J Diode AA
D3607 VHDDAN222//-1Y J Diode AA
D3608 VHDDAN222//-1Y J Diode AA
D3700 VHDDAN222//-1Y J Diode AA
D3703 VHDSFPB56//2EY J Diode AC
D3704 VHD1SS250//1EY J Diode AB
D3705 VHD1SS250//1EY J Diode AB
D3706 VHDSFPB74//2EY J Diode AD
D3707 VHDSFPB74//2EY J Diode AD
D3708 VHDDAN222//-1Y J Diode AA
D3709 VHDDAN222//-1Y J Diode AA
D3711 VHDDAN222//-1Y J Diode AA
PACKAGED CIRCUIT
X3301 RCRSB0307CEZZ J Crystal, 18.432MHz AG
COILS
L3201 VP-1M220J2R9NY J Peaking 22µH AB
L3202 RCiLPA027WJZZ J Coil AD
L3301 VP-1M101J7R7NY J Peaking 100µH AC
L3302 VP-1M4R7J1R2NY J Peaking 4.7µH AB
L3500 VP-1M101J7R7NY J Peaking 100µH AC
L3700 RCiLPA026WJZZ J Coil AD
L3702 RCiLPA026WJZZ J Coil AD
L3703 RCiLC0057CEZZY J Coil AD
L3704 RCiLC0055CEZZY J Coil AD
TRANSFORMER
å T3701 RTRNW0010CEZZY J Transformer AL
CONTROL
R3760 RVR-M0111CEZZY J 1k(B) B+Adj. AC
CAPACITORS
C3201 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3202 VCCCCY1HH330JY J 33p 50V Ceramic AA
C3203 VCCCCY1HH330JY J 33p 50V Ceramic AA
C3204 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3205 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3206 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C3208 RC-EZ1351CEZZ J 3300 6.3V Electrolytic AF
C3210 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3315 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3316 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C3317 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C3318 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C3319 VCKYCY1CB273KY J 0.027 16V Ceramic AB
C3320 VCEAPF1CN476MY J 47 16V Electrolytic AD
C3321 VCEAPF1HN225MY J 2.2 50V Electrolytic AD
C3322 VCEAPF1HN225MY J 2.2 50V Electrolytic AD
C3323 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3324 VCEAPF1HN225MY J 2.2 50V Electrolytic AD
C3325 VCEAPF1HN225MY J 2.2 50V Electrolytic AD
C3328 VCEAPF1HN225MY J 2.2 50V Electrolytic AD
C3329 VCEAPF1HN225MY J 2.2 50V Electrolytic AD
C3330 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3332 VCEAPF0JN107MY J 100 6.3V Electrolytic AD
C3333 VCEAPF1CN107MY J 100 16V Electrolytic AD
C3334 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3335 VCKYCY1HB272KY J 2700p 50V Ceramic AA
C3336 VCKYCY1HB272KY J 2700p 50V Ceramic AA
C3337 VCEAPF1CN106MY J 10 16V Electrolytic AD
C3338 VCEAPF1CN106MY J 10 16V Electrolytic AD
C3339 VCEAPF1HN335MY J 3.3 50V Electrolytic AD
C3340 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3341 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3342 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3343 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3344 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3345 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3346 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3347 VCEAPF1HW225MY J 2.2 50V Electrolytic AB
C3348 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3349 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3350 VCEAPF1CN106MY J 10 16V Electrolytic AD
C3351 RC-KZ1025CEZZY J 1 10V Ceramic AB
C3352 VCEAPF0JN107MY J 100 6.3V Electrolytic AD
C3354 VCCCCY1HH560JY J 56p 50V Ceramic AB
C3355 VCCCCY1HH560JY J 56p 50V Ceramic AB
C3356 VCCCCY1HH560JY J 56p 50V Ceramic AB
C3357 VCCCCY1HH5R0CY J 5.0p 50V Ceramic AA
C3358 VCCCCY1HH5R0CY J 5.0p 50V Ceramic AA
C3359 VCEAPF1CN106MY J 10 16V Electrolytic AD
C3360 VCEAPF1CN107MY J 100 16V Electrolytic AD
C3361 VCEAPF1HN105MY J 1 50V Electrolytic AD
C3362 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3363 VCEAPF1HN225MY J 2.2 50V Electrolytic AD
DUNTKB476DE03(LC-20E1H/M)
DUNTKB476DE06(LC-20E1M(X))
ANALOG UNIT
