Sharp LC-20S1M - Replacement Parts List

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
63
LC-20S1M
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which does no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
LCD PANEL
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
LC-20S1M
DUNTKB981DE12 – SUB Unit —
DUNTKB982DE12 – R/C,LED Unit —
DUNTKB983FE03 – INVERTER Unit —
DUNTKB988FE12 – MAIN Unit —
LC-20S1M(X)
DUNTKB981DE15 – SUB Unit —
DUNTKB982DE15 – R/C,LED Unit —
DUNTKB983FE03 – INVERTER Unit —
DUNTKB988FE12 – MAIN Unit —
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCDTA025WJZZ J 20" LCD Panel Unit DB
DUNTKB981DE12(LC-20S1M)
DUNTKB981DE15(LC-20S1M(X))
SUB UNIT
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU3201 VTUVT2U5CD553 J Tuner(LC-20S1M) BD
TU3201 VTUVT2U5CD558 J Tuner(LC-20S1M(X)) BF
INTEGRATED CIRCUITS
IC304 VHiBH3543F+-1Y J BH3543F-E2 AE
IC3301 RH-iX1853BMZZQ J MSP3410G-QG-B8 BB
IC3302 VHiBA4560F+-1Y J BA4560F-E2 AD
IC3303 VHiBA4560F+-1Y J BA4560F-E2 AD
IC3304 VHiBA4560F+-1Y J BA4560F-E2 AD
IC3305 VHiLA4635A+-1S J LA4635A AM
IC3401 VHiNJM2283F-1Y J NJM2283M AF
IC3402 VHiNJM2235V-1Y J NJM2235V AE
IC3501 VHiTC4053BF1EY J TC4053BF AF
IC3701 VHiNJM2377M-1Y J NJM2377M AK
IC3702 VHiNJM2147M-1Y J NJM2147M-TE1 AF
TRANSISTORS
Q302 VSDTC144EKA-1Y J DTC144EKA AB
Q3201 VS2SC3928AR-1Y J 2SC3928AR AB
Q3202 VS2SC3928AR-1Y J 2SC3928AR AB
Q3203 VSDTC144EE/-1Y J DTC144EE AA
Q3204 VSDTC144EE/-1Y J DTC144EE AA
Q3205 VSDTC144EE/-1Y J DTC144EE AA
Q3211 VSiMZ1A////-1Y J IMZ1A AC
Q3212 VSiMZ1A////-1Y J IMZ1A AC
Q3304 VSDTC314TK/-1Y J DTC314TK AC
Q3305 VSDTC314TK/-1Y J DTC314TK AC
Q3501 VSUMG4N++++-1Y J UMG4N AB
Q3502 VSFDC6305N+-1Y J FDC6305N AD
Q3503 VS2SC3928AR-1Y J 2SC3928AR AB
Q3504 VS2SC3928AR-1Y J 2SC3928AR AB
Q3505 VSDTC114EE/-1Y J DTC114EE AB
Q3510 VSDTC314TK/-1Y J DTC314TK AC
Q3511 VSDTC314TK/-1Y J DTC314TK AC
Q3512 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q3513 VS2SC2712Y/-1Y J 2SC2712Y AB
Q3701 VSDTC144EE/-1Y J DTC144EE AA
Q3702 VSFMMT718//-1Y J FMMT718 AE
Q3703 VSFMMT718//-1Y J FMMT718 AE
Q3704 VS2SK2503//-1Y J 2SK2503 AE
Q3705 VSDTC144EE/-1Y J DTC144EE AA
Q3708 VSDTC114YE/-1Y J DTC114YE AB
Q3709 VSDTC114YE/-1Y J DTC114YE AB
Q3711 VSFMMT619//-1Y J FMMT619 AE
Q3712 VS2SC3928AR-1Y J 2SC3928AR AB
Q3713 VSiMZ1A////-1Y J IMZ1A AC
Q3714 VSiMZ1A////-1Y J IMZ1A AC
DIODES
D301 VHDMA3120WA-1Y J Diode AD
D302 VHDMA3120WA-1Y J Diode AD
D303 VHDDAN222//-1Y J Diode AA
D3302 VHDDAN222//-1Y J Diode AA
D3304 RH-EX1271CEZZY J Zener Diode, 12V AB
D3305 RH-EX1271CEZZY J Zener Diode, 12V AB
D3401 RH-EX1271CEZZY J Zener Diode, 12V AB
D3402 RH-EX1271CEZZY J Zener Diode, 12V AB
D3403 RH-EX1271CEZZY J Zener Diode, 12V AB
D3404 RH-EX1271CEZZY J Zener Diode, 12V AB
D3405 RH-EX1271CEZZY J Zener Diode, 12V AB
D3501 VHDDAN222//-1Y J Diode AA
D3502 RH-EX1396CEZZY J Zener Diode, 6.8V AB
D3706 VHDSFPB56//2EY J Diode AC
D3708 VHDSFPB74//2EY J Diode AD
D3709 VHDSFPB74//2EY J Diode AD
D3710 VHDDAN222//-1Y J Diode AA
D3711 VHD1SS250//1EY J Diode AB
D3717 VHDDAN222//-1Y J Diode AA
D3718 VHDRB491D++-1Y J Diode AD
D3719 RH-EX1283CEZZY J Zener Diode, 18V AB
D3720 RH-EX1283CEZZY J Zener Diode, 18V AB
D4050 RH-EX1271CEZZY J Zener Diode, 12V AB
D4051 RH-EX1283CEZZY J Zener Diode, 18V AB
D4052 RH-EX1271CEZZY J Zener Diode, 12V AB
PACKAGED CIRCUITS
X3301 RCRSB0307CEZZ J Crystal, 18.432MHz AG
COILS
L3201 VP-1M220J2R9NY J Peaking 22µH AB
L3202 RCiLPA142WJZZ J Coil AD
L3301 VP-1M101J7R7NY J Peaking 100µH AC
L3302 VPCGM4R7MR13NYJ Peaking 4.7µH AB
L3500 VP-1M101J7R7NY J Peaking 100µH AC
L3701 RCiLPA026WJZZ J Coil AD
L3702 RCiLPA144WJZZY J Coil AD
L3703 RCiLPA143WJZZY J Coil AD
L3704 RCiLPA026WJZZ J Coil AD
TRANSFORMER
å T3701 RTRNWA090WJZZY J Transformer AH
