Sharp LC-20S5E-BK Service Manual

WAVEFORMS
21PIN
1
10μs
8
2ms
0.5V 500mV
SCALER
2
2ms
9
20ns
500mV 500mV
3
2ms
10
50μs
500mV 2.0V
AV JACK/ SWITCH
4
2ms
11
10μs
2.0V 2.0V
5
2ms
12
10ns
2.0V 500mV
TUNER RSDS
6
10μs
13
20ns
5.0V 500mV
SOUND AMP
7
2.0ms
500mV
The following waveforms were measured
at the point of the corresponding balloon
number in the schematic dia
g
ram.
NOTE:
I-1
