Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
131
LC-22AD1E
CABINET AND MECHANICAL PARTS
1 CCABAA380WJ01 J Front Cabinet Ass’y BL
1-1 Not Available – Front Cabinet —
1-2 GCOVAA449WJSA J RC/LED Cover AE
1-3 HBDGBA011WJSA J Badge ”SHARP” AG
1-4 LHLDW1025TAZZ J Holder AB
1-5 PSPAH0726CEUZ J Spacer, x2 AC
1-6 PSPAH0727CEUZ J Spacer, x2 AC
2 CCABBA275WJ01 J Rear Cabinet Ass’y BC
2-1 Not Available – Rear Cabinet —
2-2 HiNDPA567WJSA J Indicator AF
2-3 HiNDPA589WJSA J Indicator AD
2-4 LHLDZ0132CEZZ J Holder, x2 AD
3 CDAi-A045WJ09 J Stand BR
3-1 GDAi-A111WJSA J Stand, Base
3-2 CDAi-1123CE06 J Stand Joint Ass’y BC
3-2-1 Not Available – Stand Joint —
3-2-2 PSPAZA083WJZZ J Spacer, x2 AB
3-3 GCOVA1945CESA J Handle Grip AK
3-4 GCOVAA251WJSA J Stand Base Joint AM
3-5 GDAi-A082WJSA J Stand Support AS
3-6 GLEGGA014WJZZ J Foot, x6 AB
3-7 JHNDP0103CESA J Carrying Handle AX
3-8 LANGGA016WJFW J Swivel Base AG
3-9 LANGHA002WJFW J Fixing Metal, x2 AH
3-10 LX-BZA019WJFN J Screw, x2 AB
3-11 LX-NZA001WJFN J Nut AD
3-12 MHNG-A004WJFW J Swivel Hinge AU
3-13 TLABZ0793CESF J Label AC
3-14 XCBSN50P25000 J Screw, x4 AB
3-15 XCSSN50P20000 J Screw, x4 AB
3-16 XESSN40P10000 J Screw, x14 AB
3-17 XUSSN40P20000 J Screw, x4 AA
3-18 XWHSN50-16120 J Washer, x4 AB
4 CCOVAA537WJ01 J Top Cover Ass’y AS
4-1 Not Available – Top Cover —
4-2 GCOVAA259WJKA J Botton Cover, x2 AE
4-3 JBTN-A088WJKA J Power Button AF
4-4 JBTN-A100WJKA J Control Button AL
4-5 LHLDZA027WJKZ J Power Botton Holder AE
4-6 MSPRCA014WJFW J Power Botton Spring AB
4-7 XEBSN30P08000 J Screw, x2 AA
5 Not Available – 22”LCD Panel Unit Ass’y —
5-1 RLCDTA021WJZZ J 22” LCD panel unit EM
5-2 Not Available – Back Shielding Plate Ass’y —
5-2-1 PSLDMA322WJFW J Back Shielding Plate AV
5-2-2 LHLDW1173CEZZ J Wire Holder, x5 AD
5-2-3 PMLT-A100WJZZ J Shield spacer, x2 AB
5-2-4 PSPAGA136WJZZ J Spacer, x4 AB
5-2-5 PSPAZ0473CEZZ J Shield spacer AE
5-2-6 PSPAZA392WJZZ J Spacer AE
5-2-7 TCAUZA031WJZZ J Caution Card AB
5-3 KLMP-A022WJZZ J Lamp Unit-A BE
5-4 KLMP-A023WJZZ J Lamp Unit-B BE
5-5 LHLDZA218WJKZ J Lamp Fixing Holder (Top), x2 AL
5-6 LHLDZA219WJKZ J Lamp Fixing Holder (Bottom), x2 AK
5-7 LHLDZA223WJKZ J Lamp Clip, x2 AE
5-8 MSPRP1220CEFW J ITO Earth Spring AC
5-9 PSPAH0678CEZZ J HIMERON, x2 AA
5-10 PCOVU0108CEZZ J Diffusion Panel AY
5-11 PSHEP0294CEZZ J Diffusion Sheet AQ
5-12 PSHEPA002WJZZ J Prism Sheet BE
5-13 PSHEPA003WJZZ J Reflection/Deflection Sheet BR
5-14 PSHEPA112WJZZ J Reflection Sheet AN
5-15 QCNW-B658WJQZ J Connecting Cord (SCN1) AD
5-16 QCNW-B659WJQZ J Connecting Cord (SCN2) AD
5-17 QCNW-B657WJQZ J Connecting Cord (GD) AE
5-18 XBBSN30P05000 J Screw, x6 AA
5-19 XBBSN30P08000 J Screw, x4 AA
5-20 XEBSN30P08000 J Screw AA
6 RSP-ZA037WJN2 J Speaker BM
7 CPNLSA007WJ01 J Speaker net Ass’y BF
7-1 Not Available – Speaker net —
7-2 GCOVAA448WJSA J Speaker net Decoration Cover AW
7-3 PSPAGA128WJZZ J Spacer AE
7-4 PSPAGA156WJZZ J Spacer-D AC
7-5 PSPAHA238WJZZ J Spacer-B AC
7-6 PSPAHA239WJZZ J Spacer-C AC
8 CANGFA053WJ01 J Fan Angle Ass’y AL
8-1 Not Available – Fan Angle —
8-2 PSPAG0234CE00 J Gum Spacer AA
9 CCOVAA509WJ01 J Terminal Cover (L) Ass’y AS
9-1 Not Available – Terminal Cover (L) —
9-2 LHLDZA267WJKA J Holder AE
10 CCOVAA510WJ01 J Terminal Cover (R) Ass’y AS
10-1 Not Available – Terminal Cover (R) —
10-2 LHLDZA267WJKA J Holder AE
11 GCOVAA514WJKA J Chassis Frame AS
12 GCOVHA042WJKB J PC Card Cover AE
20 QCNW-B961WJQZ J Connecting Cord (PF) AH
22 QCNW-B445WJQZ J Connecting Cord (RA) AM
23 QCNW-B444WJQZ J Connecting Cord (KA) AG
24 QCNW-B886WJQZ J Connecting Cord (VA) AC
25 QCNW-B887WJQZ J Connecting Cord (VB) AC
26 QCNW-B888WJQZ J Connecting Cord (VC) AD
27 QCNW-B953WJQZ J Connecting Cord (ME) AE
28 QCNW-B954WJQZ J Connecting Cord (MF) AG
29 QCNW-B952WJQZ J Connecting Cord (MD) AP
30 QCNW-B962WJQZ J Connecting Cord (MG) AG
31 QCNW-B955WJQZ J Connecting Cord (MA)
32 QCNW-C315WJQZ J Connecting Cord AS
(MAIN-SP_SC_SD)
33 LANGK0782CEFW J Fixing Metal AF
34 XBBS930P08000 J Screw x4 AA
36 QCNW-B956WJQZ J Connecting Cord (MB) AN
38 QCNW-B958WJQZ J Connecting Cord (SB) AK
39 QCNW-B957WJPZ J Connecting Cord (SA) AQ
40 DUNTKB973FE04 – INVERTER Unit —
41 DUNTKC160DE01 – AV Unit —
43 DUNTKC162DE01 – R/C, LED Unit —
44 DUNTKC163DE01 – OPERATION Unit —
45 DUNTKC164DE01 – EXT-SP TERMINAL Unit —
46 DUNTKC165DE01 – SP-JACK Unit —
47 DUNTKC166DE01 – MAIN Unit —
48 RUNTKA060WJZZ J EU-DIGITAL Unit CR
49 B2SX4052BT J 1BIT-AMP Unit BL
53 GCOVAA511WJKA J Terminal Cover (C) AM
54 GCOVAA536WJKA J Chassis Frame Cover AG
55 GCOVA2072CEKA J BASS-Connector Cover AE
57 LANGKA167WJFW J SP Angle (L) AK
58 LANGKA214WJFW J SP Angle (R) AH
59 LANGTA085WJFW J Stand Reinforcement Angle AR
60 LHLDW1060CEZZ J Wire Holder AB
61 NFANR0126CEZZ J FAN AT
62 PSLDMA382WJZZ J Shield AH
63 PSPAZA327WJKZ J Spacer AN
64 PFLT-A037WJZZ J Felt AG
65 PSLDMA349WJZZ J Gasket AF
69 Not Available – Sirial No.Label (LC-22AD1E) —
70 RCORFA028WJZZ J Core, x2 AK
71 LX-BZ3442CEF9 J Screw, x8 AB
73 XBBSN40P06000 J Screw, x4 AA
74 XEBS930P08000 J Screw, x2 AA
75 XBPSN30P06JS0 J Screw, x15 AB
76 XBPSN30P08JS0 J Screw, x7 AB
77 XBPSN30P20XS0 J Screw, x2 AB
78 XEBSN30P08000 J Screw, x19 AA
79 XEBSN40P10000 J Screw, x2 AB
80 XEBS930P08000 J Screw, x4 AA
