Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
115
LC-22AD1E
R6565 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6566 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6567 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6568 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R6569 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6570 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6571 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6572 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R6573 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6574 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6575 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6576 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R6577 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6578 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6579 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6580 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R6581 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6582 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6583 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6584 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6585 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6586 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6587 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R6588 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
å F6551 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6552 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6553 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
å F6554 QFS-D0006CEZZ J Fuse, 1.25A/250V AF
FH6551 QFSHD1002CEZZ J Fuse Holder AA
FH6552 QFSHD1002CEZZ J Fuse Holder AA
FH6553 QFSHD1002CEZZ J Fuse Holder AA
FH6554 QFSHD1002CEZZ J Fuse Holder AA
FH6555 QFSHD1002CEZZ J Fuse Holder AA
FH6556 QFSHD1002CEZZ J Fuse Holder AA
FH6557 QFSHD1002CEZZ J Fuse Holder AA
FH6558 QFSHD1002CEZZ J Fuse Holder AA
P6551 QPLGN0155FJZZY J Plug, 3pin (LA) AE
P6552 QPLGN0155FJZZY J Plug, 3pin (LB) AE
P6553 QPLGN0155FJZZY J Plug, 3pin (LC) AE
P6554 QPLGN0155FJZZY J Plug, 3pin (LD) AE
P6555 QPLGNA059WJZZ J Plug, 5pin (PF) AC
DUNTKC160DE01
AV Unit
OPT DEVICE
IC1101 VHPGP1FH5TZ-1 J PhotoDiode AP
TRANSISTORS
Q1101 VS2SC3928AR-1Y J 2SC3928AR AB
Q1102 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D1101 RH-EX1271CEZZY J Zener Diode, 12V AB
D1102 RH-EX1271CEZZY J Zener Diode, 12V AB
D1103 RH-EX1271CEZZY J Zener Diode, 12V AB
D1104 RH-EX1271CEZZY J Zener Diode, 12V AB
D1105 RH-EX1271CEZZY J Zener Diode, 12V AB
D1106 RH-EX1264CEZZY J Zener Diode, 10V AB
D1107 RH-EX1264CEZZY J Zener Diode, 10V AB
D1108 RH-EX1264CEZZY J Zener Diode, 10V AB
D1109 RH-EX1264CEZZY J Zener Diode, 10V AB
D1110 RH-EX1271CEZZY J Zener Diode, 12V AB
D1111 RH-EX1271CEZZY J Zener Diode, 12V AB
D1112 RH-EX1271CEZZY J Zener Diode, 12V AB
D1113 RH-EX1315CEZZY J Zener Diode AC
D1114 RH-EX1315CEZZY J Zener Diode AC
D1115 RH-EX1315CEZZY J Zener Diode AC
D1116 RH-EX1315CEZZY J Zener Diode AC
D1117 RH-EX1264CEZZY J Zener Diode, 10V AB
D1118 RH-EX1264CEZZY J Zener Diode, 10V AB
D1119 RH-EX1264CEZZY J Zener Diode, 10V AB
D1120 RH-EX1264CEZZY J Zener Diode, 10V AB
D1121 RH-EX1264CEZZY J Zener Diode, 10V AB
D1122 RH-EX1264CEZZY J Zener Diode, 10V AB
D1123 RH-EX1264CEZZY J Zener Diode, 10V AB
D1124 RH-EX1264CEZZY J Zener Diode, 10V AB
D1125 RH-EX1264CEZZY J Zener Diode, 10V AB
COILS
L701 RCiLFA069WJZZ J Coil AH
L1101 VPCNN100J1R6NY J Peaking 10µH AB
L1102 VPD9M4R7J1R4NY J Peaking 4.7µH AB
L1103 RCiLPA027WJZZ J Coil AD
CAPACITORS
C1100 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1101 VCEASX1CN106MY J 10 16V Electrolytic AC
C1102 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1103 VCEASX1CN106MY J 10 16V Electrolytic AC
C1104 VCKYTV1CB105KY J 1 16V Ceramic AC
C1105 VCKYTV1CB105KY J 1 16V Ceramic AC
C1106 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1107 RC-EZA127WJZZY J 100 16V Electrolytic AC
C1108 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1109 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1110 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1111 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1112 VCKYTV1CB105KY J 1 16V Ceramic AC
C1114 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1115 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1116 VCEASX1CN476MY J 47 16V Electrolytic AC
C1117 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1118 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1119 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1120 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1121 VCEASW0JN477MY J 470 6.3V Electrolytic AD
C1123 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1124 VCAAPC0JJ337MY J 330 6.3V Electrolytic AG
C1125 VCEASX1CN107MY J 100 16V Electrolytic AC
C1126 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1127 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1128 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1129 VCAAPC0JJ337MY J 330 6.3V Electrolytic AG
C1130 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1131 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1132 VCKYCY1HB102KY J 1000p 50V Ceramic AA
DUNTKB973FE04
INVERTER Unit (Continued)
