Sharp LC-22DV510K Service Manual

108
LC-22DV510
LC-24DV510
REF No.
PARTS DESCRIPTION *
PRICE
CODE
Q188 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q189 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q190 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q191 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q192 30010733 TR NMOS 2N7002 0.1A/60V SOT23 ROHS G --
Q193 30001458 TR BC858B SMD G --
Q194 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q195 30001458 TR BC858B SMD G --
Q197 30018060 TR PMOS FDC642P -4A/-20V SSOT6 ROHS G --
Q199 30018060 TR PMOS FDC642P -4A/-20V SSOT6 ROHS G --
Q200 30018060 TR PMOS FDC642P -4A/-20V SSOT6 ROHS G --
Q202 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q204 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q205 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q207 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q208 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q209 30069749 TR NMOS BSH105 1.05A/30V SOT23 ROHS G --
Q210 30010733 TR NMOS 2N7002 0.1A/60V SOT23 ROHS G --
D145 30012411 DIODE SMD BA782 0.1A 35V SOD123 ROHS G --
D165 30042066 DIODE SMDSCH1N5819 1A/40V/25A SOD123ROHS G --
D169 30019996 DIODE BAV70 215mA/75V 4A SOT23 RoHS G --
D171 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D173 30062776 DIODE ESD AZ1045-04S SOT23-6 ROHS G --
D174 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D175 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D176 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D177 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D178 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D181 30038498 DIODE SMD ZEN C18V SOD123 ROHS G --
D184 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D185 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D186 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D189 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D191 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D2 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D203 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D204 30038502 DIODE SMD ZEN B5.1V SOD123 ROHS G --
D7 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
X2 30057263 XTAL 24MHz 22pF 30ppm 25OhmHC49S SMDROHS G --
F179 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F181 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F187 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F200 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F201 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F202 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F203 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F205 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F206 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F248 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F259 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F261 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F266 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F268 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F270 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
DIODES
PACKAGED CIRCUITS
COILS AND FILTERS
REF No.
PARTS DESCRIPTION *
PRICE
CODE
F271 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F272 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F273 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F274 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F275 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F277 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F286 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F288 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F289 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F291 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F294 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F295 30024778 FERRIT SMD 60R/100MHz 0.1R M 0.5A 603Ro G --
F296 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F297 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F298 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F299 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F300 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F301 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F303 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F305 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
FS1 30062423 FUSE SAFE SMD 4A/32VDC UF HMELT 1206RoHS G --
FS4 30064145 FUSE SAFE SMD 2A/63VDC UF 1206 RoHS G --
FS5 30062423 FUSE SAFE SMD 4A/32VDC UF HMELT 1206RoHS G --
L104 30055201 COIL SMD 2.2uH 15mA J 1R15 603 Ro G --
L114 30016659 COIL SMD 1uH 50mA K 0R4 805 Ro G --
L115 30068279 COIL SMD 120nH 0.4A J 0R51 805 Ro G --
L116 30058702 COIL SMD 10uH 2.5A M 0R4 7x7(SHL)Ro G --
L117 30058702 COIL SMD 10uH 2.5A M 0R4 7x7(SHL)Ro G --
L119 30025158 COIL SMD 4.7uH 0.03A M 1R 805 Ro G --
L120 30025158 COIL SMD 4.7uH 0.03A M 1R 805 Ro G --
L123 30057938 COIL SMD 22uH 3.6A M 35R12x12(SHL)Ro G --
L124 30068280 COIL SMD 150nH 0.15A J 2R8 402 Ro G --
TU102 30069671 TUNER DIG. HALF-NIM DTOS403LH122E RoHS G --
C1001 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1004 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1005 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1007 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1008 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1009 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1014 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1015 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1016 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1022 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1024 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1025 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1028 30046140 CAP SMD 10UF 6.3V M X5R (0805) ROHS G --
C1029 30046140 CAP SMD 10UF 6.3V M X5R (0805) ROHS G --
C1030 30046140 CAP SMD 10UF 6.3V M X5R (0805) ROHS G --
C1031 30015406 CAP ELCH 22UF 16V M 30mA 4x5.4 ROHS G --
C1032 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C1033 30069320 CAP SMD 22UF 6.3V M X7R (1206) RoHS G --
C1034 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1035 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1036 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
TUNER
CAPACITORS
